John Deere 5220 Tractor Parts

5220 parts and accessories

The John Deere 5220 tractor, manufactured from 2001 to 2004, was a popular choice for farmers needing a reliable utility tractor. Powered by a 65 HP diesel engine and offering around 54 PTO horsepower, the 5220 provided ample power for a variety of tasks. Its versatility and dependable performance made it a mainstay on many farms.

The John Deere 5220 was part of the John Deere 5000 Twenty Series, produced from 2001 to 2004. This series offered enhanced features compared to its predecessors. The 5220 is equipped with a John Deere PowerTech 3029D 2.9L 3-cylinder diesel engine, producing approximately 65 engine horsepower. Its displacement is around 179 cubic inches. Transmission options included a 9-speed SyncroPlus transmission with synchronized shifting or a 9-speed PowrReverser transmission offering clutchless directional changes. The tractor's PTO delivers around 54 horsepower at 540 RPM. Hydraulic capacity is about 12.7 GPM, typically supporting two remote valves. The 5220 features a Category II 3-point hitch, capable of lifting approximately 3200 lbs. Common applications included hay baling, loader work, operating implements in row crops, and general livestock operations. The 5220 stands out due to its comfortable operator station, improved hydraulic performance, and reliable engine, providing a modern feature set in the utility tractor segment.

Specifications

Engine	John Deere PowerTech 3029D 65 HP Diesel
PTO HP	54 HP @ 540 RPM
Transmission	9-Speed SyncroPlus/PowrReverser
Hydraulics	12.7 GPM, 2 remotes
3-Point Hitch	Category II, 3200 lbs
Fuel Capacity	25.1 gallons
Weight	5622 lbs
Years Produced	2001-2004

Maintenance Tips

Change engine oil and filter every 250 hours using high-quality oil that meets John Deere specifications.
Inspect and clean the hydraulic fluid filter and check the hydraulic fluid level regularly, replacing fluid every 1000 hours or as recommended by John Deere.
Use fresh, clean fuel and add a fuel stabilizer if the tractor will be stored for an extended period to prevent fuel degradation and injector clogging.
Before winter storage, drain the fuel system or add a fuel stabilizer, lubricate all grease fittings, and disconnect the battery to prevent damage from freezing or corrosion.

History & Background

The John Deere 5220 was introduced in 2001 as part of the 5000 Twenty Series, aiming to improve upon previous models with better ergonomics and performance. It represented a significant step forward in utility tractor design for John Deere, offering features previously found on larger tractors. This model remains a popular choice in the used tractor market due to its robust build and versatile capabilities.

Frequently Asked Questions

What engine is in the John Deere 5220?

The John Deere 5220 is powered by a John Deere PowerTech 3029D 2.9L 3-cylinder diesel engine, producing approximately 65 horsepower.

What is the PTO horsepower on a 5220?

The PTO horsepower rating for the John Deere 5220 is approximately 54 horsepower, operating at 540 RPM.

What oil filter fits the 5220?

The recommended oil filter for the John Deere 5220 is typically a John Deere filter part number RE504836. Common cross-references include Wix 51348 and Fram PH6022.

What are common parts needed for the 5220?

Common wear parts for the John Deere 5220 include engine oil filters, fuel filters, air filters, hydraulic filters, fan belts, radiator hoses, hydraulic seals, steering components (tie rod ends), and clutch components (clutch disc, pressure plate).

Showing 1-24 of 327 products

Sort by:
