Case IH 3220 Tractor Parts
Replacement parts for the Case IH 3220 Tractor. Browse our selection of OEM and aftermarket parts — filters, belts, hydraulics, electrical, and more.
The Case IH 3220 was a popular utility tractor manufactured from 1993 to 1997, known for its reliable performance in various farming tasks. Powered by a 48 horsepower diesel engine, it provided ample power for mowing, loader work, and general field operations. Its 40 PTO horsepower made it suitable for operating a range of implements, making it a versatile choice for small to medium-sized farms.
About the 3220
The Case IH 3220 was part of the 3200 series, introduced in the early 1990s as a successor to earlier Case IH models. Production ran from 1993 to 1997. It features a Shibaura N844L diesel engine, producing approximately 48 engine horsepower with a 134 cubic inch displacement. The transmission is a mechanical gear type, typically an 8-speed forward and 8-speed reverse, providing a good range of speeds for different applications. The independent PTO delivers around 40 horsepower at 540 RPM. The hydraulic system has a capacity of around 9.8 GPM, powering the Category I 3-point hitch with a lift capacity of approximately 2425 lbs. This tractor was commonly used for row crop work, hay production (mowing, raking, baling), livestock operations (feeding, manure handling), and light tillage. It distinguishes itself with its robust design, ease of maintenance, and fuel-efficient engine, making it a reliable and economical choice for farmers.
3220 Specifications
| Engine | Shibaura N844L 48 HP Diesel |
|---|---|
| PTO HP | 40 HP @ 540 RPM |
| Transmission | Mechanical Gear 8 Forward / 8 Reverse |
| Hydraulics | 9.8 GPM, 2 remotes |
| 3-Point Hitch | Category I, 2425 lbs |
| Fuel Capacity | 13.2 gallons |
| Weight | 3700 lbs |
| Years Produced | 1993-1997 |
3220 Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 250 hours using a high-quality diesel engine oil and a compatible filter. Regularly check the oil level.
- Hydraulic System: Inspect hydraulic fluid levels and change the hydraulic filter every 500 hours. Use the recommended hydraulic fluid to prevent damage to seals and components.
- Fuel System: Use clean fuel and replace the fuel filter every 250 hours. Drain any water accumulation from the fuel tank regularly to prevent fuel system issues.
- Seasonal Storage: Before storing the tractor for an extended period, fill the fuel tank to prevent condensation, change engine oil, and grease all lubrication points. Disconnect the battery and store it in a cool, dry place.
3220 History & Background
The Case IH 3220 was introduced in 1993 as part of a refresh to Case IH's utility tractor lineup. There were no major redesigns during its production run from 1993 to 1997. It provided a balance of power and economy, cementing its place as a reliable workhorse on farms across the country.
Frequently Asked Questions
Which water pump fits the Case IH 3220 tractor?
For the Case IH 3220 tractor, the recommended replacement water pump is 3132739R94 - Water pump.
What PTO clutch disc is recommended for the Case IH 3220?
A suitable PTO clutch disc for the Case IH 3220 is 401716R2 - Disc, PTO Clutch.
Which front wheel rim is suitable for the Case IH 3220?
For the Case IH 3220, a suitable front wheel rim is A38404 - Rim, Front Wheel 5.5" X 16".
What are some common replacement parts for the Case IH 3220?
For the Case IH 3220, common replacement parts include the ST553 - Bearing, Pilot (sealed), 3107556R1 - Switch w/ 2 Keys, Ignition, 65079C91 - Tie Rod, Long, 3125322R2 - Disc, Clutch Driven, 1500626C92 - Cap, Radiator w/ Cover (10 lb.), and the WL6481L - Headlight, LED, LH, Hi / Low.

SK473 - Piston Liner Kit
SKU: SK473
51 in stock

ZP0750125014 - Ball Joint
SKU: ZP0750125014
71 in stock

CAR49001 - Ball Joint (RH)
SKU: CAR49001
71 in stock

9967993 - 4WD Front Axle Bushing
SKU: 9967993
43 in stock

85805975 - Steering Cylinder Ball Joint
SKU: 85805975
71 in stock

83974364 - Ball Joint (RH)
SKU: 83974364
71 in stock

83957758 - Ball Joint (RH)
SKU: 83957758
71 in stock

83957097 - Ball Joint (RH)
SKU: 83957097
71 in stock

65079C91 - Long Tie Rod
SKU: 65079C91
213 in stock

612884R1 - Hub Cap
SKU: 612884R1
46 in stock

1966127C1 - Ball Joint (LH)
SKU: 1966127C1
13 in stock

1966125C1 - Ball Joint (RH)
SKU: 1966125C1
71 in stock

1537872C1 - Steering End
SKU: 1537872C1
23 in stock

137048A1 - Tie Rod End (RH)
SKU: 137048A1
63 in stock

137047A1 - Tie Rod End (LH)
SKU: 137047A1
9 in stock

1332805C2 - Outer Tie Rod
SKU: 1332805C2
188 in stock

112508A1 - Tie Rod
SKU: 112508A1
13 in stock

3136053R92 - Water Pump
SKU: 3136053R92
144 in stock

WL6482R - Hi / Low RH LED Headlight
SKU: WL6482R
207 in stock

WL6481L - Hi / Low LH LED Headlight
SKU: WL6481L
214 in stock

WL3405 - RH Front / LH Rear Amber LED Warning Light
SKU: WL3405
173 in stock

WL3404 - LH Front / RH Rear Amber LED Warning Light
SKU: WL3404
165 in stock

D71346 - Bulb
SKU: D71346
497 in stock

C5NN13N359E - Warning Lamp / Turn Signal (12 Volt)
SKU: C5NN13N359E
96 in stock
