Massey Ferguson SUPER-90 Tractor Parts

SUPER 90 parts and accessories

The Massey Ferguson Super 90, produced from 1961 to 1964, was a popular workhorse on farms across North America. Powered by a reliable Perkins diesel or Continental gasoline engine producing around 52 horsepower, and delivering approximately 48 PTO horsepower, the Super 90 was favored for its robust build and versatility in various agricultural tasks. Its blend of power and simplicity made it a favorite among farmers.

The Massey Ferguson Super 90 was introduced in 1961 as a successor to the MF 90, offering increased power and improved features. Production continued until 1964. It was available with either a Perkins AD4.192 diesel engine, rated at approximately 52 horsepower, or a Continental GB251 gasoline engine of similar power. The diesel engine had a displacement of 192 cubic inches, while the Continental gasoline engine was 251 cubic inches. The transmission was typically a 6-speed manual gearbox, providing ample gear choices for diverse field conditions. PTO horsepower was around 48, with a standard 540 RPM PTO. Hydraulic capacity was around 6 GPM powering a category I 3-point hitch. Commonly used for row crop work, hay baling, and general farm duties, the Super 90 distinguished itself with improved hydraulics and a more refined operator platform compared to earlier Massey Ferguson models. It offered a balance of power and fuel efficiency that was attractive to farmers of the time.

Specifications

Engine	Perkins AD4.192 52 HP Diesel or Continental GB251 52 HP Gasoline
PTO HP	48 HP @ 540 RPM
Transmission	6-speed Manual
Hydraulics	6 GPM, 2 remotes (optional)
3-Point Hitch	Category I, 2700 lbs lift capacity
Fuel Capacity	17 gallons
Weight	4800 lbs
Years Produced	1961-1964

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 100-150 hours of operation, using a quality oil that meets the manufacturer's specifications. This ensures proper engine lubrication and prolongs engine life.
Hydraulic System Maintenance: Check the hydraulic fluid level regularly and change the hydraulic filter every 300 hours. Use the correct type of hydraulic fluid to prevent damage to the hydraulic components.
Fuel System Care: Use clean, fresh fuel and add a fuel stabilizer, especially during seasonal storage. Drain the fuel tank and carburetor bowl to prevent gumming and corrosion.
Seasonal Storage: Before storing the tractor for extended periods, grease all fittings, disconnect the battery, and cover the tractor to protect it from the elements.

History & Background

The Massey Ferguson Super 90 was introduced in 1961 to improve on the features of the MF 90. The Super 90 was a popular utility tractor in its era. It represented a step forward in power and refinement for Massey Ferguson's tractor lineup.

Frequently Asked Questions

What engine is in the Massey Ferguson SUPER 90?

The Massey Ferguson Super 90 came with either a Perkins AD4.192 diesel engine or a Continental GB251 gasoline engine, both rated at approximately 52 horsepower. The Perkins engine has a displacement of 192 cubic inches, while the Continental is 251 cubic inches.

What is the PTO horsepower on a SUPER 90?

The PTO horsepower on a Massey Ferguson Super 90 is approximately 48 HP at 540 RPM.

What oil filter fits the SUPER 90?

The oil filter for the Perkins diesel engine is commonly cross-referenced to Fram PH2951 or equivalent. For the Continental gasoline engine, check your parts manual or consult with a parts supplier. Always verify the fit before installation.

What are common parts needed for the SUPER 90?

Common parts needed for the Massey Ferguson Super 90 include engine oil filters, fuel filters, hydraulic filters, fan belts, radiator hoses, hydraulic pump seals, steering linkage components, clutch discs, pressure plates, and throwout bearings.
