Case IH 826 Tractor Parts

826 parts and accessories

The Case IH 826 tractor, manufactured from 1969 to 1971, was a popular choice for farmers needing a reliable utility tractor. Powered by a 77 horsepower engine, its robust design and ample PTO horsepower made it suitable for a variety of tasks. Farmers appreciated its straightforward operation and dependable performance in diverse agricultural applications.

The Case IH 826 was introduced in 1969 and continued production through 1971. This model was known for its reliability and versatility in a wide range of farming operations. Under the hood, it featured an International Harvester C-291 6-cylinder diesel engine producing approximately 77 horsepower. The engine displaced 291 cubic inches. Transmission options included a gear-driven transmission with multiple speeds, providing good control for field work. The PTO delivered around 67 horsepower, available in 540 RPM configuration. Hydraulic capacity was sufficient for operating implements, providing adequate flow for implements and implements. It featured a Category II 3-point hitch, capable of handling a variety of implements. The Case IH 826 was commonly used in row crop operations, hay production, livestock farming, and light tillage work. It stood out for its balance of power, simplicity, and dependability within the Case IH lineup.

Specifications

Engine	International Harvester C-291 77 HP Diesel
PTO HP	67 HP @ 540 RPM
Transmission	Gear Drive, Multiple Speeds
Hydraulics	GPM varies based on configuration, up to 3 remotes
3-Point Hitch	Category II, Lift Capacity approx. 3800 lbs
Fuel Capacity	28 gallons
Weight	Approx. 7,500 lbs
Years Produced	1969-1971

Maintenance Tips

Engine Oil and Filter: Change the engine oil and filter every 125-250 hours, depending on operating conditions, using an oil that meets the specifications outlined in your operator's manual.
Hydraulic System Maintenance: Regularly check hydraulic fluid levels and inspect for leaks. Change hydraulic filters according to the manufacturer's recommendations (typically every 500 hours) to prevent contamination and ensure proper hydraulic function.
Fuel System Care: Use clean, high-quality fuel. Drain the fuel sediment bowl regularly to remove water and sediment. Consider using a fuel additive to prevent gelling in cold weather.
Seasonal Storage: Before storing the tractor for an extended period, drain the fuel tank or add a fuel stabilizer to prevent fuel degradation. Disconnect the battery and store it in a cool, dry place. Grease all lubrication points and inspect tires for proper inflation.

History & Background

The Case IH 826 was introduced in 1969 as part of International Harvester's lineup of utility tractors. It represented a blend of power and simplicity, catering to the needs of diverse farming operations. While its production run was relatively short, the 826 remains a respected and sought-after tractor among collectors and farmers.

Frequently Asked Questions

What engine is in the Case Ih 826?

The Case IH 826 is equipped with an International Harvester C-291 6-cylinder diesel engine producing around 77 horsepower and displacing 291 cubic inches.

What is the PTO horsepower on a 826?

The Case IH 826 delivers approximately 67 PTO horsepower at 540 RPM.

What oil filter fits the 826?

Common oil filter cross-references for the Case IH 826 include Wix 51794, Fram PH8A, and NAPA 1794. Always verify fitment with your parts supplier using your tractor's serial number.

What are common parts needed for the 826?

Common wear parts for the Case IH 826 include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic seals, steering components (tie rod ends), clutch discs, and pressure plates.
