John Deere 5420 Tractor Parts

5420 parts and accessories

The John Deere 5420 tractor, manufactured from 2003 to 2007, became a popular choice for farmers needing a versatile and reliable machine. Powered by a John Deere PowerTech 4.5L diesel engine producing approximately 74 horsepower, this tractor delivered ample power for a variety of tasks. Its independent 540 RPM PTO made it well-suited for operating implements like mowers, balers, and rotary cutters.

The John Deere 5420 was introduced in 2003 as part of the John Deere 5000 series, replacing earlier models and offering improvements in power, comfort, and features. Production continued until 2007. The 5420 is powered by a John Deere PowerTech 4045D 4.5L (276 ci) four-cylinder diesel engine, delivering approximately 74 engine horsepower and 63 PTO horsepower. Available transmission options included a SyncReverser transmission with 9 forward and 9 reverse gears or a PowrReverser transmission with 9 forward and 9 reverse gears offering clutchless shuttle shifting. The independent PTO provides 540 RPM speed. The hydraulic system has a capacity of around 15.9 GPM, powering two rear remotes. The three-point hitch is Category II, with a lift capacity of approximately 3,700 lbs. Common farming applications for the 5420 include hay production, livestock operations (feeding, manure handling), and light tillage. Compared to other models in the 5000 series, the 5420 offered a good balance of power and maneuverability for mid-sized farms, appealing to those needing more capability than smaller utility tractors but without the bulk of larger row crop tractors.

Specifications

Engine	John Deere PowerTech 74 HP 4.5L Diesel
PTO HP	63 HP @ 540 RPM
Transmission	SyncReverser/PowrReverser 9x9
Hydraulics	15.9 GPM, 2 remotes
3-Point Hitch	Category II, 3700 lbs
Fuel Capacity	26.4 gallons
Weight	6600 lbs
Years Produced	2003-2007

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using the recommended John Deere oil specification for optimal engine life.
Hydraulic System Maintenance: Inspect hydraulic oil levels regularly. Replace hydraulic filters every 500 hours or as recommended to prevent contamination and maintain hydraulic performance.
Fuel System Care: Use clean, high-quality diesel fuel and replace the fuel filter annually to prevent fuel system issues and ensure efficient combustion.
Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel, change the engine oil, and grease all lubrication points to prevent corrosion and ensure the tractor is ready for work when needed.

History & Background

Introduced in 2003, the John Deere 5420 aimed to provide a modern, reliable tractor in the mid-horsepower range. While no major redesigns occurred during its production run, Deere continually refined its technology and incorporated customer feedback. The 5420 played a key role in Deere's line-up, bridging the gap between smaller utility tractors and larger row crop machines, becoming a popular choice for diversified farming operations.

Frequently Asked Questions

What engine is in the John Deere 5420?

The John Deere 5420 is equipped with a John Deere PowerTech 4045D 4.5L (276 ci) four-cylinder diesel engine, naturally aspirated.

What is the PTO horsepower on a 5420?

The John Deere 5420 has a PTO horsepower rating of approximately 63 HP at 540 RPM.

What oil filter fits the 5420?

The oil filter typically used on the John Deere 5420 is a John Deere filter part number RE504836. Cross-references include Baldwin B7249, Wix 51794, and Fram PH6066.

What are common parts needed for the 5420?

Common wear parts for the John Deere 5420 include engine oil filters, fuel filters, hydraulic filters, air filters, belts (alternator/fan), hydraulic cylinder seal kits, steering components (tie rod ends, ball joints), and clutch discs/pressure plates.
