Case IH 2390 Tractor Parts
Shop Case IH 2390 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.
The Case IH 2390 tractor, manufactured from 1978 to 1981, was a popular choice for farmers needing reliable power. Powered by a 160 horsepower diesel engine and boasting a robust PTO, the 2390 provided the muscle needed for a variety of agricultural tasks. Its comfortable cab and dependable performance made it a workhorse on many farms.
About the 2390
The Case IH 2390 was introduced in 1978 as part of the updated '90 Series' tractor lineup from International Harvester, later Case IH. Production continued through 1981. It features the International Harvester DT-414 6.8L (414 cu in) diesel engine, producing approximately 160 engine horsepower and 135 PTO horsepower. This reliable engine was known for its durability and torque. The 2390 came equipped with a gear-type transmission, offering 8 forward and 4 reverse speeds. The PTO was available in both 540 and 1000 RPM configurations, making it adaptable to various implements. Hydraulic capacity was around 26 GPM, with typically two remote valves. It featured a Category II 3-point hitch. Common applications included row crop work, hay baling, livestock feeding operations, and medium-duty tillage. Compared to smaller models in the lineup, the 2390 offered significantly more power and hydraulic capacity, allowing it to handle larger implements and more demanding tasks. It was considered a versatile and reliable tractor for its time.
2390 Specifications
| Engine | International Harvester DT-414 160 HP 414 ci Diesel |
|---|---|
| PTO HP | 135 HP @ 540/1000 RPM |
| Transmission | Gear Type 8F/4R |
| Hydraulics | 26 GPM, 2 remotes |
| 3-Point Hitch | Category II, 5400 lbs lift capacity |
| Fuel Capacity | 62 gallons |
| Weight | 13,465 lbs |
| Years Produced | 1978-1981 |
2390 Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 250 hours using API CI-4 or newer oil and a quality filter.
- Hydraulic System: Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours. Use only Case IH Hy-Tran fluid or equivalent.
- Fuel System: Use clean, high-quality diesel fuel. Drain water from the fuel filter/water separator regularly to prevent injector damage.
- Seasonal Storage: Before storing for the winter, fill the fuel tank to prevent condensation, change engine oil and filter, grease all fittings, and disconnect the battery.
2390 History & Background
The Case IH 2390 was launched in 1978 as part of the International Harvester / Case IH '90 Series'. It represented a significant step up in power and capability compared to previous models. The 2390, with its reliable engine and versatile PTO, became a popular tractor, contributing to the productivity of farms across the United States and Canada.
Frequently Asked Questions
Which alternator is compatible with the Case IH 2390?
The A46938 - Alternator, Delco is designed to be compatible with the Case IH 2390 tractor.
What PTO clutch friction plate fits the Case IH 2390?
For the Case IH 2390, the 1981228C1 - Plate, PTO Clutch Friction is a suitable replacement.
Which water filter is recommended for the Case IH 2390?
The WF2071 - Filter, Water, Spin-On (QTY 12) is a suitable water filter for the Case IH 2390.
What are some common replacement parts for the Case IH 2390?
Regularly needed replacement parts for the Case IH 2390 include a A47038 - Seal Kit, Hydrostatic Steering Hand Pump, 1981280C1 - Clutch Plate, Sintered, 87271837 - Switch, Flasher Control, D71346 - Bulb, and a WBKCA3 - Wheel Bearing Kit.

A147100 - Muffler
SKU: A147100
21 in stock

SRK720 - 2 Oring Liner Sealing Ring Kit
SKU: SRK720
4 in stock

SK416 - Piston Liner Kit
SKU: SK416
24 in stock

SRK722 - 3 Oring Liner Sealing Ring Kit
SKU: SRK722
2 in stock

SK424 - Piston Liner Kit
SKU: SK424
27 in stock

WBKCA3 - Wheel Bearing Kit
SKU: WBKCA3
57 in stock

F22580 - CASE-IH
SKU: F22580
114 in stock

B93222 - Wheel Bearing Kit
SKU: B93222
18 in stock

A160200 - Short Tie Rod End
SKU: A160200
23 in stock

A160197 - Long Tie Rod End
SKU: A160197
60 in stock

A149033 - Tie Rod Tube
SKU: A149033
33 in stock

A145857 - Tie Rod Wedge
SKU: A145857
27 in stock

A145846 - Spacer
SKU: A145846
167 in stock

A143876 - Tie Rod End (LH)
SKU: A143876
11 in stock

112204 - Tie Rod Assembly
SKU: 112204
2 in stock

199352A1 - Water Pump
SKU: 199352A1
146 in stock

LM603049-I - Tapered Roller Bearing Cone
SKU: LM603049-I
336 in stock

LM603011-I - Tapered Bearing Cup
SKU: LM603011-I
94 in stock

WL7610 - Trapezoid LED Light Assembly
SKU: WL7610
98 in stock

WL7606 - Flood LED Light Assembly
SKU: WL7606
92 in stock

WL1300 - Rectangle Hi / Low Flood / Spot Combo LED Work Lamp
SKU: WL1300
243 in stock

WL1295 - Rectangle Flood / Spot Combo LED Work Lamp
SKU: WL1295
Out of stock

D71346 - Bulb
SKU: D71346
497 in stock

A42294 - Sealed Beam Bulb (12 Volt)
SKU: A42294
340 in stock
