Massey Ferguson 3070 Tractor Parts

3070 parts and accessories

The Massey Ferguson 3070, produced from 1987 to 1997, was a popular choice for farmers due to its robust design and versatility. Powered by a Perkins 1004.4T 78 HP diesel engine, this tractor delivered reliable performance across various tasks. It offered a PTO horsepower of around 68, making it suitable for a wide range of implements.

The Massey Ferguson 3070 was introduced in 1987 as part of the 3000 series, designed to offer enhanced performance and comfort compared to previous models. It was manufactured until 1997. The tractor is equipped with a Perkins 1004.4T four-cylinder turbocharged diesel engine, producing approximately 78 horsepower. The engine displacement is 244 cubic inches (4.0 liters). Transmission options included a synchro-mesh gearbox with 12 forward and 4 reverse gears. The independent PTO delivers around 68 horsepower, with options for 540 or 1000 RPM. The hydraulic system has a capacity of approximately 15.9 GPM, with multiple remote valves available. It featured a Category II three-point hitch with a lift capacity around 5,732 lbs. Common farming applications for the 3070 included row crop work, hay production, livestock operations, and light tillage. It distinguished itself from other models in the lineup through its balance of power, features, and user-friendly design, providing a reliable and efficient workhorse for various agricultural tasks.

Specifications

Engine	Perkins 1004.4T 78 HP Diesel
PTO HP	68 HP @ 540/1000 RPM
Transmission	Synchro-mesh 12F/4R
Hydraulics	15.9 GPM, 2-3 remotes
3-Point Hitch	Category II, 5732 lbs
Fuel Capacity	26.4 gallons
Weight	9,000 lbs
Years Produced	1987-1997

Maintenance Tips

Change engine oil and filter every 250 hours using a high-quality oil that meets the manufacturer's specifications for diesel engines.
Regularly inspect and clean the hydraulic system filters to prevent contamination and maintain optimal hydraulic performance. Change hydraulic fluid per manufacturer's recommendations.
Use clean, high-quality fuel and replace the fuel filter at least annually to prevent fuel system issues. Consider adding a fuel stabilizer when storing the tractor for extended periods.
Before seasonal storage, thoroughly inspect all fluid levels, grease all fittings, and protect tires from direct sunlight to prevent dry rot.

History & Background

The Massey Ferguson 3070 was launched in 1987 as part of the 3000 series, which aimed to update the brand's offerings with improved ergonomics and performance. While there weren't major redesigns during its production run, ongoing refinements ensured its competitiveness. The 3070 contributed to Massey Ferguson's reputation for building dependable and versatile tractors.

Frequently Asked Questions

What engine is in the Massey Ferguson 3070?

The Massey Ferguson 3070 is powered by a Perkins 1004.4T four-cylinder turbocharged diesel engine producing approximately 78 horsepower.

What is the PTO horsepower on a 3070?

The Massey Ferguson 3070 has a PTO horsepower rating of approximately 68 HP, with options for both 540 and 1000 RPM.

What oil filter fits the 3070?

Common oil filter cross-references for the Massey Ferguson 3070 include Baldwin B1421, Fram PH3614, and Wix 51068. Always verify the correct part number with your parts supplier.

What are common parts needed for the 3070?

Common wear parts for the Massey Ferguson 3070 include oil filters, fuel filters, hydraulic filters, fan belts, hydraulic pump seals, steering cylinder repair kits, clutch discs, and brake pads.
