John Deere 5510N Tractor Parts
Browse John Deere 5510N Tractor replacement parts. Everything from routine maintenance items to hard-to-find components.
The John Deere 5510N, manufactured from 1999 to 2007, is a narrow row crop tractor known for its versatility and power in specialty farming operations. Powered by a 75 HP diesel engine, this tractor delivered reliable performance. With a PTO horsepower of approximately 63 HP, the 5510N offered ample power for running implements in confined spaces.
About the 5510N
The John Deere 5510N was introduced in 1999 as part of the John Deere N-series narrow tractors, designed specifically for orchard, vineyard, and row crop applications where space is limited. Production continued until 2007. This model features a Yanmar 4TNE94 diesel engine producing approximately 75 horsepower. The engine displacement is 2.8L (170.9 cu in). Transmission options include a synchro range transmission with 9 forward and 3 reverse gears, or a PowrReverser transmission with 9 forward and 9 reverse gears, offering enhanced maneuverability. The PTO delivers around 63 horsepower and offers 540 RPM. Its hydraulic system has a capacity of around 11.9 GPM, with two or three rear remotes available. The 3-point hitch is Category II, with a lift capacity of approximately 2646 lbs. Common applications for the 5510N include working in vineyards, orchards, vegetable farms, and other close-row crop settings. What sets it apart is its narrow design and robust power for implements within confined spaces, making it well-suited for specialty farming tasks compared to standard utility tractors.
5510N Specifications
| Engine | Yanmar 4TNE94 75 HP Diesel |
|---|---|
| PTO HP | 63 HP @ 540 RPM |
| Transmission | Synchro Range or PowrReverser, 9 Forward / 3 or 9 Reverse |
| Hydraulics | 11.9 GPM, 2-3 remotes |
| 3-Point Hitch | Category II, 2646 lbs |
| Fuel Capacity | 18.5 gallons |
| Weight | 5401 lbs |
| Years Produced | 1999-2007 |
5510N Maintenance Tips
- Engine Oil & Filter: Change the engine oil and filter every 250 hours using a high-quality oil meeting John Deere specifications. Always replace the filter with a genuine or equivalent quality filter.
- Hydraulic System: Inspect hydraulic oil levels regularly and change the hydraulic filter every 500 hours. Use John Deere Hy-Gard or equivalent hydraulic fluid.
- Fuel System: Regularly drain water from the fuel tank and replace the fuel filter every 500 hours to prevent fuel system issues. Use clean, fresh diesel fuel.
- Seasonal Storage: Before storing the tractor for the off-season, fill the fuel tank to prevent condensation, change engine oil and filters, grease all fittings, and disconnect the battery. Store in a dry location.
5510N History & Background
The John Deere 5510N was launched in 1999 as part of John Deere's commitment to providing specialized equipment for niche agricultural applications. As a narrow row crop tractor, it filled a critical need for farmers working in tight spaces. The 5510N remains a respected and sought-after model for its blend of power and maneuverability.
Frequently Asked Questions
Which water pump is recommended for the John Deere 5510N?
For the John Deere 5510N, the recommended replacement water pump is RE500734 - Water Pump.
Which PTO disc is suitable for the John Deere 5510N?
A common replacement PTO disc for the John Deere 5510N is the RE227648 - PTO Disc; 4 Button.
What oil filter fits the John Deere 5510N?
The recommended engine oil filter for the John Deere 5510N is RE59754 - Filter, Engine Oil.
What are common replacement parts for the John Deere 5510N?
Common replacement parts for the John Deere 5510N include the RE45864 - Filter, Hydraulic, Spin-on, the RE516553 - Seal Kit, Fuel Filter, a AL177185 - Cab Filter, the RE48786 - Injector, Pencil, the RE177574 - Trans Disc: 11", 6-button, spring loaded, and the R109452 - Bushing, Spindle, Upper / Lower.

T20328 - Oil Filler Cap Gasket
SKU: T20328
48 in stock

RE66271 - Piston Rings
SKU: RE66271
45 in stock

RE65967 - Piston Liner Kit
SKU: RE65967
55 in stock

RE506195 - Taper Nose Crankshaft
SKU: RE506195
4 in stock

T20073 - Camshaft Follower
SKU: T20073
131 in stock

T20006 - Exhaust Manifold Gasket
SKU: T20006
834 in stock

T122075 - Oil Cooler (2 PK) O-Ring
SKU: T122075
43 in stock

RE71550 - Turbocharger
SKU: RE71550
14 in stock

RE69243 - Engine Oil Dipstick
SKU: RE69243
217 in stock

RE68748 - Leak Off Tube
SKU: RE68748
214 in stock

RE66082 - Upper Gasket Set
SKU: RE66082
42 in stock

RE65912 - Thrust (.010") Bearing
SKU: RE65912
73 in stock

RE65911 - Main (.010") Bearing
SKU: RE65911
721 in stock

RE65909 - Connecting Rod (.010") Bearing
SKU: RE65909
79 in stock

RE65908 - Connecting Rod (Std) Bearing
SKU: RE65908
7182 in stock

RE65168 - Thrust (Std) Bearing
SKU: RE65168
627 in stock

RE65165 - Main (Std) Bearing
SKU: RE65165
6921 in stock

RE64292 - Injector O-Ring Kit
SKU: RE64292
1121 in stock

RE62240 - 12V Fuel Injection Pump Shutoff Solenoid
SKU: RE62240
33 in stock

RE59810 - Front Crankshaft Seal
SKU: RE59810
61 in stock

RE59296 - 5 Plate Engine Oil Cooler
SKU: RE59296
57 in stock

RE56375 - Camshaft
SKU: RE56375
9 in stock

RE548027 - Belt Tensioner
SKU: RE548027
143 in stock

RE527042 - Complete Overhaul Gasket Set
SKU: RE527042
30 in stock
