Case IH 5488 Tractor Parts
Case IH 5488 Tractor parts in stock. Quality OEM and aftermarket replacement parts with fast shipping and competitive prices.
The Case IH 5488, manufactured from 1985 to 1989, is a powerful and reliable agricultural tractor. Powered by a 466 cubic inch (7.6L) International Harvester DT-466 diesel engine producing approximately 185 engine horsepower, the 5488 delivered around 145 PTO horsepower. Its robust design and ample power made it a popular choice for farmers needing a versatile tractor for various field operations.
About the 5488
The Case IH 5488 was introduced in 1985 as part of the 88 series tractors, which were known for their modern styling and improved operator comfort compared to previous models. Production continued through 1989. The 5488 is equipped with an International Harvester DT-466 inline 6-cylinder turbocharged diesel engine. This engine has a displacement of 466 cubic inches (7.6 liters) and produces around 185 engine horsepower. PTO horsepower is rated at approximately 145. The transmission is a partially synchronized 18-speed forward and 9-speed reverse with torque amplifier. The PTO features both 540 and 1000 RPM options, providing versatility for different implements. The hydraulic system has a capacity of approximately 26 gallons per minute, powering three standard remote valves. The 3-point hitch is a Category II, offering a lift capacity of around 6,700 lbs. The 5488 was commonly used for row crop operations, hay production, livestock feeding, and tillage. Compared to the smaller 5288 and 5088 models, the 5488 offered more power and hydraulic capacity, making it suitable for larger implements and more demanding tasks. Its dependable engine and robust construction contributed to its enduring popularity among farmers.
5488 Specifications
| Engine | International Harvester DT-466 185 HP Diesel |
|---|---|
| PTO HP | 145 HP @ 1000 RPM |
| Transmission | Partial Powershift 18F/9R |
| Hydraulics | 26 GPM, 3 remotes |
| 3-Point Hitch | Category II, 6700 lbs |
| Fuel Capacity | 68 gallons |
| Weight | 15,200 lbs |
| Years Produced | 1985-1989 |
5488 Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 250 hours of operation using a high-quality oil that meets Case IH specifications.
- Hydraulic System: Regularly check hydraulic fluid levels and inspect for leaks. Change hydraulic filters every 500 hours to prevent contamination and maintain optimal performance.
- Fuel System: Use clean, high-quality diesel fuel and replace fuel filters according to the manufacturer's recommendations (typically every 250-500 hours). Consider using a fuel additive to prevent gelling in cold weather.
- Seasonal Storage: Before storing the tractor for extended periods, stabilize the fuel, change engine oil and filter, grease all fittings, and disconnect the battery to prevent discharge. Store the tractor in a dry location to prevent rust and corrosion.
5488 History & Background
The Case IH 5488 was released in 1985 as part of the 88 Series. These tractors represented a design shift from previous Case IH models, emphasizing operator comfort and updated styling. The 5488 became a respected workhorse on many farms throughout the late 80s and early 90s.
Frequently Asked Questions
Which water pump fits the Case IH 5488?
A reliable replacement water pump for the Case IH 5488 is 673162C1 - WATER PUMP.
What replacement PTO clutch disc kit is available for the 5488?
For maintaining your 5488's PTO system, consider the 68803C91 - PTO Clutch Disc Kit.
What oil filter fits the Case IH 5488?
For optimal engine performance in your Case IH 5488, we recommend the LF3316 - Filter, Lube, Full-Flow Spin-On lube filter.
What are common replacement parts for the Case IH 5488?
Commonly needed replacement parts for the Case IH 5488 include: 384006R92 - Tie Rod, Inner, 359984R93 - Tie Rod, Outer, 87271837 - Switch, Flasher Control, 531242R1 - Bushing, Axle Pivot, 1280600C1 - Seal, Front Pivot, and A47038 - Seal Kit, Hydrostatic Steering Hand Pump.

VTK241 - Valve Train Kit
SKU: VTK241
7 in stock

SW462 - Cylinder Liner
SKU: SW462
15 in stock

C7NN3290A - Tie Rod
SKU: C7NN3290A
30 in stock

A145857 - Tie Rod Wedge
SKU: A145857
27 in stock

86502997 - Tie Rod
SKU: 86502997
14 in stock

531260R92 - w/ Bushings Knee
SKU: 531260R92
91 in stock

44995098 - Wheel Seal
SKU: 44995098
198 in stock

39-5698 - Pivot Pin Retaining Pin
SKU: 39-5698
Out of stock

384006R1 - inner Ref 12 - Tie rod
SKU: 384006R1
499 in stock

383917R1 - Tube
SKU: 383917R1
238 in stock

374062R1 - Jam Nut
SKU: 374062R1
350 in stock

359986R1 - Clamp
SKU: 359986R1
340 in stock

359984R1 - outer Ref 13 - Tie rod
SKU: 359984R1
415 in stock

223313 - Complete Tie Rod Assembly
SKU: 223313
349 in stock

1287611C1 - Tie Rod Jam Nut
SKU: 1287611C1
15 in stock

1287610C1 - Tie Rod Jam Nut
SKU: 1287610C1
141 in stock

1280662C1 - Long; 2WD Tie Rod
SKU: 1280662C1
68 in stock

1280661C1 - Jam Nut (1-1/8" NF)
SKU: 1280661C1
14 in stock

1280658C1 - Short; 2WD Tie Rod
SKU: 1280658C1
43 in stock

1280657C1 - Tie Rod; 2WD Tube
SKU: 1280657C1
29 in stock

1277452C1 - Tie Rod
SKU: 1277452C1
30 in stock

1277451C1 - Tie Rod
SKU: 1277451C1
48 in stock

1277261C1 - Power Steering (MFWD) Cylinder End
SKU: 1277261C1
112 in stock

1259512C2 - HD Square Axle Rear Pivot Pin
SKU: 1259512C2
17 in stock
