John Deere 2520 Tractor Parts

Find parts for your John Deere 2520 Tractor. We stock OEM and quality aftermarket replacements ready to ship.

The John Deere 2520 was a popular compact utility tractor manufactured from 2003 to 2005. Powered by a Yanmar 3TNV76 diesel engine producing around 31 horsepower, the 2520 offered a reliable and efficient workhorse for various farm tasks. Its versatility and practical PTO horsepower made it a sought-after choice for small-scale farming operations and property maintenance.

About the 2520

The John Deere 2520 was introduced as part of John Deere's compact utility tractor lineup, aiming to provide robust performance in a smaller package. Produced from 2003 to 2005, it quickly became a favorite for its blend of power and maneuverability. The 2520 features a Yanmar 3TNV76 diesel engine, a liquid-cooled, 3-cylinder powerplant producing approximately 31 engine horsepower. This tractor is equipped with a hydrostatic transmission, offering infinite forward and reverse speeds controlled via two pedals. The independent rear PTO delivers approximately 24 PTO horsepower at 540 RPM. The hydraulic system boasts a flow rate of around 7.4 gallons per minute, providing ample power for implements. It features a Category 1 3-point hitch, capable of lifting approximately 1433 pounds. The 2520 was commonly used for tasks like mowing, light tillage, loader work, and operating various implements in row crop and hay operations. What sets it apart from other models in the John Deere lineup is its size and hydrostatic transmission, making it incredibly user-friendly and suitable for operators of all skill levels.

2520 Specifications

EngineYanmar 3TNV76 31 HP Diesel
PTO HP24 HP @ 540 RPM
TransmissionHydrostatic Infinite Forward/Reverse
Hydraulics7.4 GPM, 1 remotes
3-Point HitchCategory 1, 1433 lbs lift
Fuel Capacity6.6 gallons
Weight1610 lbs
Years Produced2003-2005

2520 Maintenance Tips

  • Change engine oil and filter every 200 hours of operation using the recommended John Deere engine oil and filter.
  • Regularly inspect and maintain the hydraulic system, checking for leaks and ensuring proper fluid levels. Replace the hydraulic filter every 400 hours of operation.
  • Use clean, high-quality diesel fuel and replace the fuel filter annually to prevent fuel system issues.
  • Before storing the tractor for extended periods, drain the fuel tank, add fuel stabilizer, and lubricate all grease fittings to prevent corrosion and ensure easy startup in the spring.

2520 History & Background

The John Deere 2520 was introduced in 2003 as a successor to previous compact tractor models, offering enhanced features and performance. This model was part of John Deere's initiative to provide versatile and reliable tractors for smaller farming operations and landowners. It made a significant impact by providing the utility of a larger tractor in a more compact and manageable size.

Frequently Asked Questions

Which connecting rod bearing fits the John Deere 2520?

The standard connecting rod bearing for the John Deere 2520 is RE27348 - Bearing, Connecting Rod (Std).

What fuel pump is recommended for the John Deere 2520?

For reliable fuel delivery on the 2520, the recommended fuel lift transfer pump is RE27667 - Pump, Fuel Lift Transfer.

What replacement brake pads are available for the John Deere 2520?

The R111122 - Brake Pads, Metallic are a suitable replacement for the John Deere 2520, offering durable stopping performance.

What are common parts needed for the 2520?

For routine maintenance and common repairs on the John Deere 2520, frequently needed items include the AT17387 - Filter, Diesel Fuel, RE37104 - Disc, Syncro for transmission repair, AR51584 - Tie Rod, Long Outer for steering adjustments, and RE336111 - Lamp, Worklight; LED, Flood. Additionally, clutch system maintenance may require the R26637 - Spring, Clutch Plate / Cover, Outer.

Showing 1-24 of 506 products
