John Deere 5303 Tractor Parts
Browse John Deere 5303 Tractor replacement parts. Everything from routine maintenance items to hard-to-find components.
The John Deere 5303 was a popular utility tractor produced from 2003 to 2007. Known for its reliable diesel engine, typically around 64 horsepower, and a PTO horsepower in the mid-50s, the 5303 offered a balance of power and versatility. Farmers appreciated its adaptability for various tasks, making it a dependable workhorse on the farm.
About the 5303
The John Deere 5303 was part of the popular 5000 series of utility tractors, manufactured between 2003 and 2007. It was designed as a versatile machine suited for a wide range of agricultural tasks. The 5303 typically featured a John Deere PowerTech 3029D diesel engine, a 2.9L (179 cu in) 3-cylinder engine, producing approximately 64 engine horsepower. Transmission options commonly included a synchro-mesh transmission with several forward and reverse gears, enhancing operational flexibility. The PTO horsepower generally reached around 54 HP, with a standard 540 RPM PTO. The hydraulic system provided a flow rate suitable for operating implements, with typically two rear remotes available. The 3-point hitch was usually Category II, offering ample lift capacity for implements. The 5303 found applications in various farming operations, including row crop work, hay production, livestock management, and light tillage. Compared to smaller models in the series, the 5303 provided a step up in power and hydraulic capacity, while remaining more compact and fuel-efficient than larger frame tractors.
5303 Specifications
| Engine | John Deere PowerTech 64 HP Diesel |
|---|---|
| PTO HP | 54 HP @ 540 RPM |
| Transmission | Synchro-Mesh, 9 forward and 3 reverse gears |
| Hydraulics | 12 GPM, 2 remotes |
| 3-Point Hitch | Category II, 3200 lbs lift capacity |
| Fuel Capacity | 18 gallons |
| Weight | 5700 lbs |
| Years Produced | 2003-2007 |
5303 Maintenance Tips
- Engine Oil and Filter: Change the engine oil and filter every 250 hours using the recommended John Deere oil specification. Regularly check the oil level and condition.
- Hydraulic System: Inspect hydraulic fluid levels and hoses every 50 hours of operation. Change hydraulic fluid and filters according to the manufacturer's recommendations, typically every 500 hours.
- Fuel System: Use clean, high-quality diesel fuel and replace the fuel filter every 250 hours. Drain water from the fuel/water separator regularly to prevent contamination.
- Seasonal Storage: Before storing the tractor for extended periods, fill the fuel tank to prevent condensation, add a fuel stabilizer, and disconnect the battery. Perform a thorough inspection and lubrication of all moving parts.
5303 History & Background
The John Deere 5303 was introduced as part of the 5000 series, aiming to provide a modern and versatile utility tractor to farmers. While it didn't undergo major redesigns during its production run, it represented a significant step forward in terms of operator comfort and overall performance compared to earlier utility models.
Frequently Asked Questions
Which pencil injector is recommended for the John Deere 5303?
For the John Deere 5303, the RE48786 - Injector, Pencil is a recommended replacement part.
What PTO clutch disc fits the John Deere 5303?
The RE227648 - PTO Disc; 4 Button is an appropriate replacement part for the John Deere 5303.
Which hydraulic filter is compatible with the John Deere 5303?
The RE45864 - Filter, Hydraulic, Spin-on is a compatible hydraulic filter for the John Deere 5303.
What common replacement parts are available for the John Deere 5303?
For routine maintenance and repairs on the John Deere 5303, frequently replaced items include the RE62418 - Filter, Separator, Fuel/Water, the RE61717 - Switch; Ignition, an T20006 - Gasket, Exhaust Manifold, and R109452 - Bushing, Spindle, Upper / Lower.

T26321 - Lower Bushing
SKU: T26321
69 in stock

T24534 - Pan Gasket
SKU: T24534
36 in stock

T20328 - Oil Filler Cap Gasket
SKU: T20328
48 in stock

RE66271 - Piston Rings
SKU: RE66271
45 in stock

RE507287 - Injector Nozzle
SKU: RE507287
Out of stock

RE27348 - Connecting Rod (Std) Bearing
SKU: RE27348
1575 in stock

T20094 - Crankshaft Gear
SKU: T20094
5 in stock

T20073 - Camshaft Follower
SKU: T20073
131 in stock

T20070 - Camshaft Gear
SKU: T20070
13 in stock

T20034 - Upper Bushing
SKU: T20034
21 in stock

T20006 - Exhaust Manifold Gasket
SKU: T20006
834 in stock

RE70358 - Metric Filter Head
SKU: RE70358
143 in stock

RE64292 - Injector O-Ring Kit
SKU: RE64292
1121 in stock

RE61769 - Oil w/ Gasket Cooler
SKU: RE61769
168 in stock

RE61767 - Oil w/ Gasket Cooler
SKU: RE61767
1 in stock

RE60062 - Pencil Injector
SKU: RE60062
68 in stock

RE52020 - Oil Pump Repair Kit
SKU: RE52020
23 in stock

RE519569 - Pencil Injector
SKU: RE519569
5 in stock

RE516553 - Fuel Filter Seal Kit
SKU: RE516553
232 in stock

RE515684 - Pencil Injector
SKU: RE515684
23 in stock

RE50833 - Pencil Injector
SKU: RE50833
20 in stock

RE508317 - W/ Adjusting Screw Rocker Arm
SKU: RE508317
64 in stock

RE50467 - Fuel Hand Primer
SKU: RE50467
717 in stock

RE503242 - Temperature Switch
SKU: RE503242
109 in stock
