Case IH 686 Tractor Parts
Replacement parts for the Case IH 686 Tractor. Browse our selection of OEM and aftermarket parts — filters, belts, hydraulics, electrical, and more.
The Case IH 686 tractor, manufactured from 1976 to 1981, was a popular choice for farmers due to its reliable performance and versatile capabilities. Powered by a diesel engine producing around 66 horsepower, the 686 offered sufficient power for various tasks. Its robust design and practical PTO horsepower made it a valuable asset for small to medium-sized farming operations.
About the 686
The Case IH 686 tractor was introduced in 1976 and remained in production until 1981, forming part of the International Harvester (IH) line that transitioned to Case IH. This model was designed to offer a balance of power and affordability to farmers. Under the hood, it typically featured an International Harvester D-239 4-cylinder diesel engine, producing approximately 66 engine horsepower. Displacement was around 239 cubic inches. The transmission was typically a gear-type transmission with 8 forward and 4 reverse speeds, providing ample gearing options for diverse tasks. The PTO horsepower was rated at around 58 HP, available in a 540 RPM configuration. The hydraulic system offered a flow rate of approximately 12 GPM, powering rear remotes for implements. Its 3-point hitch was classified as Category II, with a lift capacity around 3,300 lbs. Farmers commonly utilized the 686 for tasks like row crop cultivation, hay baling, livestock feeding, and light tillage. Compared to smaller models, the 686 offered increased power and hydraulic capacity, while remaining more economical and maneuverable than the larger IH models. Its straight forward design contributed to easy maintenance and repair.
686 Specifications
| Engine | International Harvester D-239 66 HP Diesel |
|---|---|
| PTO HP | 58 HP @ 540 RPM |
| Transmission | Gear, 8F/4R |
| Hydraulics | 12 GPM, 2 remotes |
| 3-Point Hitch | Category II, 3300 lbs lift capacity |
| Fuel Capacity | 21 gallons |
| Weight | 6,140 lbs |
| Years Produced | 1976-1981 |
686 Maintenance Tips
- Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using a high-quality oil meeting the manufacturer's specifications. Regular oil changes are crucial for engine longevity.
- Hydraulic System: Inspect and maintain hydraulic fluid levels regularly. Replace hydraulic filters every 500 hours or as recommended to prevent contamination and ensure smooth operation.
- Fuel System: Use clean, high-quality diesel fuel and replace the fuel filter annually or after every 500 hours of operation. Drain any water accumulation from the fuel tank periodically.
- Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel, grease all fittings, and disconnect the battery. Store the tractor in a dry location to prevent rust and corrosion.
686 History & Background
The Case IH 686 was launched during a period of transition for International Harvester, eventually becoming a Case IH model as the companies merged. This tractor was a practical and reliable workhorse that filled a vital niche in the agricultural market, providing farmers with a capable machine for a wide range of tasks.
Frequently Asked Questions
Which water pump fits the Case IH 686 tractor?
The recommended replacement water pump for the Case IH 686 is the 673162C1 - WATER PUMP.
What replacement alternator is recommended for the Case IH 686?
For the Case IH 686, a suitable replacement alternator is the 1103184 - Alternator, Delco.
What oil filter fits the 686?
For the Case IH 686, a full-flow spin-on lube filter is the LF3316 - Filter, Lube, Full-Flow Spin-On (QTY 12). Always verify fitment with your specific engine configuration.
What are common replacement parts for the Case IH 686?
Common replacement parts for the Case IH 686 include the 384006R92 - Tie Rod, Inner, 359984R93 - Tie Rod, Outer, 68803C91 - PTO Clutch Disc Kit, Consist Of:, WBKIH3 - Wheel Bearing Kit, and 391445R1 - disc, brake.

VTK310 - Valve Train Kit
SKU: VTK310
Out of stock

VTK291 - Valve Train Kit
SKU: VTK291
2 in stock

SK445 - Piston Liner Kit
SKU: SK445
2 in stock

SRK724 - Liner Sealing Ring Kit
SKU: SRK724
20 in stock

SD602 - Cylinder Liner
SKU: SD602
7 in stock

671806C1 - Tach Drive
SKU: 671806C1
65 in stock

383917R1 - Tube
SKU: 383917R1
238 in stock

374062R1 - Jam Nut
SKU: 374062R1
350 in stock

370689R21 - w/ Bushings Knee
SKU: 370689R21
59 in stock

359986R1 - Clamp
SKU: 359986R1
340 in stock

359984R1 - outer Ref 13 - Tie rod
SKU: 359984R1
415 in stock

251105R1 - Pivot Pin Retaining Pin
SKU: 251105R1
27 in stock

223313 - Complete Tie Rod Assembly
SKU: 223313
349 in stock

LM603049-I - Tapered Roller Bearing Cone
SKU: LM603049-I
336 in stock

LM603011-I - Tapered Bearing Cup
SKU: LM603011-I
94 in stock

LM48548-I - Tapered Roller Bearing Cone
SKU: LM48548-I
794 in stock

LM48510-I - Tapered Bearing Cup
SKU: LM48510-I
340 in stock

WL7610 - Trapezoid LED Light Assembly
SKU: WL7610
98 in stock

WL7606 - Flood LED Light Assembly
SKU: WL7606
92 in stock

WL3005 - Combo LED Sealed Beam
SKU: WL3005
58 in stock

WL2116 - 4 1/2" Diameter Trapezoid LED Sealed Beam
SKU: WL2116
341 in stock

WL1116 - 4 1/2" Diameter Flood LED Sealed Beam
SKU: WL1116
1157 in stock

C5NN13N359E - Warning Lamp / Turn Signal (12 Volt)
SKU: C5NN13N359E
96 in stock

A42294 - Sealed Beam Bulb (12 Volt)
SKU: A42294
340 in stock
