Specifications
- Dim A (1):
- Top Ring Width: .125"
- Dim B (2):
- Top Ring Type: Keystone Wedge W/ Internal Chamfer
- Dim C (3):
- Second Ring Width: .096"
- Dim D (4):
- Second Ring Type: Half Keystone Wedge
- Dim E (5):
- Third Ring Width: .136"
- Dim F (6):
- Third Ring Type: Oil Control W/ Coil Spring
- Dim G (7):
- For 3 Ring Piston
About This Product
The RE524453 Rings, Piston is a premium replacement part engineered to fit John Deere equipment. Part number RE524453 is built to OEM specifications for reliable, long-lasting performance in demanding agricultural and industrial applications. Key specifications for RE524453: Dim A (1): Top Ring Width: .125"; Dim B (2): Top Ring Type: Keystone Wedge W/ Internal Chamfer; Dim C (3): Second Ring Width: .096"; Dim D (4): Second Ring Type: Half Keystone Wedge; Dim E (5): Third Ring Width: .136"; Dim F (6): Third Ring Type: Oil Control W/ Coil Spring; Dim G (7): For 3 Ring Piston. These specifications ensure proper fitment and function on compatible equipment. RE524453 is a direct-fit replacement designed for the following equipment: John Deere 1570, 9550, 9550SH, 9560, 9560SH, 9560WTS, and additional models. Part number RE524453 replaces OEM part numbers RE524453 (JOHN DEERE), RE516268 (JOHN DEERE). Confirm your part number before ordering to ensure correct replacement. Order RE524453 from Madison Tractor for fast shipping, knowledgeable parts support, and our quality guarantee. We stock thousands of replacement parts for tractors, mowers, and agricultural equipment — if you have questions about RE524453 or need help confirming fitment, our parts specialists are ready to help.
Cross References
A-RE524453
JOHN DEERE
HCTRE516268
A & I MEGA-CROSS
HCTRE524453
A & I MEGA-CROSS
RE516268
JOHN DEERE
A-RE524453
JOHN DEERE
VPB4066
VAPORMATIC
Fits the following makes and models:
