Case IH 4210 Tractor Parts
Replacement parts for the Case IH 4210 Tractor. Browse our selection of OEM and aftermarket parts — filters, belts, hydraulics, electrical, and more.
The Case IH 4210 tractor, manufactured from 1994 to 1998, was a versatile workhorse for many farms. Powered by a reliable 66 HP diesel engine and offering a PTO horsepower of 57, the 4210 was known for its robust build and ability to handle a variety of tasks, from pulling implements to powering PTO-driven equipment. Its combination of power and simplicity made it a popular choice.
About the 4210
The Case IH 4210 was part of the 40 series tractor line, introduced in 1994 and produced until 1998. It was designed as a utility tractor suitable for a wide range of farming applications. The tractor is powered by a Case IH 4-cylinder diesel engine, rated at 66 horsepower with a displacement of approximately 239 cubic inches (3.9 liters). This engine provided sufficient power for various field tasks. The 4210 came standard with a mechanical transmission, typically an 8-speed forward, 2-speed reverse gear transmission providing a good range of speeds for different field conditions. The PTO horsepower is rated at 57, offering both 540 RPM PTO and optional 1000 RPM PTO for operating implements like mowers, balers, and rotary tillers. Hydraulic capacity is approximately 11.7 gallons per minute, sufficient for operating hydraulic implements. The 3-point hitch is a Category II, offering a lift capacity of around 3600 lbs. The Case IH 4210 was commonly used in row crop operations for tasks like planting and cultivating, as well as in hay production and livestock operations. It distinguished itself from smaller tractors with its increased horsepower and robust build, while remaining more compact than the larger row-crop tractors.
4210 Specifications
| Engine | Case IH 66 HP Diesel 3.9L |
|---|---|
| PTO HP | 57 HP @ 540/1000 RPM |
| Transmission | Mechanical 8 Forward, 2 Reverse |
| Hydraulics | 11.7 GPM, 2 remotes |
| 3-Point Hitch | Category II, 3600 lbs |
| Fuel Capacity | 24 gallons |
| Weight | 6,393 lbs |
| Years Produced | 1994-1998 |
4210 Maintenance Tips
- Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using the recommended oil type and a quality filter to ensure proper lubrication and cooling.
- Hydraulic System: Inspect the hydraulic fluid level regularly and change the hydraulic fluid and filter every 500 hours to prevent contamination and maintain optimal performance.
- Fuel System: Use a fuel conditioner regularly, especially during seasonal storage, to prevent fuel degradation and keep the fuel system clean. Drain any water accumulation from the fuel/water separator regularly.
- Seasonal Storage: Before storing the tractor for extended periods, fill the fuel tank to prevent condensation, disconnect the battery, and protect the tires from direct sunlight to prolong their life.
4210 History & Background
The Case IH 4210 was introduced in 1994 as part of the 40 series line, which aimed to provide farmers with reliable and versatile tractors. It did not undergo any major redesigns during its production run. This model represented a solid, mid-size utility tractor option for farmers needing a balance of power and maneuverability.
Frequently Asked Questions
Which water pump fits the Case IH 4210 tractor?
The recommended water pump for the Case IH 4210 is 3132739R94 - Water pump. This part ensures proper engine cooling performance.
What PTO clutch disc is recommended for the Case IH 4210?
For the PTO system on the Case IH 4210, the 401716R2 - Disc, PTO Clutch is a suitable replacement part.
Which right-hand ball joint is suitable for the Case IH 4210?
The 1966125C1 - Ball Joint (RH) is an appropriate replacement for the Case IH 4210's steering system.
What are some essential replacement parts for the Case IH 4210?
For maintaining your Case IH 4210, essential replacement parts include a 527658R91 - Tie Rod, Short, a 3125322R2 - Disc, Clutch Driven, and the ST553 - Bearing, Pilot (sealed). Other useful parts are the WF2071 - Filter, Water, Spin-On, an 87703630 - Lamp, Amber LED Flasher/Tail Light, and 404341R3 - Stud, Rear Wheel (10 Pk).

SK473 - Piston Liner Kit
SKU: SK473
51 in stock

ZP0750125014 - Ball Joint
SKU: ZP0750125014
71 in stock

CAR49001 - Ball Joint (RH)
SKU: CAR49001
71 in stock

9967993 - 4WD Front Axle Bushing
SKU: 9967993
43 in stock

85805975 - Steering Cylinder Ball Joint
SKU: 85805975
71 in stock

83974364 - Ball Joint (RH)
SKU: 83974364
71 in stock

83957758 - Ball Joint (RH)
SKU: 83957758
71 in stock

83957097 - Ball Joint (RH)
SKU: 83957097
71 in stock

67529C1 - Tie Rod Tube
SKU: 67529C1
248 in stock

65079C91 - Long Tie Rod
SKU: 65079C91
213 in stock

612884R1 - Hub Cap
SKU: 612884R1
46 in stock

527658R91 - Short Tie Rod
SKU: 527658R91
237 in stock

43747D - Tie Rod Clamp
SKU: 43747D
403 in stock

1966127C1 - Ball Joint (LH)
SKU: 1966127C1
13 in stock

1966125C1 - Ball Joint (RH)
SKU: 1966125C1
71 in stock

1537872C1 - Steering End
SKU: 1537872C1
23 in stock

137048A1 - Tie Rod End (RH)
SKU: 137048A1
63 in stock

137047A1 - Tie Rod End (LH)
SKU: 137047A1
9 in stock

1332805C2 - Outer Tie Rod
SKU: 1332805C2
188 in stock

112508A1 - Tie Rod
SKU: 112508A1
13 in stock

3136053R92 - Water Pump
SKU: 3136053R92
144 in stock

WL6482R - Hi / Low RH LED Headlight
SKU: WL6482R
207 in stock

WL6481L - Hi / Low LH LED Headlight
SKU: WL6481L
214 in stock

WL3405 - RH Front / LH Rear Amber LED Warning Light
SKU: WL3405
173 in stock
