Case IH 484 Tractor Parts

484 parts and accessories

The Case IH 484 tractor, manufactured from 1978 to 1984, was a versatile workhorse for many farms. Powered by an International Harvester diesel engine producing around 48 horsepower, it provided reliable performance for a variety of tasks. With a PTO horsepower of approximately 42, the 484 gained popularity due to its compact size, ease of use, and dependable operation.

The Case IH 484 was introduced in 1978 as part of the International Harvester and later Case IH line of utility tractors and was produced until 1984. This model features a robust International Harvester D-179 diesel engine, a 179 cubic inch (2.9L) 3-cylinder engine producing approximately 48 engine horsepower. Some early models might have a gasoline engine option. The transmission is typically an 8-speed gear transmission, offering a good range of speeds for various field tasks. The 484 boasts a PTO horsepower of around 42, with a standard 540 RPM PTO. The hydraulic system has a capacity of approximately 8 GPM, providing adequate power for implements and attachments. It's equipped with a Category I 3-point hitch, making it suitable for a variety of implements used in row crop operations, hay production, and livestock management. Its manageable size and horsepower made it ideal for tasks like mowing, baling hay, light tillage, and general farm maintenance. The 484 stands out from smaller compact tractors due to its heavier build and increased capabilities, while remaining more nimble than larger row-crop tractors.

Specifications

Engine	International Harvester D-179 48 HP Diesel
PTO HP	42 HP @ 540 RPM
Transmission	Gear, 8 Forward/4 Reverse
Hydraulics	8 GPM, 1-2 remotes
3-Point Hitch	Category I, 2500 lbs lift capacity
Fuel Capacity	16 gallons
Weight	4500 lbs
Years Produced	1978-1984

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250 hours using the recommended oil type and filter for your climate. Regularly check the oil level and top off as needed.
Hydraulic System: Inspect hydraulic hoses and fittings for leaks. Replace the hydraulic filter every 500 hours to maintain optimal hydraulic performance and prevent damage to components.
Fuel System: Use clean, high-quality fuel and add a fuel stabilizer if storing the tractor for extended periods. Drain the fuel sediment bowl regularly to remove water and contaminants.

History & Background

The Case IH 484 was introduced during a period of significant change in the agricultural industry, offering farmers a dependable and affordable tractor option. While not revolutionary in design, it represented a solid and practical machine that met the needs of many small to medium-sized farms. Its long production run and continued popularity are testaments to its enduring appeal and reliable performance.

Frequently Asked Questions

What engine is in the Case Ih 484?

The Case IH 484 is equipped with an International Harvester D-179 diesel engine, a 3-cylinder engine with a displacement of 179 cubic inches (2.9L), producing approximately 48 horsepower.

What is the PTO horsepower on a 484?

The PTO horsepower on the Case IH 484 is approximately 42 HP at a standard 540 RPM.

What oil filter fits the 484?

The Case IH 484 typically uses a Fram PH2870A or equivalent oil filter. Always consult your tractor's manual or a parts professional for the most accurate recommendation. Common cross-references include Wix 51060, Napa 1060, and AC Delco PF25.

What are common parts needed for the 484?

Common parts needed for the Case IH 484 include engine oil filters, fuel filters, air filters, hydraulic filters, radiator hoses, belts, tie rod ends, steering components, clutch discs, and PTO seals. These parts are subject to wear and tear over time and require periodic replacement to maintain optimal performance.
