John Deere 6170R Tractor Parts
Shop John Deere 6170R Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.
The John Deere 6170R tractor, manufactured from 2011 to 2015, became a favorite among farmers for its robust performance and versatility. Powered by a John Deere PowerTech 6.8L diesel engine producing 170 horsepower, it offered exceptional power for various tasks. With a PTO horsepower of around 140, the 6170R proved itself a reliable workhorse in demanding agricultural applications.
About the 6170R
The John Deere 6170R was introduced in 2011 as part of the 6R series, replacing older models and offering updated technology and increased efficiency. Production ran until 2015. At its heart is a John Deere PowerTech 6.8L 6-cylinder diesel engine, delivering a rated engine horsepower of 170 hp. The engine's large displacement provides ample torque for challenging tasks. The 6170R primarily featured the AutoQuad Plus or DirectDrive transmission, offering various gear options for optimal speed and efficiency, with some models featuring an Infinitely Variable Transmission (IVT). PTO horsepower is approximately 140 hp, with both 540/1000 RPM PTO options available. The hydraulic system boasts a capacity of around 30 GPM, with multiple remote valves for controlling implements. The 3-point hitch is Category III, capable of lifting over 10,000 lbs. This tractor found applications across row crop farming, hay production, livestock operations, and tillage. The 6170R stood out from other models in the lineup due to its balance of power, size, and features, making it ideal for medium-sized farms needing a versatile machine.
6170R Specifications
| Engine | John Deere PowerTech 6.8L 170 HP Diesel |
|---|---|
| PTO HP | 140 HP @ 540/1000 RPM |
| Transmission | AutoQuad Plus/DirectDrive/IVT (Optional) |
| Hydraulics | 30 GPM, Up to 5 remotes |
| 3-Point Hitch | Category III, 10,141 lbs lift capacity |
| Fuel Capacity | 94.1 gallons |
| Weight | 18,188 lbs |
| Years Produced | 2011-2015 |
6170R Maintenance Tips
- Change engine oil and filter every 500 hours of operation using the recommended John Deere engine oil and filter.
- Inspect and maintain the hydraulic system regularly, checking for leaks and changing the hydraulic fluid and filters per the manufacturer's recommendations (typically every 1000-1500 hours).
- Use high-quality diesel fuel and add a fuel conditioner, especially during cold weather or prolonged storage, to prevent fuel gelling and injector issues.
- Before seasonal storage, drain water from the fuel/water separator, lubricate all grease fittings, and store the tractor in a dry place to prevent rust and corrosion.
6170R History & Background
The John Deere 6170R was introduced as part of the updated 6R series in 2011, marking a significant upgrade in technology and performance compared to previous John Deere tractor models. While there weren't major redesigns during its production run, continuous improvements were implemented. The 6170R solidified John Deere's position as a leader in mid-sized agricultural tractors.
Frequently Asked Questions
Which ignition switch is compatible with the John Deere 6170R?
The RE61717 - Switch; Ignition is designed for reliable starts in your 6170R.
What PTO clutch disc is recommended for the John Deere 6170R?
The RE23286 - Disc, PTO Clutch ensures proper power take-off engagement for your 6170R.
What fuel/water separator filter is used on the John Deere 6170R?
For optimal fuel system protection, use the RE541922 - Filter, Separator, Fuel/Water on your 6170R.
What are common wear items for the John Deere 6170R?
Regular maintenance on your 6170R often involves replacing items such as the L214634 - Filter, Cab Air, Recirculation, the RE35512 - Disc, Clutch, and a AL160535 - Seal, MFWD. Other frequently replaced parts include the RE573609 - Work Lamp, LED; Flood and the R530923 - Gasket; EGR Cooler Outlet Tube.

RE575415 - Crankcase Pressure Sensor
SKU: RE575415
279 in stock

RE545562 - Fuel; Common Rail Injector
SKU: RE545562
Out of stock

RE545330 - Common Rail To Fuel Injector Fuel Line
SKU: RE545330
72 in stock

RE542461 - Exhaust Manifold Pressure Sensor
SKU: RE542461
243 in stock

RE538131 - Exhaust System Diesel Oxidation Catalyst Pressure Sensor
SKU: RE538131
278 in stock

RE538128 - Fuel Pressure Sensor
SKU: RE538128
82 in stock

RE538127 - Fuel Temperature Sensor
SKU: RE538127
6 in stock

RE537640 - Engine Oil Pressure Sensor
SKU: RE537640
93 in stock

RE537639 - Manifold Air Pressure Sensor
SKU: RE537639
255 in stock

RE537636 - EGR Temperature Sensor
SKU: RE537636
149 in stock

RE537635 - Manifold Air Temperature Sensor
SKU: RE537635
130 in stock

RE536920 - Fuel Inlet Connector Tube
SKU: RE536920
44 in stock

RE536275 - Fuel Rail Pressure Sensor
SKU: RE536275
163 in stock

RE536274 - Rail Fuel Injection Pressure Relief Valve
SKU: RE536274
242 in stock

RE516553 - Fuel Filter Seal Kit
SKU: RE516553
232 in stock

RE500608 - Fracture Type Connecting Rod
SKU: RE500608
Out of stock

R80135 - Oil Filler Cap Gasket
SKU: R80135
23 in stock

R28574 - Seal Retainer
SKU: R28574
934 in stock

AL209601 - LH / RH Tie Rod End Outer
SKU: AL209601
146 in stock

AL209419 - RH/LH Steering Cylinder Ball Joint
SKU: AL209419
333 in stock

AL160111 - Tie Rod Assembly
SKU: AL160111
53 in stock

U41966 - Durometer 75 (4/Pack) .103" Thick O-Ring; 1.424" ID X 1.630" OD
SKU: U41966
176 in stock

U11326 - 5/pack Durometer 75 O-Ring; 1.114" ID X 1.254" OD X .070" Thick
SKU: U11326
520 in stock

T42302 - Durometer 70 (1/Pack) .103" Thick O-Ring; 3.987" ID X 4.193" OD
SKU: T42302
344 in stock
