Case IH 770 Tractor Parts

Browse Case IH 770 Tractor replacement parts. Everything from routine maintenance items to hard-to-find components.

The Case IH 770 tractor, manufactured from 1976 to 1978, was a popular choice among farmers for its reliability and versatility. Powered by a robust 70 horsepower diesel engine, it delivered ample power for various tasks. With a PTO horsepower of around 64, the 770 was well-suited for running implements and machinery, making it a valuable asset in any farming operation.

About the 770

The Case IH 770 tractor was produced from 1976 to 1978, representing a solid, mid-sized option in the Case IH lineup of the era. It was powered by a Case IH D-239 4-cylinder diesel engine, producing approximately 70 horsepower. The engine's displacement was 239 cubic inches. This tractor featured a gear-drive transmission, offering 8 forward and 2 reverse speeds. The PTO delivered around 64 horsepower at 540 RPM. Hydraulic capacity was approximately 13 GPM, providing sufficient power for implements. The 3-point hitch was a Category II, capable of lifting around 3500 lbs. The 770 found applications across various farming operations, including row crop work, hay baling, livestock feeding, and light tillage. Compared to other models in the line, the 770 offered a balance of power and maneuverability, making it ideal for farms needing a versatile machine for a range of tasks. It filled a niche between smaller utility tractors and larger, more specialized row-crop machines.

770 Specifications

EngineCase IH D-239 70 HP 239 ci Diesel
PTO HP64 HP @ 540 RPM
TransmissionGear 8F/2R
Hydraulics13 GPM, 2 remotes
3-Point HitchCategory II, 3500 lbs
Fuel Capacity25 gallons
Weight6,000 lbs
Years Produced1976-1978

770 Maintenance Tips

  • Change engine oil and filter every 250 hours of operation. Use a high-quality oil designed for diesel engines.
  • Inspect and maintain hydraulic fluid levels regularly. Replace hydraulic filters according to the manufacturer's recommendations, typically every 500 hours.
  • Ensure the fuel system is clean and free of contaminants. Use fuel stabilizer during seasonal storage to prevent fuel degradation.
  • Before storing the tractor for the off-season, drain fluids and replace them with fresh fluids to prevent corrosion and ensure optimal performance when put back into service.

770 History & Background

The Case IH 770 was introduced in 1976 as part of the Case IH lineup, offering a reliable and versatile tractor for mid-sized farming operations. It was a well-regarded model that contributed to the brand's reputation for producing durable and capable agricultural equipment. Its availability during a period of significant agricultural growth cemented its place in farming history.

Frequently Asked Questions

Which thermostat is recommended for the Case IH 770?

For optimal engine temperature regulation in the Case IH 770, consider the 3042303R1 - Thermostat (180°).

What replacement clutch plate is suitable for the Case IH 770?

A recommended replacement for the Case IH 770 clutch system is the 1981280C1 - Clutch Plate, Sintered.

What fuel filter is compatible with the Case IH 770?

For the Case IH 770, a compatible fuel filter option is the 3044506R1 - Filter, Fuel, ensuring clean fuel delivery to your engine.

What are common replacement parts for the Case IH 770?

Regular maintenance for your Case IH 770 often involves replacing items such as the A44762 - Tie Rod End (RH Thread), Short, a 83937061 - Filter, Fuel, or a 1975469C1 - Brake Disc. Additionally, seals like A57250 - Seal and engine components like the A57641 - Thermostat (180°) are frequently needed.

Showing 1-24 of 145 products
