John Deere 4230 Tractor Parts

4230 parts and accessories

The John Deere 4230, manufactured from 1973 to 1977, was a popular choice for farmers seeking a reliable and versatile tractor. Powered by a robust 80-horsepower diesel engine, the 4230 delivered ample power for various farming tasks. Its PTO horsepower of around 70 made it well-suited for operating implements like mowers, balers, and rotary cutters.

The John Deere 4230 was introduced in 1973 as part of the '30 Series' tractors, replacing the earlier 4020. Production continued through 1977. The heart of the 4230 is a John Deere 404 CID (6.6L) 4-cylinder diesel engine producing approximately 80 horsepower. A gasoline version was also available, but far less common. The tractor features a Syncro Range transmission with 8 forward and 2 reverse gears, providing a good range of speeds for various field operations. PTO horsepower is rated at approximately 70 HP at 540 RPM, with an optional 1000 RPM PTO available. The hydraulic system delivers around 25 GPM and typically includes two remote valves for implement control. The 3-point hitch is a Category II, capable of lifting around 4,700 lbs. The 4230 was commonly used for row crop work, hay production, livestock operations, and tillage. What set it apart from smaller models in the lineup was its increased power and hydraulic capacity, while remaining more compact and maneuverable than larger frame tractors.

Specifications

Engine	John Deere 404 CID (6.6L) 80 HP Diesel
PTO HP	70 HP @ 540 RPM
Transmission	Syncro Range 8 Forward, 2 Reverse
Hydraulics	25 GPM, 2 remotes
3-Point Hitch	Category II, 4700 lbs lift capacity
Fuel Capacity	28 gallons
Weight	8,250 lbs
Years Produced	1973-1977

Maintenance Tips

Engine Oil & Filter: Change engine oil and filter every 250 hours using the recommended John Deere oil specification. Regularly inspect the oil level and condition.
Hydraulic System: Check hydraulic oil levels and inspect for leaks. Replace hydraulic filters every 500 hours to maintain system performance and prevent damage.
Fuel System: Use clean, high-quality diesel fuel and replace the fuel filter every 250 hours. Drain the fuel/water separator regularly to prevent water contamination.
Seasonal Storage: Before storing the tractor for extended periods, drain the fuel tank, add fuel stabilizer, and lubricate all grease fittings. Disconnect the battery and store it in a cool, dry place.

History & Background

The John Deere 4230 was introduced in 1973 as part of the '30 Series,' representing a significant upgrade in operator comfort and hydraulic performance compared to the previous '20 Series.' While not a revolutionary design change, the 4230 built upon the proven reliability of its predecessors and solidified John Deere's position in the agricultural machinery market.

Frequently Asked Questions

What engine is in the John Deere 4230?

The John Deere 4230 is equipped with a John Deere 404 cubic inch (6.6L) 4-cylinder diesel engine producing approximately 80 horsepower.

What is the PTO horsepower on a 4230?

The John Deere 4230 has a PTO horsepower rating of approximately 70 horsepower. It typically operates at 540 RPM, with an optional 1000 RPM PTO available on some models.

What oil filter fits the 4230?

The common oil filter for the John Deere 4230 is a John Deere AR50041 or equivalent. Cross-references include Wix 51794 and Fram PH3754.

What are common parts needed for the 4230?

Common wear parts for the John Deere 4230 include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic cylinder seal kits, steering linkage components, and clutch disc or pressure plate parts depending on usage.
