John Deere 6620 Tractor Parts
Find parts for your John Deere 6620 Tractor. We stock OEM and quality aftermarket replacements ready to ship.
The John Deere 6620 tractor, manufactured from 2003 to 2007, was a popular choice for farmers needing a reliable and versatile machine. Powered by a John Deere PowerTech 6.8L diesel engine producing approximately 125 horsepower, the 6620 offered ample power for a variety of tasks. Its robust design and a PTO horsepower rating of around 105 made it well-suited for haying, tillage, and livestock operations.
About the 6620
The John Deere 6620 was introduced in 2003 as part of the '20 Series' tractors, replacing earlier models and offering improvements in engine technology and operator comfort. Production continued until 2007. It featured a John Deere PowerTech 6.8L turbocharged diesel engine, delivering around 125 horsepower. This engine was known for its fuel efficiency and reliability. Transmission options included a standard SyncroPlus transmission with several gear options depending on the specific configuration, some offering partial power shift capabilities. The independent PTO delivered around 105 horsepower, available in both 540 and 1000 RPM options, providing versatility for different implements. The hydraulic system had a capacity of approximately 29 GPM, providing ample flow for hydraulic implements. The 3-point hitch was a Category II, offering a lift capacity of around 6,500 lbs. The 6620 found applications in various farming operations, including row crop work, hay production, and livestock management. Compared to the smaller 6000 series, it offered more power and hydraulic capacity, while remaining more compact and maneuverable than the larger 7000 series tractors, making it a well-rounded machine for many farm sizes.
6620 Specifications
| Engine | John Deere PowerTech 6.8L 125 HP Diesel |
|---|---|
| PTO HP | 105 HP @ 540/1000 RPM |
| Transmission | SyncroPlus (Various Speed Options Available) |
| Hydraulics | 29 GPM, 2-3 remotes |
| 3-Point Hitch | Category II, 6500 lbs |
| Fuel Capacity | 47.5 gallons |
| Weight | 12,500 lbs |
| Years Produced | 2003-2007 |
6620 Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 250-300 hours using the recommended John Deere oil specification for optimal engine life.
- Hydraulic System: Check hydraulic fluid levels regularly and replace hydraulic filters according to the manufacturer's recommendations (usually every 500 hours) to prevent contamination and maintain hydraulic performance.
- Fuel System: Use clean, high-quality diesel fuel and regularly inspect the fuel filter. Drain any water or sediment from the fuel tank to prevent fuel system issues.
- Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel, grease all fittings, and consider covering the exhaust pipe to prevent moisture from entering the engine.
6620 History & Background
The John Deere 6620 was launched in 2003 as part of John Deere's revamped '20 Series' tractor line. This series was designed to improve upon the previous generation with enhanced engine technology and improved operator comfort. The 6620 proved a popular model during its production run due to its versatile size and power.
Frequently Asked Questions
Which exhaust manifold gasket fits the John Deere 6620?
The T20006 - Gasket, Exhaust Manifold is designed for the John Deere 6620.
What replacement clutch disc is recommended for the John Deere 6620?
For the John Deere 6620, we recommend the RE35512 - Disc, Clutch.
Which fuel/water separator filter is appropriate for the John Deere 6620?
The RE62418 - Filter, Separator, Fuel/Water is a suitable replacement for the John Deere 6620.
What are some essential replacement parts for the John Deere 6620?
Essential replacement parts for the John Deere 6620 include the VPK1551 - Hydraulic Filter, L214634 - Filter, Cab Air, Recirculation, AL156090 - Tensioner, Belt, AL78021 - Mirror Head; LH/RH Outer Rear View, and L158186 - Pin; Lower Lift Link.

RE527832 - Upper Gasket Set
SKU: RE527832
17 in stock

RE519115 - Valve; Intake/Exhaust Seal
SKU: RE519115
290 in stock

T20073 - Camshaft Follower
SKU: T20073
131 in stock

T20006 - Exhaust Manifold Gasket
SKU: T20006
834 in stock

RE66085 - Upper Gasket Set
SKU: RE66085
8 in stock

RE65969 - Piston Liner Kit
SKU: RE65969
52 in stock

RE65912 - Thrust (.010") Bearing
SKU: RE65912
73 in stock

RE65911 - Main (.010") Bearing
SKU: RE65911
721 in stock

RE65909 - Connecting Rod (.010") Bearing
SKU: RE65909
79 in stock

RE65908B - Connecting Rod (.020") Bearing
SKU: RE65908B
8 in stock

RE65908 - Connecting Rod (Std) Bearing
SKU: RE65908
7182 in stock

RE65168B - Thrust (.020") Bearing
SKU: RE65168B
14 in stock

RE65168 - Thrust (Std) Bearing
SKU: RE65168
627 in stock

RE65165 - Main (Std) Bearing
SKU: RE65165
6921 in stock

RE64292 - Injector O-Ring Kit
SKU: RE64292
1121 in stock

RE61812 - Air Intake Temperature Sensor
SKU: RE61812
138 in stock

RE59810 - Front Crankshaft Seal
SKU: RE59810
61 in stock

RE59298 - 9 Plate Engine Oil Cooler
SKU: RE59298
7 in stock

RE557891 - Exhaust; 30° Valve
SKU: RE557891
818 in stock

RE557890 - Intake; 30° Valve
SKU: RE557890
1146 in stock

RE55512 - Piston
SKU: RE55512
5 in stock

RE531436 - Fuel Injector
SKU: RE531436
452 in stock

RE522594 - Side Feed Tube
SKU: RE522594
37 in stock

RE519696 - Water In Fuel Sensor
SKU: RE519696
161 in stock
