John Deere 4040 Tractor Parts
Shop John Deere 4040 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.
The John Deere 4040, manufactured from 1978 to 1983, was a popular utility tractor known for its reliability and versatility. Powered by a robust John Deere diesel engine, it delivered around 80 horsepower at the PTO, making it well-suited for a variety of farming tasks. Farmers appreciated its comfortable operator station and strong hydraulic system, contributing to its lasting legacy.
About the 4040
The John Deere 4040 was introduced in 1978 as part of the 'Iron Horse' lineup, replacing the earlier John Deere 4030. It was produced until 1983, when it was succeeded by the John Deere 4050. The 4040 is powered by a John Deere 6.4L (390 cu in) 6-cylinder diesel engine, producing approximately 85 engine horsepower and 75 PTO horsepower. The transmission options included a SyncroRange transmission with 8 forward and 4 reverse gears, or the optional Quad-Range transmission with 16 forward and 6 reverse gears, which provided a wider range of working speeds. The PTO offered both 540 and 1000 RPM options, allowing it to power a variety of implements. Its hydraulic system delivered around 26 GPM flow to power implements and the 3-point hitch, which was Category II rated. It was commonly used for row crop operations, hay baling, livestock feeding, and light tillage. Unlike some larger models, it was compact enough for smaller farms, while still providing enough power for demanding tasks.
4040 Specifications
| Engine | John Deere 6.4L (390 ci) 85 HP Diesel |
|---|---|
| PTO HP | 75 HP @ 540/1000 RPM |
| Transmission | SyncroRange or Quad-Range (8F/4R or 16F/6R) |
| Hydraulics | 26 GPM, 2 remotes |
| 3-Point Hitch | Category II, 5300 lbs lift capacity |
| Fuel Capacity | 34 gallons |
| Weight | 9,900 lbs |
| Years Produced | 1978-1983 |
4040 Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 250 hours using a high-quality oil meeting John Deere specifications. Check oil levels regularly.
- Hydraulic System: Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours. Use only John Deere-approved hydraulic fluid.
- Fuel System: Drain water and sediment from the fuel tank regularly to prevent fuel system issues. Replace the fuel filter annually or every 500 hours.
- Seasonal Storage: Before storing the tractor for the winter, fill the fuel tank, add fuel stabilizer, and disconnect the battery. Consider changing the engine oil and filter to protect the engine during storage.
4040 History & Background
The John Deere 4040 was introduced in 1978 as part of a significant model refresh from John Deere. It continued the tradition of reliable and versatile utility tractors from John Deere. Its popularity cemented its place as a workhorse tractor for many farms across the country.
Frequently Asked Questions
Which connecting rod bearings are suitable for the John Deere 4040?
The standard connecting rod bearing for the John Deere 4040 is RE27348 - Bearing, Connecting Rod (Std).
Which fuel transfer pump is recommended for the John Deere 4040?
For the John Deere 4040, the recommended fuel lift transfer pump is RE27667 - Pump, Fuel Lift Transfer.
Which diesel fuel filter is suitable for the John Deere 4040?
The recommended diesel fuel filter for the John Deere 4040 is AR50041 - Filter, Diesel Fuel.
What are common replacement parts needed for the John Deere 4040?
Common wear and replacement parts for the John Deere 4040 include the AR94516 - Disc, Direct Drive Clutch, R111122 - Brake Pads, Metallic, R83021 - Gasket, Exhaust Manifold, R79779 - Seal, Load Control (Ref. 3), JD9449 - Bearing, Pilot: .669" I.D., and AR64422 - Switch, Flasher Control.

VTK17903 - Valve Train Kit (Std)
SKU: VTK17903
3 in stock

TY22423 - Bulk Engine Oil Cooler Hose
SKU: TY22423
40 in stock

T26321 - Lower Bushing
SKU: T26321
69 in stock

T20328 - Oil Filler Cap Gasket
SKU: T20328
48 in stock

RE520036 - Rear Crankshaft Seal
SKU: RE520036
236 in stock

RE27667 - Fuel Lift Transfer Pump
SKU: RE27667
2834 in stock

RE27348 - Connecting Rod (Std) Bearing
SKU: RE27348
1575 in stock

RE19778 - Turbocharger
SKU: RE19778
133 in stock

T20129 - Valve Stem Cap
SKU: T20129
155 in stock

T20077 - Valve Keeper
SKU: T20077
1248 in stock

T20073 - Camshaft Follower
SKU: T20073
131 in stock

T20006 - Exhaust Manifold Gasket
SKU: T20006
834 in stock

SE500105 - Injector
SKU: SE500105
43 in stock

RE62777 - Exhaust Manifold; Outer (2/Pack) Gasket
SKU: RE62777
896 in stock

RE53422 - Crankshaft w/ A-R26049 Gear
SKU: RE53422
42 in stock

RE524107 - Overhaul without Seals Gasket Set
SKU: RE524107
1 in stock

RE524105 - Oil Cooler To Block Gasket
SKU: RE524105
205 in stock

RE52020 - Oil Pump Repair Kit
SKU: RE52020
23 in stock

RE48818 - Piston Rings
SKU: RE48818
63 in stock

RE37503 - Pencil Injector
SKU: RE37503
101 in stock

RE35685 - Oil Pump
SKU: RE35685
141 in stock

RE31929 - Engine Oil Cooler
SKU: RE31929
27 in stock

RE30250 - Piston Liner Kit
SKU: RE30250
115 in stock

RE27786 - Leak-Off Fuel Line
SKU: RE27786
488 in stock
