John Deere 3040 Tractor Parts
John Deere 3040 Tractor parts in stock. Quality OEM and aftermarket replacement parts with fast shipping and competitive prices.
The John Deere 3040, manufactured from 1979 to 1982, was a popular utility tractor known for its reliability and versatility. Powered by a robust 75 horsepower diesel engine and offering a 65 PTO horsepower, this model provided farmers with the power needed for a wide range of tasks. Its comfortable cab and ease of operation made it a favorite for everything from row crop work to haying operations.
About the 3040
The John Deere 3040 was introduced in 1979 as part of the '40 Series' tractors, replacing earlier models and offering improved features and performance. Production continued through 1982. The heart of the 3040 is the John Deere 4.239D diesel engine, a 239 cubic inch (3.9L) inline four-cylinder engine producing around 75 engine horsepower. This reliable diesel powerplant provided ample torque for pulling implements and powering PTO-driven equipment. It featured a naturally aspirated design and direct fuel injection. Transmission options included a standard Syncro Range transmission offering 8 forward and 4 reverse speeds, or an optional PowrQuad transmission providing 16 forward and 8 reverse speeds. The independent PTO delivered approximately 65 horsepower at 540 RPM, or an optional 1000 RPM. The open-center hydraulic system provided around 19.8 GPM of flow to power implements, with one or two remote valves available. The 3-point hitch was a Category II, offering a lift capacity of approximately 4,800 lbs. The John Deere 3040 found common application in row crop farming, hay production, livestock operations, and general tillage work. Compared to smaller models in the lineup, the 3040 offered increased horsepower and hydraulic capacity, making it suitable for larger implements and more demanding tasks. It stood out for its comfortable cab, relatively quiet operation, and dependable performance.
3040 Specifications
| Engine | John Deere 4.239D 75 HP 239 ci Diesel |
|---|---|
| PTO HP | 65 HP @ 540/1000 RPM |
| Transmission | Syncro Range 8F/4R or PowrQuad 16F/8R |
| Hydraulics | 19.8 GPM, 1-2 remotes |
| 3-Point Hitch | Category II, 4800 lbs |
| Fuel Capacity | 26.4 gallons |
| Weight | 7,100 lbs |
| Years Produced | 1979-1982 |
3040 Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 250 hours of operation using a high-quality diesel engine oil meeting John Deere specifications.
- Hydraulic System: Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours. Use only John Deere Hy-Gard or equivalent hydraulic fluid.
- Fuel System: Drain the fuel sediment bowl regularly to remove water and debris. Replace fuel filters annually to prevent fuel system issues and ensure optimal engine performance.
- Seasonal Storage: Before storing the tractor for extended periods, add fuel stabilizer to the fuel tank, change engine oil, and grease all lubrication points. Disconnect the battery and store it in a cool, dry place.
3040 History & Background
The John Deere 3040 was part of the '40 Series' tractors launched in 1979. It represented a significant upgrade in terms of operator comfort and features compared to its predecessors. This model helped solidify John Deere's position as a leading manufacturer of reliable and versatile agricultural tractors.
Frequently Asked Questions
Which main bearing set is recommended for the John Deere 3040?
For the John Deere 3040, the recommended standard main bearing set is RE27352 - Bearing, Main (Std).
What PTO clutch plate fits the John Deere 3040?
The PTO clutch plate that fits the John Deere 3040 is L64752 - Plate, PTO Clutch.
What diesel fuel filter fits the John Deere 3040?
The diesel fuel filter recommended for the John Deere 3040 is AR50041 - Filter, Diesel Fuel.
What are common parts needed for the 3040?
Common wear parts for the John Deere 3040 include the hydraulic filter AL56469 - Filter, Hydraulic, Spin-on, the clutch plate spring R26637 - Spring, Clutch Plate / Cover, Outer, the fuel injection nozzle o-ring kit RE32011 - O-Ring Kit; Fuel Injection Nozzle Seal, valve seal RE31617 - Seal, Valve, exhaust manifold gasket T20006 - Gasket, Exhaust Manifold, and cab door hinge bushing R65570 - Bushing; Cab Door Hinge.

T26321 - Lower Bushing
SKU: T26321
69 in stock

T20328 - Oil Filler Cap Gasket
SKU: T20328
48 in stock

RE38852 - Upper (329) Gasket Set
SKU: RE38852
65 in stock

RE27667 - Fuel Lift Transfer Pump
SKU: RE27667
2834 in stock

RE27348 - Connecting Rod (Std) Bearing
SKU: RE27348
1575 in stock

RE18678 - Flywheel w/ Ring Gear
SKU: RE18678
2 in stock

T20129 - Valve Stem Cap
SKU: T20129
155 in stock

T20077 - Valve Keeper
SKU: T20077
1248 in stock

T20073 - Camshaft Follower
SKU: T20073
131 in stock

T20006 - Exhaust Manifold Gasket
SKU: T20006
834 in stock

RE64292 - Injector O-Ring Kit
SKU: RE64292
1121 in stock

RE53884-S - Camshaft
SKU: RE53884-S
5 in stock

RE53884 - Camshaft Kit
SKU: RE53884
5 in stock

RE52020 - Oil Pump Repair Kit
SKU: RE52020
23 in stock

RE508317 - W/ Adjusting Screw Rocker Arm
SKU: RE508317
64 in stock

RE502079 - Glow Plug
SKU: RE502079
164 in stock

RE35685 - Oil Pump
SKU: RE35685
141 in stock

RE33115 - Piston Liner Kit
SKU: RE33115
94 in stock

RE32011 - Fuel Injection Nozzle Seal O-Ring Kit
SKU: RE32011
127 in stock

RE31929 - Engine Oil Cooler
SKU: RE31929
27 in stock

RE31617 - Valve Seal
SKU: RE31617
322 in stock

RE27368 - Main (.030") Bearing
SKU: RE27368
10 in stock

RE27364 - Connecting Rod (.030") Bearing Set
SKU: RE27364
24 in stock

RE27360 - Main (.020") Bearing
SKU: RE27360
55 in stock
