John Deere 3141 Tractor Parts

3141 parts and accessories

The John Deere 3141 tractor, manufactured between 1985 and 1991, became a popular choice for farmers due to its reliable performance and versatility. Powered by a robust 66 horsepower diesel engine, it provided ample power for a variety of tasks. With a PTO horsepower rating of 60, the 3141 was well-suited for operating implements like mowers, balers, and rotary cutters, making it an excellent all-around agricultural tractor.

The John Deere 3141 was introduced in 1985 as part of the John Deere utility tractor lineup, designed to provide a balance of power and maneuverability for a wide range of farming applications. Production continued until 1991. The 3141 is equipped with a Yanmar 4T84 diesel engine, producing approximately 66 horsepower with a displacement of 134 cubic inches. It features a gear-type transmission offering a variety of speeds to suit different tasks. The tractor's PTO delivers around 60 horsepower at 540 RPM, enabling it to efficiently power various implements. Hydraulics provide around 12 GPM flow, with optional remotes for implement control. The 3-point hitch is a Category II, providing flexibility in implement attachment. The 3141 was commonly used in row crop applications, hay production, livestock operations, and light tillage work. Its size and power positioned it between smaller utility tractors and larger row crop models, making it a versatile and cost-effective option for many farms.

Specifications

Engine	Yanmar 4T84 66 HP 134 ci Diesel
PTO HP	60 HP @ 540 RPM
Transmission	Gear Type 8 Forward, 4 Reverse
Hydraulics	12 GPM, Optional Remotes
3-Point Hitch	Category II, 2600 lbs lift capacity
Fuel Capacity	17 gallons
Weight	5300 lbs
Years Produced	1985-1991

Maintenance Tips

Engine Oil & Filter: Change engine oil and filter every 250 hours using a high-quality diesel engine oil and a John Deere-recommended filter.
Hydraulic System: Regularly inspect hydraulic fluid levels and check for leaks. Change the hydraulic fluid and filter according to the manufacturer's recommendations to prevent contamination and maintain optimal performance.
Fuel System: Use clean, high-quality diesel fuel. Replace the fuel filter annually or every 500 hours to prevent fuel system clogging.
Seasonal Storage: Before storing the tractor for an extended period, stabilize the fuel with a fuel stabilizer, grease all fittings, and disconnect the battery to prevent corrosion.

History & Background

The John Deere 3141 was launched in 1985, representing a solid utility tractor offering in John Deere's agricultural equipment lineup. There were no major redesigns or updates throughout its production run from 1985-1991. This tractor played a significant role in allowing small to medium-sized farms to efficiently perform various tasks, contributing to overall agricultural productivity.

Frequently Asked Questions

What engine is in the John Deere 3141?

The John Deere 3141 is equipped with a Yanmar 4T84 diesel engine, producing approximately 66 horsepower with a displacement of 134 cubic inches.

What is the PTO horsepower on a 3141?

The PTO horsepower on the John Deere 3141 is rated at 60 horsepower, operating at 540 RPM.

What oil filter fits the 3141?

The recommended oil filter for the John Deere 3141 is a John Deere filter part number AM101207. A common cross-reference is Fram PH3614 or Wix 51348.

What are common parts needed for the 3141?

Common wear parts for the John Deere 3141 include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic seals, tie rod ends, and clutch components.
