John Deere 9200 Tractor Parts

9200 parts and accessories

The John Deere 9200 tractor, manufactured from 1996 to 2000, was a powerful workhorse for large-scale farming operations. Equipped with a robust Cummins N14 diesel engine producing between 305 and 360 horsepower, it delivered impressive performance for demanding tasks. Its high PTO horsepower made it a popular choice for pulling large implements and powering heavy machinery on large acreage farms.

The John Deere 9200 was part of John Deere's 9000 series of articulated 4WD tractors, introduced in 1996. This series aimed to provide farmers with increased power and productivity for large-scale operations. The 9200 featured a Cummins N14 diesel engine, available in various horsepower ratings ranging from 305 to 360 HP. Engine displacement was 14.0L (855 cu in). It came standard with a 12-speed powershift transmission. The PTO horsepower was rated at around 220-265 HP, with a 1000 RPM PTO speed. Hydraulic capacity was approximately 45 GPM, often equipped with 3-4 remote valves. While not typically equipped with a 3-point hitch from the factory, aftermarket hitches could be added. Common applications included heavy tillage, pulling large planters or air seeders, and operating other demanding implements. The 9200 distinguished itself from other models in the lineup with its balance of power and efficiency, making it ideal for large-acreage operations requiring a reliable and versatile tractor.

Specifications

Engine	Cummins N14 305-360 HP Diesel
PTO HP	220-265 HP @ 1000 RPM
Transmission	Powershift 12-Speed
Hydraulics	45 GPM, 3-4 remotes
3-Point Hitch	Category IV (Aftermarket)
Fuel Capacity	200 gallons
Weight	31,000 lbs
Years Produced	1996-2000

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250-300 hours using a high-quality diesel engine oil meeting John Deere specifications.
Hydraulic System: Check hydraulic oil levels regularly and replace hydraulic filters every 500 hours to prevent contamination and ensure proper hydraulic function.
Fuel System: Use clean, high-quality diesel fuel and replace fuel filters according to the manufacturer's recommendations to prevent fuel system problems.
Seasonal Storage: Before storing the tractor for the off-season, drain fluids, add fuel stabilizer, and protect it from the elements to prevent corrosion and ensure it starts easily when needed.

History & Background

The John Deere 9200 was introduced in 1996 as part of the 9000 series of articulated 4WD tractors. This series marked a significant step forward in tractor power and technology for John Deere. It remained in production until 2000, providing farmers with a reliable and productive machine for large-scale agricultural operations.

Frequently Asked Questions

What engine is in the John Deere 9200?

The John Deere 9200 is powered by a Cummins N14 diesel engine, producing between 305 and 360 horsepower.

What is the PTO horsepower on a 9200?

The PTO horsepower on a John Deere 9200 is typically rated between 220 and 265 HP, operating at 1000 RPM.

What oil filter fits the 9200?

The John Deere 9200 typically uses a John Deere oil filter part number RE504836 or a cross-reference such as a Fleetguard LF9009.

What are common parts needed for the 9200?

Common wear parts for the John Deere 9200 include engine oil filters, fuel filters, hydraulic filters, belts, hydraulic cylinder seal kits, steering cylinder repair kits, and clutch components.
