Case IH 395 Tractor Parts
Shop Case IH 395 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.
The Case IH 395 tractor, manufactured from 1985 to 1987, was a popular choice for farmers seeking a reliable and versatile machine. Powered by a robust 41 horsepower diesel engine, it delivered ample power for various farm tasks. Its 35 PTO horsepower made it well-suited for operating implements like mowers, tillers, and balers, making it a valuable asset on many farms.
About the 395
The Case IH 395 was introduced in 1985 as part of the Case IH lineup following the merger of International Harvester and Case. Production continued through 1987. This tractor is powered by an International Harvester D-179 3-cylinder diesel engine producing approximately 41 horsepower. The engine has a displacement of 179 cubic inches. It was available with a gear transmission, offering 8 forward and 2 reverse speeds. The PTO delivers approximately 35 horsepower at 540 RPM. The hydraulic system has a capacity of around 7.4 gallons per minute and usually featured one or two remote valves. The 3-point hitch is a Category I, capable of lifting approximately 2400 pounds. The Case IH 395 was commonly used for tasks like mowing, light tillage, hay production, and general farm chores. It offered a good balance of power and maneuverability compared to larger models, making it a practical choice for small to medium-sized farms. It was not equipped with a hydrostatic or powershift transmission, which was a key difference from larger, more advanced models.
395 Specifications
| Engine | International Harvester D-179 41 HP Diesel |
|---|---|
| PTO HP | 35 HP @ 540 RPM |
| Transmission | Gear 8F/2R |
| Hydraulics | 7.4 GPM, 1-2 remotes |
| 3-Point Hitch | Category I, 2400 lbs |
| Fuel Capacity | 16 gallons |
| Weight | 3600 lbs |
| Years Produced | 1985-1987 |
395 Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 250 hours of operation using the recommended oil type and a quality replacement filter to ensure optimal engine lubrication and performance.
- Hydraulic System: Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours. Check for leaks around hydraulic lines and cylinders and address them promptly to maintain hydraulic system efficiency.
- Fuel System: Use clean, high-quality fuel and replace the fuel filter annually to prevent fuel system contamination. Drain any water from the fuel tank periodically to avoid corrosion and engine issues.
- Seasonal Storage: Before storing the tractor for an extended period, treat the fuel with a stabilizer, lubricate all grease fittings, and disconnect the battery to prevent corrosion and ensure a smooth start when the tractor is put back into service.
395 History & Background
The Case IH 395 emerged in 1985, marking the beginning of the Case IH brand after the merger. This model, while only produced for a few years, provided an affordable and reliable option for farmers needing a versatile utility tractor. It represents a significant moment in agricultural machinery history as it signifies the transition and evolution of two major tractor manufacturers coming together.
Frequently Asked Questions
Which water pump fits the Case IH 395?
The 3132739R94 - Water pump is a suitable replacement for the Case IH 395.
Which clutch driven disc is recommended for the Case IH 395?
A reliable replacement for the Case IH 395 is the 3125322R2 - Disc, Clutch Driven.
Which water filter is suitable for the Case IH 395?
The WF2071 - Filter, Water, Spin-On (QTY 12) is a compatible water filter for the Case IH 395.
What are common parts needed for the 395?
For the Case IH 395, frequently replaced components often include: 527658R91 - Tie Rod, Short, 65079C91 - Tie Rod, Long, 358958R1 - Bushing, Spindle, 530104R91 - Seal and 185106C1 - Bearing, Thrust.

A173180 - Muffler
SKU: A173180
11 in stock

SK445 - Piston Liner Kit
SKU: SK445
2 in stock

SRK724 - Liner Sealing Ring Kit
SKU: SRK724
20 in stock

ZP0750125014 - Ball Joint
SKU: ZP0750125014
71 in stock

CAR49001 - Ball Joint (RH)
SKU: CAR49001
71 in stock

9967993 - 4WD Front Axle Bushing
SKU: 9967993
43 in stock

85805975 - Steering Cylinder Ball Joint
SKU: 85805975
71 in stock

83974364 - Ball Joint (RH)
SKU: 83974364
71 in stock

83957758 - Ball Joint (RH)
SKU: 83957758
71 in stock

83957097 - Ball Joint (RH)
SKU: 83957097
71 in stock

67529C1 - Tie Rod Tube
SKU: 67529C1
248 in stock

66702C91 - Knee w/ Bushings (RH)
SKU: 66702C91
Out of stock

65082C91 - Long Tie Rod
SKU: 65082C91
22 in stock

65079C91 - Long Tie Rod
SKU: 65079C91
213 in stock

612884R1 - Hub Cap
SKU: 612884R1
46 in stock

530104R91 - Seal
SKU: 530104R91
881 in stock

527658R91 - Short Tie Rod
SKU: 527658R91
237 in stock

3129380R2 - Long Tie Rod
SKU: 3129380R2
9 in stock

3116408R1 - Tie Rod Tube
SKU: 3116408R1
29 in stock

1968468C1 - Ball Joint
SKU: 1968468C1
30 in stock

1968464C1 - Tie Rod
SKU: 1968464C1
20 in stock

1966127C1 - Ball Joint (LH)
SKU: 1966127C1
13 in stock

1966125C1 - Ball Joint (RH)
SKU: 1966125C1
71 in stock

1537872C1 - Steering End
SKU: 1537872C1
23 in stock
