John Deere 8120 Tractor Parts
Browse John Deere 8120 Tractor replacement parts. Everything from routine maintenance items to hard-to-find components.
The John Deere 8120 tractor, manufactured from 2003 to 2006, is a workhorse known for its power and reliability on the farm. Equipped with a robust John Deere PowerTech 8.1L diesel engine producing around 200 horsepower, the 8120 offers a PTO horsepower of approximately 175. Its blend of power, versatility, and operator comfort made it a popular choice for row crop farming and heavy tillage operations.
About the 8120
The John Deere 8120 was introduced as part of the 8020 series, replacing the earlier 8010 models and offering improvements in performance and technology. Production spanned from 2003 to 2006. At its heart lies a John Deere PowerTech 8.1L 6-cylinder diesel engine, producing approximately 200 horsepower (149 kW) at the flywheel. The engine features a displacement of 496 cubic inches (8.1 liters) and is turbocharged for enhanced power and efficiency. Transmission options include a 16-speed PowerShift transmission providing smooth gear changes under load. The independent PTO delivers around 175 horsepower (130 kW) and offers both 540 and 1000 RPM speeds for versatility. The hydraulic system provides a flow rate of approximately 30 GPM (113.6 L/min), and is often configured with 3-4 remote valves. It features a Category III 3-point hitch with a lift capacity of around 9,921 lbs (4500 kg). The 8120 found common application in row crop operations like planting and cultivating corn and soybeans, as well as in hay production and heavy tillage tasks. Its heavier frame and powerful engine differentiate it from smaller models in the John Deere lineup, making it well-suited for demanding tasks.
8120 Specifications
| Engine | John Deere PowerTech 8.1L 200 HP Diesel |
|---|---|
| PTO HP | 175 HP @ 540/1000 RPM |
| Transmission | PowerShift 16-Speed |
| Hydraulics | 30 GPM, 3-4 remotes |
| 3-Point Hitch | Category III, 9,921 lbs |
| Fuel Capacity | 125 gallons |
| Weight | 19,321 lbs |
| Years Produced | 2003-2006 |
8120 Maintenance Tips
- Engine Oil & Filter: Change your engine oil and filter every 250-300 hours of operation, using the recommended John Deere oil specification. Regularly check the oil level to prevent engine damage.
- Hydraulic System: Inspect hydraulic hoses and fittings for leaks regularly. Change hydraulic fluid and filters according to the manufacturer's recommendations (typically every 1000-1200 hours) to maintain optimal performance.
- Fuel System: Use clean, high-quality diesel fuel. Replace fuel filters at recommended intervals to prevent fuel system contamination and ensure proper engine operation. Consider using a fuel additive during winter months to prevent gelling.
- Seasonal Storage: Before storing the tractor for an extended period, stabilize the fuel, change the engine oil and filters, grease all fittings, and disconnect the battery. Store the tractor in a dry, sheltered location.
8120 History & Background
The John Deere 8120 was part of the 8020 series launched in 2003, representing an evolution in tractor design and performance. This model built upon the success of previous John Deere tractors, incorporating technological advancements and improved operator comfort. The 8120 played a significant role in modern agriculture, offering farmers a powerful and reliable solution for a wide range of tasks.
Frequently Asked Questions
Which main bearing is used in the John Deere 8120 engine?
For the John Deere 8120, the standard main bearing replacement is RE529319 - Main Bearing, Std.
What direct drive clutch disc is compatible with the John Deere 8120?
The AR94516 - Disc, Direct Drive Clutch is suitable for the direct drive clutch system on the John Deere 8120.
What oil filter fits the 8120?
For the John Deere 8120, the recommended lube filter cartridge is RE509672 - Filter, Lube, Cartridge.
What are common parts needed for the 8120?
Commonly needed parts for the John Deere 8120 include the RE509672 - Filter, Lube, Cartridge, RE522372 - Filter, Fuel, Spin-on, RE62777 - Gasket, Exhaust Manifold; Outer (2/Pack), RE61717 - Switch; Ignition, and AL78021 - Mirror Head; LH/RH Outer Rear View.

RE64509 - High Compression Piston Piston Liner Kit
SKU: RE64509
60 in stock

RE520036 - Rear Crankshaft Seal
SKU: RE520036
236 in stock

T20129 - Valve Stem Cap
SKU: T20129
155 in stock

T20077 - Valve Keeper
SKU: T20077
1248 in stock

RE62777 - Exhaust Manifold; Outer (2/Pack) Gasket
SKU: RE62777
896 in stock

RE62776 - Exhaust Manifold; Inner Gasket
SKU: RE62776
1106 in stock

RE61812 - Air Intake Temperature Sensor
SKU: RE61812
138 in stock

RE61253 - Std. Thrust Washer Set
SKU: RE61253
10 in stock

RE57604 - Dual; Heavy Duty Torsional Damper
SKU: RE57604
Out of stock

RE57603 - Torsional Damper
SKU: RE57603
Out of stock

RE57054 - Camshaft W/ Tappets
SKU: RE57054
30 in stock

RE55475 - Head Gasket
SKU: RE55475
43 in stock

RE542461 - Exhaust Manifold Pressure Sensor
SKU: RE542461
243 in stock

RE537635 - Manifold Air Temperature Sensor
SKU: RE537635
130 in stock

RE535300 - Crankshaft
SKU: RE535300
10 in stock

RE534314 - Crankshaft
SKU: RE534314
10 in stock

RE534183 - .011 Undersize Thrust Bearing
SKU: RE534183
Out of stock

RE534181 - .011 Undersize Main Bearing
SKU: RE534181
16 in stock

RE529320 - Std. Thrust Bearing
SKU: RE529320
440 in stock

RE529319 - Std. Main Bearing
SKU: RE529319
4392 in stock

RE528402 - Upper Gasket Set
SKU: RE528402
4 in stock

RE528400 - O/H Gasket Set
SKU: RE528400
18 in stock

RE527551 - Complete Overhaul Gasket Set
SKU: RE527551
10 in stock

RE527550 - Head Gasket Set
SKU: RE527550
7 in stock
