John Deere 4755 Tractor Parts

4755 parts and accessories

The John Deere 4755, manufactured from 1989 to 1992, was a popular choice for farmers needing a reliable and powerful tractor. Powered by a 7.6L diesel engine producing around 172 horsepower, this workhorse offered a PTO horsepower of approximately 145. Its robust design and advanced features for the time solidified its place in agricultural history.

The John Deere 4755 was introduced in 1989 as part of the '55 Series' tractors, replacing the earlier '50 Series'. Production continued until 1992. The heart of the 4755 is a John Deere 7.6L (466 cu in) 6-cylinder diesel engine, delivering approximately 172 horsepower. This engine provided ample power for a variety of demanding tasks. Transmission options included a 15-speed Power Shift. It features an independent PTO with approximately 145 PTO horsepower, offering both 540 and 1000 RPM speeds. The hydraulic system boasts a capacity of around 29 GPM, with multiple remote options for implements. A Category II 3-point hitch provides a substantial lift capacity. The 4755 was commonly used for row crop farming, hay production, livestock operations, and various tillage tasks. Compared to other models in the lineup, the 4755 offered a sweet spot between power and maneuverability, making it a versatile choice for medium to large-sized farms.

Specifications

Engine	John Deere 7.6L Diesel 172 HP
PTO HP	145 HP @ 540/1000 RPM
Transmission	15-speed Power Shift
Hydraulics	29 GPM, 2-4 remotes
3-Point Hitch	Category II, 8,427 lbs lift capacity
Fuel Capacity	73 gallons
Weight	15,400 lbs
Years Produced	1989-1992

Maintenance Tips

Change engine oil and filter every 250 hours of operation, using the recommended oil type and John Deere filter.
Inspect and maintain hydraulic fluid levels and filters according to the operator's manual, paying attention to any signs of contamination.
Regularly inspect and clean the fuel system, including fuel filters, to prevent clogging and ensure optimal engine performance.
Before seasonal storage, completely fill the fuel tank, add a fuel stabilizer, and disconnect the battery to prevent corrosion and degradation.

History & Background

The John Deere 4755 was introduced in 1989 as part of the '55 Series', representing a significant advancement in tractor technology for the time. This model helped bridge the gap between older mechanical tractors and the more technologically advanced machines of the future. Its popularity solidified John Deere's position as a leading manufacturer of agricultural equipment.

Frequently Asked Questions

What engine is in the John Deere 4755?

The John Deere 4755 is equipped with a John Deere 7.6L (466 cubic inch) 6-cylinder turbocharged diesel engine producing approximately 172 horsepower.

What is the PTO horsepower on a 4755?

The PTO horsepower rating for the John Deere 4755 is approximately 145 HP, and it offers both 540 and 1000 RPM PTO speeds.

What oil filter fits the 4755?

The oil filter commonly used on the John Deere 4755 is a John Deere part number AR73180. Cross-references include Wix 51794 or equivalent.

What are common parts needed for the 4755?

Common wear parts for the John Deere 4755 include engine oil filters (AR73180), fuel filters (AR58929), hydraulic filters (AH128018), fan belts, hydraulic seals, tie rod ends, and clutch components.
