John Deere 1520 Tractor Parts
Shop John Deere 1520 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.
The John Deere 1520 tractor, manufactured from 1973 to 1975, was a popular utility tractor renowned for its reliability and versatility. Powered by a 36 horsepower diesel engine, it provided ample power for various farm tasks. Its PTO horsepower of 31.5 made it well-suited for operating implements like mowers and tillers, making it a valuable asset for farmers of all sizes.
About the 1520
The John Deere 1520 was introduced in 1973 as a part of John Deere's utility tractor lineup, filling a crucial niche for smaller farms and diverse agricultural applications. Production continued until 1975. This model was equipped with a Yanmar 3T80 diesel engine, a 101.7 cubic inch (1.7L) three-cylinder engine producing approximately 36 horsepower. The transmission was typically a gear-type transmission with 8 forward and 2 reverse speeds, offering a good range for different tasks. The PTO delivered 31.5 horsepower, typically operating at 540 RPM. The hydraulic system had a capacity of around 6.3 GPM, providing adequate power for implements. It featured a Category I 3-point hitch, capable of lifting around 1800 lbs. The 1520 was commonly used for tasks like mowing, light tillage, haying operations, and general utility work around livestock farms. Compared to larger models like the 2030 or 3020, the 1520 offered a more compact size and lower operating costs, making it an attractive option for small-scale farming and hobby farms.
1520 Specifications
| Engine | Yanmar 3T80 36 HP Diesel |
|---|---|
| PTO HP | 31.5 HP @ 540 RPM |
| Transmission | Gear, 8 forward and 2 reverse |
| Hydraulics | 6.3 GPM, 2 remotes (optional) |
| 3-Point Hitch | Category I, 1800 lbs lift capacity |
| Fuel Capacity | 12.5 gallons |
| Weight | 2870 lbs |
| Years Produced | 1973-1975 |
1520 Maintenance Tips
- Engine Oil & Filter: Change the engine oil and filter every 200-250 hours of operation using an oil that meets John Deere specifications. Regular oil changes are crucial for engine longevity.
- Hydraulic System: Inspect hydraulic fluid levels and check for leaks regularly. Replace hydraulic filters according to the manufacturer's recommendations (typically every 500 hours) to prevent contamination and maintain hydraulic performance.
- Fuel System: Use clean, high-quality diesel fuel. Drain the fuel sediment bowl regularly to remove water and contaminants that can damage the fuel injection system. Consider using a fuel additive for seasonal storage to prevent fuel degradation.
1520 History & Background
The John Deere 1520 was released in 1973, aiming to provide a compact and economical tractor option. It offered a blend of power and maneuverability suited for smaller farms. While it had a relatively short production run, the 1520 remains a testament to John Deere's commitment to meeting the diverse needs of agricultural operations.
Frequently Asked Questions
Which fuel lift pump fits the John Deere 1520?
For the John Deere 1520, the recommended fuel lift transfer pump is RE27667 - Pump, Fuel Lift Transfer.
Which PTO clutch disc is suitable for the John Deere 1520?
The appropriate PTO clutch disc for the John Deere 1520 is AR108105 - Disc, PTO Clutch.
Which diesel fuel filter is recommended for the John Deere 1520?
For the John Deere 1520, a suitable diesel fuel filter is AR50041 - Filter, Diesel Fuel.
What are some commonly replaced wear parts for the John Deere 1520?
For routine maintenance and common replacements on the John Deere 1520, consider the T20006 - Gasket, Exhaust Manifold, RE27348 - Bearing, Connecting Rod (Std), AR89564 - Injector, Pencil, AT20703 - Seal, Rear Axle Shaft, T23118 - Bushing, Center Steering Arm, and R34733 - O-Ring, (25/Pack).

VTK3481-3 - Valve Train Kit (.003")
SKU: VTK3481-3
1 in stock

VTK3481-15 - Valve Train Kit (.015")
SKU: VTK3481-15
2 in stock

VTK3481 - Valve Train Kit (Std)
SKU: VTK3481
2 in stock

TY22423 - Bulk Engine Oil Cooler Hose
SKU: TY22423
40 in stock

T32343 - Cylinder Liner
SKU: T32343
21 in stock

T26321 - Lower Bushing
SKU: T26321
69 in stock

T24534 - Pan Gasket
SKU: T24534
36 in stock

T23471 - Connecting Rod Bushing
SKU: T23471
326 in stock

T23263 - Dry Air Cleaner Valve
SKU: T23263
48 in stock

T20298 - Oil Pump Drive Gear
SKU: T20298
2 in stock

T20252 - Exhaust Manifold
SKU: T20252
38 in stock

T20215 - Thermostat Housing (5 pack) Gasket
SKU: T20215
86 in stock

RE27667 - Fuel Lift Transfer Pump
SKU: RE27667
2834 in stock

RE27348 - Connecting Rod (Std) Bearing
SKU: RE27348
1575 in stock

T20219 - Housing to Block Thermostat Gasket
SKU: T20219
20 in stock

T20129 - Valve Stem Cap
SKU: T20129
155 in stock

T20094 - Crankshaft Gear
SKU: T20094
5 in stock

T20077 - Valve Keeper
SKU: T20077
1248 in stock

T20073 - Camshaft Follower
SKU: T20073
131 in stock

T20070 - Camshaft Gear
SKU: T20070
13 in stock

T20034 - Upper Bushing
SKU: T20034
21 in stock

T20006 - Exhaust Manifold Gasket
SKU: T20006
834 in stock

T19854 - O-ring
SKU: T19854
246 in stock

T13213 - Oil Plug (10 pk) Gasket
SKU: T13213
112 in stock
