John Deere 8220 Tractor Parts

John Deere 8220 Tractor parts in stock. Quality OEM and aftermarket replacement parts with fast shipping and competitive prices.

The John Deere 8220 tractor, manufactured from 2002 to 2005, was a workhorse on farms across the country. Powered by a John Deere PowerTech 8.1L diesel engine producing around 200 engine HP and approximately 170 PTO HP, it delivered reliable performance. Its robust design and comfortable cab made it a popular choice for demanding farming tasks.

About the 8220

The John Deere 8220 was part of the 20 Series tractors introduced in 2002, replacing the previous 10 Series. This model was produced until 2005 and featured several improvements over its predecessors, including enhanced hydraulics and operator comfort. The heart of the 8220 is a John Deere PowerTech 8.1L 6-cylinder turbocharged diesel engine, generating approximately 200 engine horsepower. The engine displacement is 496 cubic inches. The transmission options included a PowrQuad transmission with 16 forward and 16 reverse gears or an optional AutoQuad transmission. The PTO delivered about 170 HP with both 540 and 1000 RPM options. The hydraulic system had a capacity of around 41 gallons per minute, with up to four rear remotes available. It featured a Category III 3-point hitch, providing a lift capacity of approximately 9,700 lbs. The 8220 was commonly used for row crop work, tillage operations, hay production, and livestock management. Compared to other models in the lineup, the 8220 offered a good balance of power, features, and price, making it a versatile option for many farming operations.

8220 Specifications

EngineJohn Deere PowerTech 200 HP 8.1L Diesel
PTO HP170 HP @ 540/1000 RPM
TransmissionPowrQuad/AutoQuad 16F/16R
Hydraulics41 GPM, 4 remotes
3-Point HitchCategory III, 9700 lbs
Fuel Capacity95 gallons
Weight16,755 lbs
Years Produced2002-2005

8220 Maintenance Tips

  • Engine Oil & Filter: Change the engine oil and filter every 250-300 hours using high-quality oil meeting John Deere specifications. Regularly inspect the oil level and condition.
  • Hydraulic System: Check the hydraulic fluid level regularly and change the hydraulic filters every 500 hours. Use only John Deere Hy-Gard or equivalent hydraulic fluid.
  • Fuel System: Use clean, high-quality diesel fuel and replace the fuel filters according to the manufacturer's recommendations (typically every 500 hours). Drain any water accumulation from the fuel/water separator.
  • Seasonal Storage: Before storing the tractor for the off-season, fill the fuel tank to prevent condensation, change the engine oil and filter, grease all fittings, and disconnect the battery. Store the tractor in a dry, sheltered location.

8220 History & Background

The John Deere 8220 was launched in 2002 as part of the 20 Series tractors, marking a significant upgrade in engine technology and operator comfort. This series represented John Deere's commitment to providing farmers with reliable and efficient machines. While the core design remained consistent throughout its production run, minor improvements were incorporated based on customer feedback.

Frequently Asked Questions

Which ignition switch fits the John Deere 8220?

The recommended ignition switch for the John Deere 8220 is RE61717 - Switch; Ignition.

What replacement mirror head is recommended for the John Deere 8220?

For the John Deere 8220, we recommend the AL78021 - Mirror Head; LH/RH Outer Rear View.

What oil filter fits the John Deere 8220?

For optimal performance, the RE509672 - Filter, Lube, Cartridge is recommended for the John Deere 8220.

Showing 1-24 of 388 products
RE64509 - High Compression Piston Piston Liner Kit

RE64509 - High Compression Piston Piston Liner Kit

SKU: RE64509

$407.75

60 in stock

RE520036 - Rear Crankshaft Seal

RE520036 - Rear Crankshaft Seal

SKU: RE520036

$39.33

236 in stock

T20129 - Valve Stem Cap

T20129 - Valve Stem Cap

SKU: T20129

$5.13

155 in stock

T20077 - Valve Keeper

T20077 - Valve Keeper

SKU: T20077

$0.64

1248 in stock

RE62777 - Exhaust Manifold; Outer (2/Pack) Gasket

RE62777 - Exhaust Manifold; Outer (2/Pack) Gasket

SKU: RE62777

$4.56

896 in stock

RE62776 - Exhaust Manifold; Inner Gasket

RE62776 - Exhaust Manifold; Inner Gasket

SKU: RE62776

$3.43

1106 in stock

RE61812 - Air Intake Temperature Sensor

RE61812 - Air Intake Temperature Sensor

SKU: RE61812

$23.35

138 in stock

RE61253 - Std. Thrust Washer Set

RE61253 - Std. Thrust Washer Set

SKU: RE61253

$69.76

10 in stock

RE57604 - Dual; Heavy Duty Torsional Damper
Out of Stock

RE57604 - Dual; Heavy Duty Torsional Damper

SKU: RE57604

$339.69

Out of stock

RE57603 - Torsional Damper
Out of Stock

RE57603 - Torsional Damper

SKU: RE57603

$256.57

Out of stock

RE57054 - Camshaft W/ Tappets

RE57054 - Camshaft W/ Tappets

SKU: RE57054

$693.28

30 in stock

RE55475 - Head Gasket

RE55475 - Head Gasket

SKU: RE55475

$86.33

43 in stock

RE542461 - Exhaust Manifold Pressure Sensor

RE542461 - Exhaust Manifold Pressure Sensor

SKU: RE542461

$65.72

243 in stock

RE537635 - Manifold Air Temperature Sensor

RE537635 - Manifold Air Temperature Sensor

SKU: RE537635

$49.15

130 in stock

RE535300 - Crankshaft

RE535300 - Crankshaft

SKU: RE535300

$3822.74

10 in stock

RE534314 - Crankshaft

RE534314 - Crankshaft

SKU: RE534314

$4249.97

10 in stock

RE534183 - .011 Undersize Thrust Bearing
Out of Stock

RE534183 - .011 Undersize Thrust Bearing

SKU: RE534183

$96.56

Out of stock

RE534181 - .011 Undersize Main Bearing

RE534181 - .011 Undersize Main Bearing

SKU: RE534181

$38.15

16 in stock

RE529320 - Std. Thrust Bearing

RE529320 - Std. Thrust Bearing

SKU: RE529320

$70.15

440 in stock

RE529319 - Std. Main Bearing

RE529319 - Std. Main Bearing

SKU: RE529319

$29.18

4392 in stock

RE528402 - Upper Gasket Set

RE528402 - Upper Gasket Set

SKU: RE528402

$452.90

4 in stock

RE528400 - O/H Gasket Set

RE528400 - O/H Gasket Set

SKU: RE528400

$658.56

18 in stock

RE527551 - Complete Overhaul Gasket Set

RE527551 - Complete Overhaul Gasket Set

SKU: RE527551

$756.89

10 in stock

RE527550 - Head Gasket Set

RE527550 - Head Gasket Set

SKU: RE527550

$321.82

7 in stock
