John Deere 2510 Tractor Parts
Shop John Deere 2510 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.
The John Deere 2510 tractor, manufactured between 1965 and 1967, was a popular utility tractor known for its reliability. Powered by a 45 horsepower engine, available in both gasoline and diesel configurations, this tractor delivered around 40 PTO horsepower, making it a versatile workhorse for various farming tasks. Its user-friendly design and dependable performance solidified its place in the fields.
About the 2510
The John Deere 2510 was introduced in 1965 as part of John Deere's New Generation tractor lineup, replacing earlier models and offering improved performance and features. Production continued through 1967. The tractor was available with either a John Deere-built 3.7L (227 cu in) four-cylinder gasoline engine producing around 45 horsepower or a John Deere-built 3.0L (180 cu in) three-cylinder diesel engine also rated at approximately 45 horsepower. It featured a Synchro-Range transmission with 8 forward and 2 reverse gears, offering a range of speeds suitable for different field operations. The 2510's PTO delivered around 40 horsepower at 540 RPM. Hydraulic capacity was rated around 12.5 GPM, and it typically had two remote valves. It featured a Category I 3-point hitch, providing a lift capacity of approximately 2,500 lbs. The 2510 was commonly used for row crop work, haying, livestock operations, and light tillage. Distinguishing itself from smaller models, the 2510 offered more power and hydraulic capacity, while remaining compact and maneuverable compared to larger John Deere tractors of the time.
2510 Specifications
| Engine | John Deere 45 HP Gasoline or Diesel |
|---|---|
| PTO HP | 40 HP @ 540 RPM |
| Transmission | Synchro-Range 8F/2R |
| Hydraulics | 12.5 GPM, 2 remotes |
| 3-Point Hitch | Category I, 2500 lbs |
| Fuel Capacity | 16 gallons |
| Weight | 4140 lbs |
| Years Produced | 1965-1967 |
2510 Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 125 hours of operation, using a high-quality oil appropriate for the engine type (gasoline or diesel) and climate.
- Hydraulic System: Regularly inspect hydraulic fluid levels and check for leaks. Replace hydraulic filters as recommended (typically every 500 hours) to maintain optimal performance.
- Fuel System: Use clean, fresh fuel and add a fuel stabilizer when storing the tractor for extended periods. Inspect fuel lines and filters regularly.
- Seasonal Storage: Before storing the tractor for the winter, drain the fuel tank or add a fuel stabilizer, change the engine oil and filter, grease all fittings, and protect tires from direct sunlight.
2510 History & Background
The John Deere 2510 was launched in 1965 as part of the New Generation series, marking a significant advancement in tractor technology for John Deere. It was a popular utility tractor, highly regarded for its versatility and reliability. No major redesigns occurred during its short production run, solidifying its place as a capable and efficient machine for farmers.
Frequently Asked Questions
Which fuel lift pump fits the John Deere 2510?
For the John Deere 2510, the recommended fuel lift pump is RE27667 - Pump, Fuel Lift Transfer.
What brake pads are suitable for the John Deere 2510?
Metallic brake pads suitable for the John Deere 2510 are available as R111122 - Brake Pads, Metallic.
What fuel filter is recommended for the John Deere 2510 diesel engine?
For the diesel engine of the John Deere 2510, a suitable fuel filter is AT17387 - Filter, Diesel Fuel.
What are common replacement parts for the John Deere 2510?
Common replacement parts for the John Deere 2510 include the T20006 - Gasket, Exhaust Manifold, RE36170 - Disc, Transmission Drive Shaft Assembly, AR89564 - Injector, Pencil, AR26616 - Seal, JD16 - Wheel Bolt (9/16"), and R34733 - O-Ring, (25/Pack).

VTK4591-3 - Valve Train Kit (.003")
SKU: VTK4591-3
1 in stock

VTK4591 - Valve Train Kit (Std)
SKU: VTK4591
9 in stock

VTK4481 - Valve Train Kit (Std)
SKU: VTK4481
1 in stock

VTK180 - Valve Train Kit (Std)
SKU: VTK180
5 in stock

T526T - Connecting Rod Bushing
SKU: T526T
7 in stock

T32343 - Cylinder Liner
SKU: T32343
21 in stock

T32340 - Cylinder Liner
SKU: T32340
7 in stock

T26321 - Lower Bushing
SKU: T26321
69 in stock

T25467 - Exhaust Valve
SKU: T25467
27 in stock

T25466 - Intake Valve
SKU: T25466
18 in stock

T23482 - Piston Pin
SKU: T23482
12 in stock

T23481 - Piston
SKU: T23481
26 in stock

T23471 - Connecting Rod Bushing
SKU: T23471
326 in stock

T20298 - Oil Pump Drive Gear
SKU: T20298
2 in stock

T20215 - Thermostat Housing (5 pack) Gasket
SKU: T20215
86 in stock

RE27667 - Fuel Lift Transfer Pump
SKU: RE27667
2834 in stock

RE27348 - Connecting Rod (Std) Bearing
SKU: RE27348
1575 in stock

T20249 - Exhaust Manifold
SKU: T20249
20 in stock

T20219 - Housing to Block Thermostat Gasket
SKU: T20219
20 in stock

T20129 - Valve Stem Cap
SKU: T20129
155 in stock

T20094 - Crankshaft Gear
SKU: T20094
5 in stock

T20077 - Valve Keeper
SKU: T20077
1248 in stock

T20075 - Rocker Cover Gasket
SKU: T20075
52 in stock

T20073 - Camshaft Follower
SKU: T20073
131 in stock
