John Deere 4230 Tractor Parts

Find parts for your John Deere 4230 Tractor. We stock OEM and quality aftermarket replacements ready to ship.

The John Deere 4230, manufactured from 1973 to 1977, was a popular choice for farmers seeking a reliable and versatile tractor. Powered by a robust 80-horsepower diesel engine, the 4230 delivered ample power for various farming tasks. Its PTO horsepower of around 70 made it well-suited for operating implements like mowers, balers, and rotary cutters.

About the 4230

The John Deere 4230 was introduced in 1973 as part of the '30 Series' tractors, replacing the earlier 4020. Production continued through 1977. The heart of the 4230 is a John Deere 404 CID (6.6L) 4-cylinder diesel engine producing approximately 80 horsepower. A gasoline version was also available, but far less common. The tractor features a Syncro Range transmission with 8 forward and 2 reverse gears, providing a good range of speeds for various field operations. PTO horsepower is rated at approximately 70 HP at 540 RPM, with an optional 1000 RPM PTO available. The hydraulic system delivers around 25 GPM and typically includes two remote valves for implement control. The 3-point hitch is a Category II, capable of lifting around 4,700 lbs. The 4230 was commonly used for row crop work, hay production, livestock operations, and tillage. What set it apart from smaller models in the lineup was its increased power and hydraulic capacity, while remaining more compact and maneuverable than larger frame tractors.

4230 Specifications

EngineJohn Deere 404 CID (6.6L) 80 HP Diesel
PTO HP70 HP @ 540 RPM
TransmissionSyncro Range 8 Forward, 2 Reverse
Hydraulics25 GPM, 2 remotes
3-Point HitchCategory II, 4700 lbs lift capacity
Fuel Capacity28 gallons
Weight8,250 lbs
Years Produced1973-1977

4230 Maintenance Tips

  • Engine Oil & Filter: Change engine oil and filter every 250 hours using the recommended John Deere oil specification. Regularly inspect the oil level and condition.
  • Hydraulic System: Check hydraulic oil levels and inspect for leaks. Replace hydraulic filters every 500 hours to maintain system performance and prevent damage.
  • Fuel System: Use clean, high-quality diesel fuel and replace the fuel filter every 250 hours. Drain the fuel/water separator regularly to prevent water contamination.
  • Seasonal Storage: Before storing the tractor for extended periods, drain the fuel tank, add fuel stabilizer, and lubricate all grease fittings. Disconnect the battery and store it in a cool, dry place.

4230 History & Background

The John Deere 4230 was introduced in 1973 as part of the '30 Series,' representing a significant upgrade in operator comfort and hydraulic performance compared to the previous '20 Series.' While not a revolutionary design change, the 4230 built upon the proven reliability of its predecessors and solidified John Deere's position in the agricultural machinery market.

Frequently Asked Questions

Which fuel lift pump fits the John Deere 4230?

The RE27667 - Pump, Fuel Lift Transfer is recommended for the John Deere 4230.

Which brake pads are compatible with the John Deere 4230?

The R110464 - Brake Pads, Metallic are designed for the John Deere 4230.

What oil filter fits the 4230?

The AR50041 - Filter, Diesel Fuel is a common oil filter for the John Deere 4230.

What are common replacement parts for the John Deere 4230?

For routine maintenance and common replacements on the John Deere 4230, consider parts such as the R83021 - Gasket, Exhaust Manifold, R45822 - Bushing, Hydraulic Drive, T20077 - Keeper, Valve, AR51584 - Tie Rod, Long Outer, and R111122 - Brake Pads, Metallic.

Showing 1-24 of 695 products
