Case IH 3588 Tractor Parts

Shop Case IH 3588 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.

The Case IH 3588, manufactured from 1981 to 1984, was a popular choice for farmers needing a reliable and versatile tractor. Powered by a robust 170 gross HP diesel engine, the 3588 delivered ample power for a variety of tasks. Its impressive PTO horsepower made it well-suited for demanding implements, contributing to its reputation for performance and dependability.

About the 3588

The Case IH 3588 was part of the System 88 series, introduced to provide farmers with more powerful and feature-rich options. Production spanned from 1981 to 1984. At its heart is the International Harvester DT-466 diesel engine, a 466 cubic inch (7.6L) inline six-cylinder powerplant, delivering approximately 170 gross horsepower. The engine's reliable design made it a favorite among operators. The 3588 typically featured a partial power shift transmission providing multiple speeds, enhancing operational flexibility. It boasts a PTO horsepower of around 145-150 HP and offered both 540 and 1000 RPM PTO options. The hydraulic system provided around 28 GPM of flow, with typically two remote valves for implement control. It came standard with a Category II 3-point hitch. Farmers frequently employed the 3588 in row crop operations, hay production, livestock management, and tillage work. It was distinguished within the IH lineup for its balance of power and features, positioning it as a step up from smaller models while remaining more economical than larger, higher-horsepower options.

3588 Specifications

EngineInternational Harvester DT-466 170 HP 466 ci Diesel
PTO HP145-150 HP @ 540/1000 RPM
TransmissionPartial Power Shift
Hydraulics28 GPM, 2 remotes
3-Point HitchCategory II, 6,374 lbs lift capacity
Fuel Capacity75 gallons
Weight15,500 lbs
Years Produced1981-1984

3588 Maintenance Tips

  • Engine Oil & Filter: Change engine oil and filter every 250 hours of operation using a high-quality diesel engine oil that meets API CI-4 or CJ-4 specifications. Regularly inspect the oil level and condition.
  • Hydraulic System: Inspect hydraulic oil levels and filter condition every 500 hours. Use the recommended hydraulic fluid and replace filters according to the manufacturer's schedule to prevent contamination and ensure optimal performance.
  • Fuel System: Regularly check and drain the fuel/water separator to remove any accumulated water or sediment. Use clean, high-quality diesel fuel and consider adding a fuel stabilizer during seasonal storage.
  • Seasonal Storage: Before storing the tractor for the off-season, perform a complete service, including changing fluids and filters, lubricating all grease points, and protecting the engine from corrosion. Disconnect the battery and store it in a cool, dry place.

3588 History & Background

The Case IH 3588 was introduced in 1981 as part of the System 88 series, representing a significant advancement in tractor technology for International Harvester. While it didn't receive major redesigns during its production run, it quickly became known for its reliable engine and versatile capabilities. Its popularity cemented its place as a noteworthy model in agricultural history during a period of transition in the farm equipment industry.

Frequently Asked Questions

Which water pump fits the Case IH 3588?

The 673162C1 - WATER PUMP is recommended for the Case IH 3588 tractor.

What PTO clutch disc kit is available for the Case IH 3588?

The 68803C91 - PTO Clutch Disc Kit, Consist Of: is a suitable replacement for the Case IH 3588.

What oil filter fits the 3588?

For the Case IH 3588, the LF3316 - Filter, Lube, Full-Flow Spin-On (QTY 12) is a recommended replacement.

What are common parts needed for the 3588?

Showing 1-24 of 312 products
VTK241 - Valve Train Kit

VTK241 - Valve Train Kit

SKU: VTK241

$356.43

7 in stock

SW462 - Cylinder Liner

SW462 - Cylinder Liner

SKU: SW462

$113.92

15 in stock

671806C1 - Tach Drive

671806C1 - Tach Drive

SKU: 671806C1

$121.75

65 in stock

WL7610 - Trapezoid LED Light Assembly

WL7610 - Trapezoid LED Light Assembly

SKU: WL7610

$102.38

98 in stock

WL7606 - Flood LED Light Assembly

WL7606 - Flood LED Light Assembly

SKU: WL7606

$102.38

92 in stock

WL2116 - 4 1/2" Diameter Trapezoid LED Sealed Beam

WL2116 - 4 1/2" Diameter Trapezoid LED Sealed Beam

SKU: WL2116

$83.35

341 in stock

WL1116 - 4 1/2" Diameter Flood LED Sealed Beam

WL1116 - 4 1/2" Diameter Flood LED Sealed Beam

SKU: WL1116

$70.46

1157 in stock

A42294 - Sealed Beam Bulb (12 Volt)

A42294 - Sealed Beam Bulb (12 Volt)

SKU: A42294

$14.49

340 in stock

87703630 - Amber LED Flasher/Tail Light Lamp

87703630 - Amber LED Flasher/Tail Light Lamp

SKU: 87703630

$61.89

88 in stock

87271837 - Flasher Control Switch

87271837 - Flasher Control Switch

SKU: 87271837

$77.54

390 in stock

388947R1 - Lamp Retainer

388947R1 - Lamp Retainer

SKU: 388947R1

$5.36

178 in stock

373662R1 - Sealed Beam Bulb (12 Volt)

373662R1 - Sealed Beam Bulb (12 Volt)

SKU: 373662R1

$11.28

246 in stock

OK218 - Major Engine Overhaul Kit

OK218 - Major Engine Overhaul Kit

SKU: OK218

$2280.13

3 in stock

IK218 - In Frame Engine Overhaul Kit

IK218 - In Frame Engine Overhaul Kit

SKU: IK218

$1700.76

7 in stock

1817247 - Piston Ring Set

1817247 - Piston Ring Set

SKU: 1817247

$73.69

25 in stock

A47038 - Hydrostatic Steering Hand Pump Seal Kit

A47038 - Hydrostatic Steering Hand Pump Seal Kit

SKU: A47038

$26.04

148 in stock

70933C91 - Hyd Main Hitch (12 GPM) Pump

70933C91 - Hyd Main Hitch (12 GPM) Pump

SKU: 70933C91

$775.78

9 in stock

70932C91 - Main Hitch (15 GPM) Pump

70932C91 - Main Hitch (15 GPM) Pump

SKU: 70932C91

$775.78

31 in stock

70931C91 - Main Hitch (12 GPM) Pump

70931C91 - Main Hitch (12 GPM) Pump

SKU: 70931C91

$775.78

24 in stock

544799R1 - Backup Washer

544799R1 - Backup Washer

SKU: 544799R1

$2.39

50 in stock

382319R1 - Drive Selector Valve Stem
Out of Stock

382319R1 - Drive Selector Valve Stem

SKU: 382319R1

$57.29

Out of stock

139027C2 - Hydraulic Auxillary Valve Flow Control Cable

139027C2 - Hydraulic Auxillary Valve Flow Control Cable

SKU: 139027C2

$16.96

46 in stock

1272964C94 - IH Remote Couplers To ISO Remote Couplers Conversion Kit

1272964C94 - IH Remote Couplers To ISO Remote Couplers Conversion Kit

SKU: 1272964C94

$279.11

243 in stock

1272196C1 - Coupler Dust Cap

1272196C1 - Coupler Dust Cap

SKU: 1272196C1

$9.96

139 in stock
