Case IH 784 Tractor Parts
Browse Case IH 784 Tractor replacement parts. Everything from routine maintenance items to hard-to-find components.
The Case IH 784 tractor, manufactured from 1978 to 1984, was a versatile workhorse for farmers. Powered by a robust 55-horsepower diesel engine, and boasting around 50 PTO horsepower, it provided ample power for a variety of tasks. Its reliability and straightforward design made it a popular choice for farmers needing a dependable utility tractor.
About the 784
The Case IH 784 was part of the International Harvester/Case IH line of tractors produced from 1978 to 1984. It succeeded earlier models, incorporating improvements in engine technology and operator comfort. The 784 was equipped with an International Harvester D-239 diesel engine, a 239 cubic inch (3.9L) 4-cylinder engine producing approximately 55 horsepower. The transmission was typically a gear-drive, offering 8 forward and 4 reverse speeds, providing suitable speed ranges for various farm operations. PTO horsepower was around 50 HP, available at the standard 540 RPM. Hydraulic capacity was adequate for operating implements, with a typical flow rate around 8-10 GPM and often featuring one or two remote valves. The 3-point hitch was Category II, capable of lifting around 3300 lbs. Common applications included row crop work, haying, livestock operations (feeding, manure handling), and light tillage. What set the 784 apart was its simple design and its ability to perform well in a wide range of farming activities, making it a very versatile tractor for its time. It was smaller and more maneuverable than the larger Case IH models like the 986, but offered more power and capabilities than the compact 584.
784 Specifications
| Engine | International Harvester D-239 55 HP 239 ci Diesel |
|---|---|
| PTO HP | 50 HP @ 540 RPM |
| Transmission | Gear Drive 8 Forward/4 Reverse |
| Hydraulics | 8 GPM, 1-2 remotes |
| 3-Point Hitch | Category II, 3300 lbs |
| Fuel Capacity | 18 gallons |
| Weight | 6,000 lbs |
| Years Produced | 1978-1984 |
784 Maintenance Tips
- Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using a high-quality diesel engine oil. Regularly inspect the oil level and condition.
- Hydraulic System: Inspect hydraulic oil levels and filters every 500 hours. Change hydraulic fluid every 1000 hours or as recommended by the manufacturer to prevent contamination and ensure proper function.
- Fuel System: Use clean, high-quality diesel fuel. Drain the fuel sediment bowl regularly to remove water and contaminants. Replace the fuel filter every year or 500 hours of operation.
- Seasonal Storage: Before storing the tractor for extended periods, fill the fuel tank to prevent condensation. Disconnect the battery and store it in a cool, dry place. Consider adding fuel stabilizer to prevent fuel degradation.
784 History & Background
The Case IH 784 was introduced in 1978 as part of International Harvester's updated line of utility tractors. It represented a step up in power and features from earlier models while maintaining a compact and user-friendly design. Its reliability and versatility contributed to its popularity and cemented its place as a valuable tractor in agricultural history.
Frequently Asked Questions
Which water pump fits the Case IH 784?
The 3132739R94 - Water pump is a suitable replacement for the Case IH 784 tractor.
What PTO clutch disc is recommended for the Case IH 784?
For the Case IH 784, the 401716R2 - Disc, PTO Clutch is a recommended replacement part.
Which fuel filter is suitable for the Case IH 784?
The 3044506R1 - Filter, Fuel is a suitable replacement for the Case IH 784.
What are common parts needed for the 784?
For routine maintenance and wear part replacement on your Case IH 784, consider stocking up on items such as the K960911 - Element, Fuel Filter, a 527658R91 - Tie Rod, Short for steering, a 3125322R2 - Disc, Clutch Driven, or a ST553 - Bearing, Pilot (sealed).

A173180 - Muffler
SKU: A173180
11 in stock

SK163 - Piston Liner Kit
SKU: SK163
35 in stock

C5NN3A300C - Front Drag Link End
SKU: C5NN3A300C
113 in stock

67529C1 - Tie Rod Tube
SKU: 67529C1
248 in stock

65082C91 - Long Tie Rod
SKU: 65082C91
22 in stock

65079C91 - Long Tie Rod
SKU: 65079C91
213 in stock

65077C91 - Long Tie Rod
SKU: 65077C91
36 in stock

65074C91 - Long Tie Rod
SKU: 65074C91
16 in stock

612884R1 - Hub Cap
SKU: 612884R1
46 in stock

530104R91 - Seal
SKU: 530104R91
881 in stock

527658R91 - Short Tie Rod
SKU: 527658R91
237 in stock

43747D - Tie Rod Clamp
SKU: 43747D
403 in stock

390686R1 - Jam Nut
SKU: 390686R1
295 in stock

379327R91 - Tie Rod End
SKU: 379327R91
19 in stock

379326R91 - Tie Rod End
SKU: 379326R91
113 in stock

3129380R2 - Long Tie Rod
SKU: 3129380R2
9 in stock

3125172R1 - Tie Rod Tube
SKU: 3125172R1
20 in stock

3125171R2 - Long Tie Rod
SKU: 3125171R2
Out of stock

3121257R91 - Knee Extension (RH)
SKU: 3121257R91
12 in stock

3121256R91 - Knee Extension (LH)
SKU: 3121256R91
12 in stock

3116408R1 - Tie Rod Tube
SKU: 3116408R1
29 in stock

223326 - Complete Tie Rod Assembly
SKU: 223326
74 in stock

1502269C2 - Tie Rod
SKU: 1502269C2
9 in stock

1332805C2 - Outer Tie Rod
SKU: 1332805C2
188 in stock
