John Deere SE6610 Tractor Parts

SE6610 parts and accessories

The John Deere SE6610 tractor, manufactured from 2000 to 2003, was a popular choice for farmers needing a reliable workhorse. Powered by a John Deere 6.8L diesel engine producing approximately 125 horsepower, the SE6610 delivered ample power for various farming tasks. Its robust build and a PTO horsepower rating of around 105 hp made it well-suited for handling demanding implements and attachments.

The John Deere SE6610 was produced between 2000 and 2003, filling a gap in John Deere's utility tractor lineup. It was based on the European 6010 series. Under the hood is a John Deere 6.8L 6-cylinder diesel engine, rated at approximately 125 engine horsepower. This engine delivers a potent combination of power and efficiency, crucial for demanding agricultural operations. Displacement is 6.8 liters (414 cubic inches). The SE6610 features a partial power shift transmission (PowrQuad), offering a range of speeds for optimal performance in various field conditions. PTO horsepower is approximately 105 hp, available at 540/1000 RPM. The hydraulic system delivers around 24.6 GPM, with typically two or three rear remotes. It features a Category II 3-point hitch, capable of lifting around 6,500 lbs. This tractor was commonly used for row crop applications, hay baling, livestock feeding, and general tillage. The SE6610 distinguishes itself from smaller models with its larger frame, more powerful engine, and heavier-duty components, making it suitable for more intensive farming operations. The SE6610 combines the functionality of a utility tractor with the muscle of a row crop model.

Specifications

Engine	John Deere 6.8L 125 HP Diesel
PTO HP	105 HP @ 540/1000 RPM
Transmission	PowrQuad partial power shift, 16 forward/16 reverse
Hydraulics	24.6 GPM, 2-3 remotes
3-Point Hitch	Category II, 6,500 lbs lift capacity
Fuel Capacity	48.8 gallons
Weight	12,787 lbs
Years Produced	2000-2003

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250 hours using a high-quality oil meeting John Deere specifications (JDQ-78). Always replace the oil filter (e.g., John Deere RE504836) at each oil change.
Hydraulic System: Regularly check the hydraulic fluid level and inspect for leaks. Change the hydraulic filter (e.g., John Deere AL117524) every 500 hours to prevent contamination and maintain optimal hydraulic performance.
Fuel System: Use clean, high-quality diesel fuel. Inspect and replace the fuel filter (e.g., John Deere RE522878) annually, or more frequently if fuel contamination is suspected, to protect the fuel injection system.
Seasonal Storage: Before storing the tractor for an extended period, fill the fuel tank to prevent condensation. Add a fuel stabilizer. Disconnect the battery and store it in a cool, dry place. Lubricate all grease fittings.

History & Background

The John Deere SE6610 was introduced in 2000 as part of the SE series, based on the European-designed 6010 series tractors. There were no major redesigns during its production run from 2000 to 2003. The SE6610 was significant for offering North American farmers a robust and versatile tractor suitable for a wide range of tasks in a compact package.

Frequently Asked Questions

What engine is in the John Deere SE6610?

The John Deere SE6610 is equipped with a John Deere 6.8L 6-cylinder diesel engine producing approximately 125 horsepower.

What is the PTO horsepower on a SE6610?

The PTO horsepower on the John Deere SE6610 is approximately 105 horsepower, available at both 540 and 1000 RPM.

What oil filter fits the SE6610?

The recommended oil filter for the John Deere SE6610 is John Deere RE504836. Common cross-references include Baldwin B7239 and Wix 51791.

What are common parts needed for the SE6610?

Common wear parts for the John Deere SE6610 include engine oil filters, fuel filters, hydraulic filters, belts (fan, alternator), hydraulic seals, steering components (tie rod ends), and clutch parts (pressure plate, clutch disc).
