John Deere 5075M Tractor Parts
Browse John Deere 5075M Tractor replacement parts. Everything from routine maintenance items to hard-to-find components.
The John Deere 5075M, manufactured from 2013 to 2021, is a versatile utility tractor powered by a reliable John Deere PowerTech 3.0L diesel engine, producing 75 horsepower. Its robust design and available PowrReverser transmission made it a popular choice for farmers needing a dependable tractor for various tasks, delivering around 64 PTO horsepower.
About the 5075M
The John Deere 5075M was introduced as part of the 5M series, offering a balance of power and versatility for a wide range of agricultural applications. Production spanned from 2013 to 2021. Under the hood, you'll find a John Deere PowerTech 3029T 3.0L three-cylinder diesel engine producing 75 gross horsepower. This engine provided ample power for tasks around the farm. Transmission options included a 9F/3R SyncShuttle transmission, a 16F/16R PowrReverser, and a 32F/16R PowrReverser Plus, catering to different operational needs. The PTO delivers approximately 64 horsepower and offered a 540 RPM independent PTO. The hydraulic system provided a flow rate of around 15.8 GPM, powering two rear remotes. The 3-point hitch is a Category II hitch with a lift capacity of approximately 4,123 lbs. Common farming applications for the 5075M include row crop work, hay production, livestock operations, and light tillage. Compared to smaller models in the 5 series, the 5075M offers more power and hydraulic capacity, while being more compact than the larger 5E and 5R series tractors.
5075M Specifications
| Engine | John Deere PowerTech 75 HP 3.0L Diesel |
|---|---|
| PTO HP | 64 HP @ 540 RPM |
| Transmission | 9F/3R SyncShuttle, 16F/16R PowrReverser, 32F/16R PowrReverser Plus |
| Hydraulics | 15.8 GPM, 2 remotes |
| 3-Point Hitch | Category II, 4,123 lbs |
| Fuel Capacity | 25.1 gallons |
| Weight | 6,239 lbs |
| Years Produced | 2013-2021 |
5075M Maintenance Tips
- Check and change engine oil and filter every 250 hours of operation, using the recommended John Deere oil and filter.
- Inspect hydraulic fluid levels and filter regularly (every 500 hours). Replace hydraulic fluid and filter per manufacturer's recommendations to prevent system contamination and maintain optimal performance.
- Use high-quality diesel fuel and ensure the fuel filter is replaced at recommended intervals (around 500 hours) to prevent fuel system issues. Also, drain any water accumulation from the fuel/water separator.
- Before seasonal storage, fill the fuel tank to prevent condensation, change engine oil, grease all fittings, and disconnect the battery. Store the tractor in a dry place to prevent rust and corrosion.
5075M History & Background
The John Deere 5075M was part of John Deere's effort to provide modern, efficient utility tractors for the agricultural market. Introduced in 2013, it offered updated styling and improved features compared to previous models. While not revolutionary, it served as a reliable and versatile workhorse for many farmers during its production run.
Frequently Asked Questions
Which injector is suitable for the John Deere 5075M?
For the John Deere 5075M, the RE529390 - Injector is a suitable replacement.
What glow plug is recommended for the John Deere 5075M?
The recommended glow plug for the John Deere 5075M is the RE505867 - Glow Plug.
Which fuel/water separator filter is recommended for the John Deere 5075M?
The RE546336 - Filter, Separator, Fuel/Water is a suitable option for the John Deere 5075M.
What are some common replacement parts for the John Deere 5075M?
Common replacement parts for the John Deere 5075M include the RE533026 - Filter, Fuel, RE195491 - Filter, Cab Air, RE61717 - Switch, Ignition, AL78021 - Mirror Head, and L158186 - Pin, Lower Lift Link.

T26321 - Lower Bushing
SKU: T26321
69 in stock

T24534 - Pan Gasket
SKU: T24534
36 in stock

T20328 - Oil Filler Cap Gasket
SKU: T20328
48 in stock

RE66271 - Piston Rings
SKU: RE66271
45 in stock

RE560683 - Fuel Bowl
SKU: RE560683
191 in stock

RE537940 - Idler Pulley
SKU: RE537940
113 in stock

RE507287 - Injector Nozzle
SKU: RE507287
Out of stock

RE27348 - Connecting Rod (Std) Bearing
SKU: RE27348
1575 in stock

T20094 - Crankshaft Gear
SKU: T20094
5 in stock

T20073 - Camshaft Follower
SKU: T20073
131 in stock

T20070 - Camshaft Gear
SKU: T20070
13 in stock

T20034 - Upper Bushing
SKU: T20034
21 in stock

T20006 - Exhaust Manifold Gasket
SKU: T20006
834 in stock

RE65912 - Thrust (.010") Bearing
SKU: RE65912
73 in stock

RE65911 - Main (.010") Bearing
SKU: RE65911
721 in stock

RE65909 - Connecting Rod (.010") Bearing
SKU: RE65909
79 in stock

RE65908 - Connecting Rod (Std) Bearing
SKU: RE65908
7182 in stock

RE65168 - Thrust (Std) Bearing
SKU: RE65168
627 in stock

RE65165 - Main (Std) Bearing
SKU: RE65165
6921 in stock

RE61767 - Oil w/ Gasket Cooler
SKU: RE61767
1 in stock

RE60062 - Pencil Injector
SKU: RE60062
68 in stock

RE59296 - 5 Plate Engine Oil Cooler
SKU: RE59296
57 in stock

RE538127 - Fuel Temperature Sensor
SKU: RE538127
6 in stock

RE537639 - Manifold Air Pressure Sensor
SKU: RE537639
255 in stock
