John Deere 2240 Tractor Parts

Jump to Parts

The John Deere 2240 tractor, manufactured from 1976 to 1982, was a popular utility tractor known for its reliability and versatility. Powered by a 53-horsepower diesel engine, it delivered a robust 45 PTO horsepower, making it ideal for a variety of farm tasks. Farmers appreciated its manageable size and efficient performance in diverse agricultural applications.

The John Deere 2240 was introduced in 1976 as part of the 'Iron Horses' series, replacing earlier models and offering updated features. Production continued until 1982. The tractor is powered by a John Deere 3.9L (239 cu in) 4-cylinder diesel engine, producing approximately 53 engine horsepower. Some models were also available with a gasoline engine option. The engine features direct injection and is known for its fuel efficiency. The transmission options included a standard 8-speed gear transmission or an optional partial power shift transmission. The PTO delivers around 45 horsepower, typically at 540 RPM. The hydraulic system has a capacity of around 15 GPM, providing ample power for implements. It features a Category II 3-point hitch with a lift capacity of approximately 3300 lbs. Common farming applications included row crop cultivation, hay baling, livestock feeding, and light tillage. Compared to larger models like the 4440, the 2240 offered a smaller footprint and lower operating costs, making it a favorite among smaller farms and for utility work on larger operations.

Specifications

Engine	John Deere 3.9L (239 ci) 53 HP Diesel
PTO HP	45 HP @ 540 RPM
Transmission	8-speed gear or Partial Power Shift
Hydraulics	15 GPM, 2 remotes
3-Point Hitch	Category II, 3300 lbs
Fuel Capacity	24 gallons
Weight	5200 lbs
Years Produced	1976-1982

Maintenance Tips

Change the engine oil and filter every 125 hours of operation using high-quality engine oil that meets John Deere specifications.
Inspect and clean the hydraulic system filters regularly, and replace them according to the manufacturer's recommendations (typically every 500 hours), to prevent contamination and ensure proper hydraulic function.
Use clean, high-quality fuel and inspect the fuel filter regularly. Drain any water or sediment from the fuel tank to prevent fuel system problems, especially during seasonal storage.
Before storing the tractor for extended periods, fill the fuel tank to prevent condensation, lubricate all grease fittings, and disconnect the battery to prevent drainage. Consider using a fuel stabilizer.

History & Background

The John Deere 2240 was launched in 1976 as a versatile utility tractor designed to meet the needs of smaller farms and diverse agricultural tasks. There were no major redesigns during its production run, showcasing its solid design and engineering. The 2240 played a significant role in providing reliable and affordable power to farmers during a time of changing agricultural practices.

Frequently Asked Questions

What engine is in the John Deere 2240?

The John Deere 2240 is equipped with a John Deere 3.9L (239 cubic inch) 4-cylinder diesel engine producing approximately 53 horsepower.

What is the PTO horsepower on a 2240?

The PTO horsepower on a John Deere 2240 is approximately 45 horsepower, typically at 540 RPM.

What oil filter fits the 2240?

The John Deere 2240 uses a John Deere oil filter part number AR50041. Common cross-references include Fram PH3600 or Wix 51794.

What are common parts needed for the 2240?

Common parts needed for the John Deere 2240 include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic cylinder seal kits, steering components (tie rod ends), and clutch components (clutch disc, pressure plate).
