John Deere 6810 Tractor Parts

6810 parts and accessories

The John Deere 6810, manufactured from 1997 to 2001, is a robust and reliable agricultural tractor favored by farmers for its versatility. Powered by a John Deere 6.8L PowerTech diesel engine producing around 125 engine HP and approximately 105 PTO HP, this tractor delivers the performance needed for demanding tasks. Its blend of power and functionality made it a popular choice for a variety of farming operations.

The John Deere 6810 was introduced in 1997 as part of the John Deere 6010 series, designed to offer enhanced performance and operator comfort. Production continued until 2001. The tractor is equipped with a John Deere 6.8L PowerTech turbocharged diesel engine, delivering approximately 125 engine horsepower (93 kW). The engine displacement is 414 cubic inches (6.8 liters). Transmission options included a PowrQuad transmission with 16 forward and 16 reverse gears, providing excellent speed selection for different field conditions. The independent PTO delivers around 105 horsepower (78 kW) and offers both 540 and 1000 RPM options. Hydraulic capacity is rated at approximately 29 GPM (110 lpm), with typically two or three rear remote valves available. The 3-point hitch is a Category II, offering a lift capacity of around 8,157 lbs. (3700 kg). Common farming applications for the 6810 include row crop operations, hay production, livestock farming, and tillage work. It stands out from other models in the 6010 series due to its balance of power and maneuverability, making it a versatile workhorse for medium-sized farms.

Specifications

Engine	John Deere 6.8L PowerTech 125 HP Diesel
PTO HP	105 HP @ 540/1000 RPM
Transmission	PowrQuad 16F/16R
Hydraulics	29 GPM, 2-3 remotes
3-Point Hitch	Category II, 8,157 lbs
Fuel Capacity	47.6 gallons
Weight	12,346 lbs
Years Produced	1997-2001

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250-300 hours using the recommended John Deere oil or equivalent. Regularly check the oil level.
Hydraulic System: Inspect hydraulic fluid levels and filters every 500 hours. Replace filters as needed, and use only approved hydraulic fluid to prevent contamination.
Fuel System: Use clean, high-quality diesel fuel and replace the fuel filter every 500 hours to ensure optimal engine performance and prevent injector issues.
Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel, grease all fittings, and disconnect the battery to prevent corrosion.

History & Background

The John Deere 6810 was launched in 1997 as a key model in the 6010 series. It represented a step forward in terms of engine technology and operator comfort compared to previous generations. The 6810 helped solidify John Deere's reputation for producing reliable and versatile tractors suitable for a wide range of agricultural tasks.

Frequently Asked Questions

What engine is in the John Deere 6810?

The John Deere 6810 is powered by a John Deere 6.8L PowerTech turbocharged diesel engine, producing approximately 125 horsepower.

What is the PTO horsepower on a 6810?

The John Deere 6810 has a PTO horsepower rating of approximately 105 HP and offers both 540 and 1000 RPM options.

What oil filter fits the 6810?

The recommended oil filter for the John Deere 6810 is typically a John Deere filter part number RE504836. Cross-references include Wix 51791 and Baldwin B7349.

What are common parts needed for the 6810?

Common wear parts for the John Deere 6810 include oil filters, fuel filters, hydraulic filters, belts, hydraulic seals, steering components, and clutch parts. Regular replacement of these parts ensures optimal performance and minimizes downtime.
