John Deere 7410 Tractor Parts
John Deere 7410 Tractor parts in stock. Quality OEM and aftermarket replacement parts with fast shipping and competitive prices.
The John Deere 7410, manufactured from 1997 to 2002, is a sought-after utility tractor renowned for its reliability. Powered by a John Deere 6.8L PowerTech diesel engine producing around 125 horsepower, and offering approximately 105 PTO horsepower, it was a popular choice for a variety of farming tasks. Farmers appreciated its robust design and versatility.
About the 7410
The John Deere 7410 was introduced in 1997 as part of the 7010 series, replacing the earlier 7000 series tractors. Production continued until 2002. It features a John Deere 6.8L PowerTech six-cylinder diesel engine. This engine produces approximately 125 engine horsepower with a displacement of 414 cubic inches. Several transmission options were available, including a 16-speed PowrQuad transmission, providing a range of gear selections for different field conditions. The 7410 offers around 105 PTO horsepower, with both 540 and 1000 RPM PTO options. The hydraulic system delivers a flow rate of approximately 29 GPM, with typically two or three remote valves. It features a Category II 3-point hitch with a lift capacity of around 6,724 lbs. The 7410 was commonly used for row crop operations, hay production, livestock management, and tillage applications. Distinguishing it from other models in the John Deere lineup, the 7410 offered a balance of power and versatility suitable for mid-sized farms, filling a crucial gap between smaller utility tractors and larger row crop tractors.
7410 Specifications
| Engine | John Deere 6.8L 125 HP Diesel |
|---|---|
| PTO HP | 105 HP @ 540/1000 RPM |
| Transmission | PowrQuad, 16-speed |
| Hydraulics | 29 GPM, 2-3 remotes |
| 3-Point Hitch | Category II, 6,724 lbs |
| Fuel Capacity | 47.5 gallons |
| Weight | 13,090 lbs |
| Years Produced | 1997-2002 |
7410 Maintenance Tips
- Engine Oil & Filter: Change the engine oil and filter every 250-300 hours using John Deere-recommended oil and filters. Regularly check oil levels.
- Hydraulic System: Inspect hydraulic fluid levels and condition regularly. Replace hydraulic filters every 500 hours to prevent contamination and maintain optimal performance.
- Fuel System Care: Use clean, high-quality diesel fuel. Drain water separator regularly and replace fuel filters according to the manufacturer's recommendations to prevent fuel system issues.
- Seasonal Storage: Before storing the tractor for extended periods, stabilize the fuel, change engine oil, grease all fittings, and disconnect the battery to prevent corrosion and ensure easy starting when you need it again.
7410 History & Background
The John Deere 7410 was launched in 1997 as part of the 7010 series, marking an evolution in John Deere's utility tractor offerings. It built upon the success of previous models by incorporating updated engine technology and improved transmission options. The 7410 became a popular choice for farmers needing a versatile and dependable tractor for various agricultural tasks.
Frequently Asked Questions
Which pencil injector is compatible with the John Deere 7410?
The recommended pencil injector for the John Deere 7410 is RE48786 - Injector, Pencil. It's designed for optimal fuel delivery and performance.
What PTO clutch disc fits the John Deere 7410?
The RE23286 - Disc, PTO Clutch is suitable for the John Deere 7410. This component is essential for reliable power transfer to your PTO-driven implements.
Which main bearing is recommended for the John Deere 7410?
For standard replacement, the RE65165 - Bearing, Main (Std) is suitable for the John Deere 7410. Always ensure proper sizing and consult your service manual.
What are common replacement parts for the John Deere 7410?
Regular maintenance and timely replacement of wear parts ensure the longevity of your John Deere 7410. Commonly replaced items include the RE62419 - Filter, Separator, Fuel/Water, VPK1551 - Hydraulic Filter, RE64292 - Kit, Injector O-Ring, RE35512 - Disc, Clutch, RE31617 - Seal, Valve, and RE51091 - Auxiliary Power Outlet.

RE292445 - Brake Disc
SKU: RE292445
40 in stock

VTK6059D - Valve Train Kit (Std)
SKU: VTK6059D
2 in stock

T26321 - Lower Bushing
SKU: T26321
69 in stock

RE38852 - Upper (329) Gasket Set
SKU: RE38852
65 in stock

T20094 - Crankshaft Gear
SKU: T20094
5 in stock

T20073 - Camshaft Follower
SKU: T20073
131 in stock

T20070 - Camshaft Gear
SKU: T20070
13 in stock

T20034 - Upper Bushing
SKU: T20034
21 in stock

T20006 - Exhaust Manifold Gasket
SKU: T20006
834 in stock

T122075 - Oil Cooler (2 PK) O-Ring
SKU: T122075
43 in stock

RE70358 - Metric Filter Head
SKU: RE70358
143 in stock

RE69243 - Engine Oil Dipstick
SKU: RE69243
217 in stock

RE68345 - Fuel Lift Pump
SKU: RE68345
87 in stock

RE66153 - Fuel Transfer Pump
SKU: RE66153
450 in stock

RE66085 - Upper Gasket Set
SKU: RE66085
8 in stock

RE65969 - Piston Liner Kit
SKU: RE65969
52 in stock

RE65912 - Thrust (.010") Bearing
SKU: RE65912
73 in stock

RE65911 - Main (.010") Bearing
SKU: RE65911
721 in stock

RE65909 - Connecting Rod (.010") Bearing
SKU: RE65909
79 in stock

RE65908B - Connecting Rod (.020") Bearing
SKU: RE65908B
8 in stock

RE65908 - Connecting Rod (Std) Bearing
SKU: RE65908
7182 in stock

RE65836 - Water Temp Sender Switch
SKU: RE65836
71 in stock

RE65168B - Thrust (.020") Bearing
SKU: RE65168B
14 in stock

RE65168 - Thrust (Std) Bearing
SKU: RE65168
627 in stock
