Case IH 1896 Tractor Parts

1896 parts and accessories

The Case IH 1896 tractor, manufactured from 1972 to 1976, was a popular choice among farmers for its reliable performance and versatility. Powered by a robust 401 cubic inch diesel engine producing around 131 horsepower, the 1896 delivered ample power for various field operations. With a PTO horsepower of approximately 115, it efficiently handled implements, solidifying its reputation as a dependable workhorse in the agricultural landscape.

The Case IH 1896 was introduced in 1972 as part of the International Harvester lineup, continuing after the Case acquisition. Production ran until 1976, during which time the tractor gained a strong following due to its balance of power and reliability. The 1896 is powered by an International Harvester DT-402, a 401 cubic inch (6.6L) 6-cylinder diesel engine rated at approximately 131 horsepower. This engine provided sufficient power for demanding tasks like plowing and disking. The transmission is a gear-type transmission with options for either a 6-speed forward and 2-reverse gear configuration or a 12-speed forward and 4-reverse gear configuration. The PTO horsepower is around 115 HP, available in either 540 RPM or 1000 RPM options. Hydraulic capacity is approximately 16 GPM powering around 2-3 rear remotes. It features a Category II 3-point hitch, capable of lifting substantial implements. The 1896 was commonly used in row crop operations, hay production, livestock farming for tasks like baling and feeding, and various tillage applications. It distinguished itself from smaller models with its increased horsepower and heavier construction, providing greater capability for larger-scale farming operations. It stood out from larger models with its maneuverability.

Specifications

Engine	International Harvester DT-402 131 HP 401 ci Diesel
PTO HP	115 HP @ 540/1000 RPM
Transmission	Gear Type, 6F/2R or 12F/4R speeds
Hydraulics	16 GPM, 2-3 remotes
3-Point Hitch	Category II, 5100 lbs lift capacity
Fuel Capacity	47 gallons
Weight	12,470 lbs
Years Produced	1972-1976

Maintenance Tips

Engine Oil & Filter: Change engine oil and filter every 250 hours of operation using a high-quality diesel engine oil that meets the manufacturer's specifications.
Hydraulic System: Inspect hydraulic fluid levels regularly and change hydraulic filters every 500 hours or annually, whichever comes first, to prevent contamination and ensure optimal hydraulic performance. Check for leaks around cylinders and hoses.
Fuel System: Use clean, high-quality diesel fuel and replace fuel filters every 300 hours to prevent fuel system issues. Consider adding a fuel stabilizer during seasonal storage to prevent fuel degradation.

History & Background

The Case IH 1896 emerged as a key model in the early 1970s, representing a blend of power and versatility for farmers. It did not have any major redesigns during its production run. Its success solidified the 96-series reputation for rugged reliability in an era of rapidly advancing agricultural technology.

Frequently Asked Questions

What engine is in the Case Ih 1896?

The Case IH 1896 is equipped with an International Harvester DT-402, a 401 cubic inch (6.6L) 6-cylinder diesel engine producing approximately 131 horsepower.

What is the PTO horsepower on a 1896?

The PTO horsepower on the Case IH 1896 is approximately 115 HP, with options for both 540 RPM and 1000 RPM.

What oil filter fits the 1896?

The Case IH 1896 typically uses a Fram PH25A or equivalent oil filter. Other cross-references include Wix 51794 and Napa 1794. Always verify compatibility with your specific tractor's configuration.

What are common parts needed for the 1896?

Commonly needed parts for the Case IH 1896 include engine oil filters, fuel filters, hydraulic filters, fan belts, radiator hoses, hydraulic cylinder seal kits, steering components (tie rod ends, ball joints), and clutch discs/pressure plates.
