Case IH 785 Tractor Parts
Replacement parts for the Case IH 785 Tractor. Browse our selection of OEM and aftermarket parts — filters, belts, hydraulics, electrical, and more.
The Case IH 785 tractor, manufactured from 1985 to 1990, was a versatile workhorse powered by a reliable diesel engine producing around 76 horsepower. Known for its robust build and user-friendly operation, the 785 offered a PTO horsepower rating suitable for a variety of implements, making it a popular choice for mixed farming operations.
About the 785
The Case IH 785 was introduced in 1985 as part of the Case IH 85 series, replacing earlier International Harvester models. Production continued until 1990. It was designed to be a reliable and versatile tractor suitable for a wide range of farming tasks. The 785 is powered by an International Harvester D-239 diesel engine, a 239 cubic inch (3.9L) 4-cylinder engine, producing approximately 76 horsepower. The tractor features a mechanical transmission with multiple speed options. These typically included a synchronized gear transmission with several forward and reverse speeds, allowing for precise speed control in the field. The PTO delivers around 68 horsepower at 540 RPM. The hydraulic system provides around 11.5 GPM flow, sufficient for operating various implements, with available remotes. It has a Category II 3-point hitch. The 785 found applications in row crop farming, hay production, livestock operations, and light tillage. It distinguished itself with its balanced power, simple mechanics, and dependability compared to larger or more complex models within the Case IH lineup.
785 Specifications
| Engine | International Harvester D-239 76 HP 239 ci Diesel |
|---|---|
| PTO HP | 68 HP @ 540 RPM |
| Transmission | Synchroshift 8/4 |
| Hydraulics | 11.5 GPM, 2 remotes |
| 3-Point Hitch | Category II, 3850 lbs lift |
| Fuel Capacity | 24 gallons |
| Weight | 6,700 lbs |
| Years Produced | 1985-1990 |
785 Maintenance Tips
- Change engine oil and filter every 250 hours of operation using a high-quality oil that meets or exceeds the manufacturer's specifications.
- Regularly inspect and maintain the hydraulic system. Check hydraulic fluid levels, look for leaks, and replace hydraulic filters according to the recommended intervals.
- Use clean, high-quality diesel fuel and replace fuel filters as needed to prevent fuel system contamination and ensure optimal engine performance.
- Before storing the tractor for an extended period, drain the fuel tank and add a fuel stabilizer to prevent fuel degradation and corrosion. Also, inspect and lubricate all grease fittings.
785 History & Background
The Case IH 785 was introduced in 1985 following the merger of Case and International Harvester, representing a continuation of the IH legacy under the Case IH banner. There were no major redesigns during its production run. It solidified Case IH's position in the mid-range tractor market.
Frequently Asked Questions
Which water pump fits the Case IH 785?
For the Case IH 785, the recommended replacement water pump is 3132739R94 - Water pump.
What fuel filter is recommended for the Case IH 785?
A suitable fuel filter for the Case IH 785 is 3044506R1 - Filter, Fuel.
Which ignition switch is compatible with the Case IH 785?
The 3107556R1 - Switch w/ 2 Keys, Ignition is a compatible replacement for the Case IH 785.
What are common parts needed for the 785?
Commonly needed parts for the Case IH 785 include a 83937061 - Filter, Fuel, a 3125322R2 - Disc, Clutch Driven, a 59879D - Bearing, Release: 2.375" ID (sealed), a 3116407R3 - Tie Rod, Short (RH), a ST553 - Bearing, Pilot (sealed), and a 1500626C92 - Cap, Radiator w/ Cover (10 lb.).

SK163 - Piston Liner Kit
SKU: SK163
35 in stock

3216599R91 - Short Axle Shaft
SKU: 3216599R91
13 in stock

3125172R1 - Tie Rod Tube
SKU: 3125172R1
20 in stock

3116407R3 - Short (RH) Tie Rod
SKU: 3116407R3
40 in stock

1968468C1 - Ball Joint
SKU: 1968468C1
30 in stock

1502269C2 - Tie Rod
SKU: 1502269C2
9 in stock

3136053R92 - Water Pump
SKU: 3136053R92
144 in stock

C5NN13N359E - Warning Lamp / Turn Signal (12 Volt)
SKU: C5NN13N359E
96 in stock

A139458 - Sealed Beam Halogen Lamp (12 Volt)
SKU: A139458
79 in stock

87703630 - Amber LED Flasher/Tail Light Lamp
SKU: 87703630
88 in stock

1333295C1 - LH Dip Headlamp (RH/LH)
SKU: 1333295C1
7 in stock

130609 - AMBER FL LIGHT
SKU: 130609
96 in stock

OKD246 - Major Engine Overhaul Kit
SKU: OKD246
8 in stock

IKD246 - In Frame Engine Overhaul Kit
SKU: IKD246
8 in stock

93835C92 - Hydraulic Gear Pump
SKU: 93835C92
33 in stock

67698C92 - Steering w/o Relief Valve Motor
SKU: 67698C92
26 in stock

366441A1 - Hydraulic; Steering Pump
SKU: 366441A1
19 in stock

K914312 - Front Wheel 5.5" X 16" Rim
SKU: K914312
260 in stock

K611270 - Rim Wheel (10 Pk) Bolt
SKU: K611270
7450 in stock

E1ADKN1015A - Front Wheel 5.5" X 16" Rim
SKU: E1ADKN1015A
260 in stock

E1ADDN1015B - Front Wheel 5.5" X 16" Rim
SKU: E1ADDN1015B
260 in stock

D8NN1007BA - Front Wheel 5.5" X 16" Rim
SKU: D8NN1007BA
260 in stock

D2NN1007S - Front Wheel 5.5" X 16" Rim
SKU: D2NN1007S
260 in stock

D2NN1007N - Front Wheel 5.5" X 16" Rim
SKU: D2NN1007N
260 in stock
