John Deere 9400 Tractor Parts
Shop John Deere 9400 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.
The John Deere 9400, manufactured from 1996 to 1999, is a high-horsepower row crop tractor known for its robust performance. Powered by a 375 horsepower diesel engine, the 9400 delivers dependable power and efficiency in demanding farming operations. Its high PTO horsepower made it a favorite for tillage and other PTO-driven implements.
About the 9400
The John Deere 9400 was introduced in 1996 as part of the John Deere '9000' series of four-wheel-drive tractors, designed for large-acreage farming operations. Production continued through 1999. This model is equipped with a Cummins N14 diesel engine rated at 375 horsepower, with a displacement of 855 cubic inches (14.0 liters). It featured a robust 12-speed powershift transmission for efficient power delivery. The PTO is rated at 275 horsepower. The hydraulic system provides a flow rate of approximately 46 GPM, typically equipped with 3-4 remote valves. The 9400 does not have a 3-point hitch but can be equipped with a drawbar. Its primary applications included heavy tillage (plowing, disking), planting, and pulling large implements across expansive fields. Distinguishing itself from other models in the John Deere lineup, the 9400 provided higher horsepower and increased traction for maximum productivity.
9400 Specifications
| Engine | Cummins N14 375 HP Diesel |
|---|---|
| PTO HP | 275 HP @ 1000 RPM |
| Transmission | Powershift 12-speed |
| Hydraulics | 46 GPM, 3-4 remotes |
| 3-Point Hitch | N/A |
| Fuel Capacity | 200 gallons |
| Weight | 34,500 lbs |
| Years Produced | 1996-1999 |
9400 Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 250-300 hours using the recommended John Deere oil specification. Regularly inspect the oil level and condition.
- Hydraulic System: Check hydraulic oil levels and filter condition every 500 hours. Replace hydraulic filters according to the manufacturer's recommendations to prevent contamination.
- Fuel System: Use clean, high-quality diesel fuel and replace fuel filters regularly. Drain water from the fuel/water separator to prevent fuel system issues.
- Seasonal Storage: Before storing the tractor for the off-season, fill the fuel tank to prevent condensation, change engine oil and filter, grease all fittings, and disconnect the battery. Store in a dry, sheltered location.
9400 History & Background
Introduced in 1996, the John Deere 9400 was a significant addition to the John Deere four-wheel-drive tractor lineup. It represented a step up in horsepower and pulling capacity for large-scale farming operations. The 9400 proved to be a reliable and powerful machine that helped farmers cover more ground efficiently.
Frequently Asked Questions
Which fuel lift pump is recommended for the John Deere 9400?
For the John Deere 9400, the RE27667 - Pump, Fuel Lift Transfer is a recommended replacement part.
Which PTO clutch disc is suitable for the John Deere 9400?
A suitable replacement PTO clutch disc for the John Deere 9400 is the AR94519 - Disc, PTO Clutch Assembly.
Which ignition switch fits the John Deere 9400?
The RE61717 - Switch; Ignition is a compatible replacement for the John Deere 9400.
What are some common replacement parts for the John Deere 9400?
Common replacement parts for the John Deere 9400 include the RE500186 - Filter, Fuel/Water Separator, VPK1551 - Hydraulic Filter, RE32011 - O-Ring Kit; Fuel Injection Nozzle Seal, RE336111 - Lamp, Worklight; LED, Flood, R161382 - Knob, Shift Lever, and RE49169 - Receiver Drier.

VTK6414T - Valve Train Kit
SKU: VTK6414T
Out of stock

VTK6059D - Valve Train Kit (Std)
SKU: VTK6059D
2 in stock

VPA6050 - Valve Train Kit
SKU: VPA6050
8 in stock

T26321 - Lower Bushing
SKU: T26321
69 in stock

T24534 - Pan Gasket
SKU: T24534
36 in stock

T20328 - Oil Filler Cap Gasket
SKU: T20328
48 in stock

T20252 - Exhaust Manifold
SKU: T20252
38 in stock

RE27667 - Fuel Lift Transfer Pump
SKU: RE27667
2834 in stock

RE27348 - Connecting Rod (Std) Bearing
SKU: RE27348
1575 in stock

T20129 - Valve Stem Cap
SKU: T20129
155 in stock

T20094 - Crankshaft Gear
SKU: T20094
5 in stock

T20077 - Valve Keeper
SKU: T20077
1248 in stock

T20073 - Camshaft Follower
SKU: T20073
131 in stock

T20070 - Camshaft Gear
SKU: T20070
13 in stock

T20034 - Upper Bushing
SKU: T20034
21 in stock

T20006 - Exhaust Manifold Gasket
SKU: T20006
834 in stock

RE65836 - Water Temp Sender Switch
SKU: RE65836
71 in stock

RE65265 - Hand Primer
SKU: RE65265
176 in stock

RE61812 - Air Intake Temperature Sensor
SKU: RE61812
138 in stock

RE61767 - Oil w/ Gasket Cooler
SKU: RE61767
1 in stock

RE57604 - Dual; Heavy Duty Torsional Damper
SKU: RE57604
Out of stock

RE548027 - Belt Tensioner
SKU: RE548027
143 in stock

RE52020 - Oil Pump Repair Kit
SKU: RE52020
23 in stock

RE519736 - Rocker Shaft
SKU: RE519736
7 in stock
