John Deere 5070M Tractor Parts
Browse John Deere 5070M Tractor replacement parts. Everything from routine maintenance items to hard-to-find components.
The John Deere 5070M, manufactured from 2009 to 2015, is a versatile utility tractor renowned for its reliability and performance. Powered by a John Deere PowerTech 4.5L diesel engine producing 70 horsepower, the 5070M delivers ample power for a variety of tasks. Its strong PTO, rated at 58 horsepower, made it a popular choice for farmers needing a dependable tractor for haying, loader work, and general farm duties.
About the 5070M
The John Deere 5070M was introduced in 2009 as part of the 5M series, replacing some of the earlier 5000 series models. Production continued until 2015. This tractor is equipped with a John Deere PowerTech 4045T 4.5L four-cylinder turbocharged diesel engine, delivering a rated 70 engine horsepower. The engine's robust design and reliable performance are hallmarks of the 5070M. Operators had several transmission options including a SyncShuttle transmission with 9 forward and 3 reverse gears or a PowrReverser transmission with 9 forward and 9 reverse gears for enhanced maneuverability. The PTO is rated at 58 horsepower, offering both 540 RPM and optional 540/540E RPM speeds. The hydraulic system provides a flow rate of around 15.9 GPM to power implements effectively. A Category II 3-point hitch provides a lift capacity of approximately 4,149 lbs. Common applications for the 5070M include hay production (mowing, baling, raking), livestock operations (feeding, manure handling), loader work, and light tillage. What distinguishes the 5070M is its balance of power, versatility, and operator comfort, making it a valuable asset for small to medium-sized farming operations.
5070M Specifications
| Engine | John Deere PowerTech 70 HP 4.5L Diesel |
|---|---|
| PTO HP | 58 HP @ 540/540E RPM |
| Transmission | SyncShuttle/PowrReverser 9F/3R or 9F/9R |
| Hydraulics | 15.9 GPM, 2 remotes |
| 3-Point Hitch | Category II, 4,149 lbs lift capacity |
| Fuel Capacity | 29.1 gallons |
| Weight | 7,748 lbs |
| Years Produced | 2009-2015 |
5070M Maintenance Tips
- Change engine oil and filter every 250 hours of operation using the recommended John Deere oil and filter.
- Regularly inspect hydraulic fluid levels and check for leaks. Change hydraulic filters according to the manufacturer's recommendations (usually every 500 hours).
- Use clean, high-quality diesel fuel and add a fuel stabilizer during seasonal storage to prevent fuel degradation and injector clogging.
- Before storing the tractor for the winter, drain the fuel tank, replace fuel filters, and grease all lubrication points to prevent rust and corrosion.
5070M History & Background
The John Deere 5070M was launched in 2009, representing an upgrade in the utility tractor segment. It offered improved engine technology and operator comfort compared to previous models. The 5070M played a significant role in helping farmers with various tasks, solidifying John Deere's reputation for producing reliable and versatile agricultural equipment.
Frequently Asked Questions
Which water pump fits the John Deere 5070M?
For the John Deere 5070M, the recommended replacement water pump is the RE500734 - Water Pump.
What replacement alternator is compatible with the John Deere 5070M?
A compatible replacement alternator for the John Deere 5070M is the AL166646 - Alternator.
Which fuel filter is recommended for the John Deere 5070M?
For the John Deere 5070M, the recommended fuel filter is the AL153517 - Fuel Filter.
What are common replacement parts for the John Deere 5070M?
For the John Deere 5070M, frequently needed replacement parts include the RE195491 - Filter, Cab Air, the RE61717 - Switch; Ignition, the AL78021 - Mirror Head; LH/RH Outer Rear View, the AL156090 - Tensioner, Belt, the RE65908 - Bearing, Connecting Rod (Std), and the WL338 - Work Lamp, LED; Flood.

RE65912 - Thrust (.010") Bearing
SKU: RE65912
73 in stock

RE65911 - Main (.010") Bearing
SKU: RE65911
721 in stock

RE65909 - Connecting Rod (.010") Bearing
SKU: RE65909
79 in stock

RE65908B - Connecting Rod (.020") Bearing
SKU: RE65908B
8 in stock

RE65908 - Connecting Rod (Std) Bearing
SKU: RE65908
7182 in stock

RE65836 - Water Temp Sender Switch
SKU: RE65836
71 in stock

RE65168B - Thrust (.020") Bearing
SKU: RE65168B
14 in stock

RE65168 - Thrust (Std) Bearing
SKU: RE65168
627 in stock

RE65165 - Main (Std) Bearing
SKU: RE65165
6921 in stock

RE59810 - Front Crankshaft Seal
SKU: RE59810
61 in stock

RE548734-N - Turbocharger
SKU: RE548734-N
43 in stock

RE548734 - Turbocharger
SKU: RE548734
22 in stock

RE531801 - Injector
SKU: RE531801
9 in stock

RE516553 - Fuel Filter Seal Kit
SKU: RE516553
232 in stock

RE51650 - Sediment Bowl
SKU: RE51650
279 in stock

RE508317 - W/ Adjusting Screw Rocker Arm
SKU: RE508317
64 in stock

RE504914 - Engine Oil Pump
SKU: RE504914
62 in stock

RE503242 - Temperature Switch
SKU: RE503242
109 in stock

RE503208 - Turbo Oil Inlet Hose
SKU: RE503208
225 in stock

RE502740 - Engine Oil Dipstick
SKU: RE502740
18 in stock

RE500002 - CONNECTING ROD
SKU: RE500002
24 in stock

R80135 - Oil Filler Cap Gasket
SKU: R80135
23 in stock

RE271441 - LH/RH Straight Tie Rod
SKU: RE271441
27 in stock

RE271437 - Tie Rod Assembly
SKU: RE271437
89 in stock
