John Deere 5095MH Tractor Parts

Find parts for your John Deere 5095MH Tractor. We stock OEM and quality aftermarket replacements ready to ship.

The John Deere 5095MH is a utility tractor built from 2013 to 2019, designed for versatility in various farming applications. Powered by a robust 95 horsepower diesel engine, it offers reliable performance. Farmers appreciated its agility in row crops and its adequate 75 PTO horsepower for powering implements, making it a workhorse on many operations.

About the 5095MH

The John Deere 5095MH was introduced in 2013 as part of the 5M series, offering a blend of power and maneuverability for diverse agricultural tasks. Production spanned from 2013 to 2019. It's equipped with a John Deere PowerTech 4.5L 4-cylinder diesel engine producing approximately 95 horsepower. The engine's displacement is 276 cubic inches (4.5 liters). Transmission options typically included a PowrReverser transmission with synchronized shuttle shift, allowing for easy directional changes. The PTO delivers around 75 horsepower, with a standard 540 RPM PTO and an optional 540/1000 RPM. Hydraulic capacity is approximately 16.9 GPM powering two or more remote hydraulic valves. This tractor features a Category II 3-point hitch, providing a lift capacity of around 4,100 lbs. Common applications include row crop work, hay baling, livestock operations, and light tillage. The 5095MH stands out from other models in the John Deere lineup due to its optimal balance of horsepower and compact size, making it suitable for smaller farms or operations requiring nimble tractors.

5095MH Specifications

EngineJohn Deere PowerTech 95 HP 4.5L Diesel
PTO HP75 HP @ 540/1000 RPM
TransmissionPowrReverser, 9/3 or 16/16 Speeds
Hydraulics16.9 GPM, 2-3 remotes
3-Point HitchCategory II, 4,100 lbs lift capacity
Fuel Capacity25.1 gallons
Weight7,606 lbs
Years Produced2013-2019

5095MH Maintenance Tips

  • Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using the recommended John Deere oil specification.
  • Hydraulic System: Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours to prevent contamination and maintain optimal performance.
  • Fuel System: Use clean, high-quality diesel fuel and check/replace the fuel filter every 250 hours to ensure proper fuel delivery and prevent engine issues.
  • Seasonal Storage: Before storing the tractor for an extended period, stabilize the fuel, grease all fittings, and disconnect the battery to prevent corrosion and ensure easy starting when you're ready to use it again.

5095MH History & Background

The John Deere 5095MH was introduced to provide farmers with a more compact and powerful utility tractor. While it didn't undergo major redesigns during its production run, it solidified its place as a versatile machine within the 5M series. It represented a good balance of features and size for a variety of farming needs.

Frequently Asked Questions

Which water pump fits the John Deere 5095MH?

For the John Deere 5095MH, the recommended replacement water pump is RE500734 - Water Pump.

What replacement PTO shaft is available for the John Deere 5095MH?

A suitable replacement PTO shaft for the John Deere 5095MH, supporting both 540/1000 RPM, is L156976 - Shaft, PTO (540/1000 RPM).

What oil filter fits the 5095MH?

The recommended oil filter for the John Deere 5095MH is RE504836 - Oil Filter.

What are common parts needed for the John Deere 5095MH?

Commonly needed parts for the John Deere 5095MH include the RE541922 - Filter, Separator, Fuel/Water, RE195491 - Filter, Cab Air, RE548027 - Belt Tensioner, T20006 - Gasket, Exhaust Manifold, R136239 - Bulb, Light; GE888, 50 Watt, and 51M7090 - O-Ring; .528" ID X .716" OD X .094" Thick, Durometer 75. Regularly replacing these items helps maintain optimal tractor performance.

Showing 1-24 of 246 products
