John Deere 4630 Tractor Parts

Shop John Deere 4630 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.

The John Deere 4630, manufactured from 1973 to 1977, was a powerful and versatile tractor popular among farmers. It was powered by a robust 150 horsepower diesel engine, providing ample power for various agricultural tasks. With a PTO horsepower of around 125, the 4630 proved its reliability and efficiency, becoming a favorite for row crop operations and general farm work.

About the 4630

The John Deere 4630 was introduced in 1973 as part of the '30 Series' tractors, succeeding the 4620. Production continued until 1977. This model was equipped with a John Deere 6.6L (404 cu-in) six-cylinder diesel engine, delivering approximately 150 horsepower. The engine's robust design made it ideal for demanding farm tasks. Transmission options included a Quad-Range transmission (16 forward and 6 reverse gears) and a Power Shift transmission (8 forward and 4 reverse gears). The PTO delivered around 125 horsepower and offered both 540 and 1000 RPM options, allowing for versatility with different implements. Hydraulic capacity was around 30 GPM with typically two remote valves available. The 3-point hitch was a Category II, offering a lift capacity of around 6,700 lbs. Common farming applications included row crop work, hay production, livestock operations, and tillage. The 4630 was distinguished from other models in the lineup by its higher horsepower and larger frame, making it suitable for larger farms and more demanding tasks compared to models like the 4430 or 4230.

4630 Specifications

EngineJohn Deere 6.6L (404 ci) 150 HP Diesel
PTO HP125 HP @ 540/1000 RPM
TransmissionQuad-Range (16x6) or Power Shift (8x4)
Hydraulics30 GPM, 2 remotes
3-Point HitchCategory II, 6700 lbs lift capacity
Fuel Capacity46 gallons
Weight14,180 lbs
Years Produced1973-1977

4630 Maintenance Tips

  • Engine Oil & Filter: Change engine oil and filter every 250 hours of operation using a high-quality oil that meets John Deere specifications. Regularly check oil levels.
  • Hydraulic System: Inspect hydraulic fluid levels regularly and change hydraulic filters every 500 hours to prevent contamination and maintain hydraulic performance.
  • Fuel System: Use clean, high-quality diesel fuel and replace fuel filters regularly to prevent fuel system issues. Consider adding a fuel stabilizer during seasonal storage.
  • Seasonal Storage: Before storing the tractor for the off-season, drain the fuel tank, add fuel stabilizer to the remaining fuel, grease all lubrication points, and store it in a dry, sheltered location.

4630 History & Background

The John Deere 4630 was released in 1973 as part of the updated '30 Series', providing a significant power upgrade over its predecessor. It represented a shift towards larger, more powerful tractors designed for increased productivity on modern farms. Its lasting impact can be seen in its continued use today.

Frequently Asked Questions

What connecting rod capscrew fits the John Deere 4630 engine?

The R66452 - Capscrew, Connecting Rod is a suitable replacement for the John Deere 4630 engine.

Which PTO clutch disc is recommended for the John Deere 4630?

For the John Deere 4630, the RE23286 - Disc, PTO Clutch is a recommended replacement part.

What oil filter fits the 4630?

The AR50041 - Filter, Diesel Fuel is a recommended oil filter for the John Deere 4630.

What are common parts needed for the 4630?

Showing 1-24 of 558 products
