John Deere 5320N Tractor Parts
Replacement parts for the John Deere 5320N Tractor. Browse our selection of OEM and aftermarket parts — filters, belts, hydraulics, electrical, and more.
The John Deere 5320N, manufactured from 2004 to 2007, is a specialized narrow-row crop tractor known for its maneuverability and power in confined spaces. Powered by a 67 HP Yanmar diesel engine, this tractor delivered approximately 58 PTO horsepower. Its compact design and reliable performance made it a popular choice for orchard, vineyard, and other specialized farming operations.
About the 5320N
The John Deere 5320N was produced from 2004 to 2007 as part of the John Deere's narrow-row tractor lineup. It's powered by a Yanmar 3.3L 3TNV88 diesel engine, producing approximately 67 horsepower. This tractor features a mechanical transmission, typically available as either a 9-speed forward/3-speed reverse or a 12-speed forward/12-speed reverse synchronized transmission. The PTO delivers around 58 horsepower and offers a 540 RPM setting. The hydraulic system has a capacity of around 11.9 GPM, providing ample power for implements. It features a Category II 3-point hitch. The 5320N found applications in row crop farming, particularly in orchards, vineyards, and vegetable farms where a narrow width is essential. What sets it apart from other John Deere tractors is its narrower profile and shorter wheelbase, allowing it to navigate tight rows and corners effectively. This model was designed for tasks like spraying, mowing, and light tillage in challenging environments, offering a blend of power and agility for specialized farming needs.
5320N Specifications
| Engine | Yanmar 67 HP 3.3L Diesel |
|---|---|
| PTO HP | 58 HP @ 540 RPM |
| Transmission | Mechanical 9F/3R or 12F/12R |
| Hydraulics | 11.9 GPM, 2 remotes |
| 3-Point Hitch | Category II, 3285 lbs |
| Fuel Capacity | 16.6 gallons |
| Weight | 4630 lbs |
| Years Produced | 2004-2007 |
5320N Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 250 hours of operation. Use John Deere Plus-50 II oil and a genuine John Deere oil filter for optimal engine protection.
- Hydraulic System: Check hydraulic fluid levels regularly and change the hydraulic filter every 500 hours. Use John Deere Hy-Gard fluid to maintain optimal performance and prevent component wear. Inspect hydraulic hoses and fittings for leaks or damage.
- Fuel System: Use clean, high-quality diesel fuel and replace the fuel filter every 250 hours. Drain water from the fuel tank regularly to prevent fuel system corrosion and injector problems.
- Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel with a fuel stabilizer, change engine oil and filter, lubricate all grease fittings, and disconnect the battery. Store the tractor in a dry, covered location.
5320N History & Background
The John Deere 5320N was introduced in 2004 as a specialized narrow tractor, filling a need for compact and powerful machinery in niche agricultural applications. There were no major redesigns during its production run from 2004-2007. This model significantly impacted the market by providing a reliable and efficient solution for farms requiring maneuverability in tight spaces, helping to improve productivity and reduce labor costs.
Frequently Asked Questions
Which water pump fits the John Deere 5320N?
The John Deere 5320N uses the RE500734 - Water Pump.
What replacement PTO disc is recommended for the John Deere 5320N?
The recommended PTO disc for the 5320N is the RE227648 - PTO Disc; 4 Button.
What oil filter fits the 5320N?
The John Deere 5320N can use the RE59754 - Filter, Engine Oil.
What are common parts needed for the 5320N?
Common parts needed for the 5320N include: RE45864 - Filter, Hydraulic, Spin-on, RE516553 - Seal Kit, Fuel Filter, RE548027 - Belt Tensioner, RE48786 - Injector, Pencil, T20006 - Gasket, Exhaust Manifold, and CH18562 - Bearing, Trans Release.
