John Deere 6130R Tractor Parts

6130R parts and accessories

The John Deere 6130R tractor, manufactured from 2011 to 2015, quickly became a favorite among farmers due to its versatility and power. Equipped with a robust 130 engine horsepower, 4.5L PowerTech diesel engine, and a PTO horsepower of around 105, this tractor offered a blend of size and performance ideal for a wide range of agricultural tasks. Its reliability and efficient design made it a valuable asset on any farm.

The John Deere 6130R was introduced in 2011 as part of the 6R series, replacing older models and offering enhanced features for improved productivity. Production continued until 2015. This tractor features a John Deere PowerTech 4.5L 4-cylinder diesel engine, producing approximately 130 engine horsepower. The engine's displacement is 4.5 liters, providing ample power for various agricultural applications. Transmission options included PowerQuad Plus, AutoQuad Plus, and DirectDrive (IVT) transmissions, offering a range of gear and continuously variable options to suit different operator preferences and field conditions. The PTO delivers around 105 horsepower, available in both 540 and 1000 RPM configurations, making it suitable for operating a variety of implements. The hydraulic system provides a flow rate of approximately 29 GPM, with multiple remote valves available for hydraulic implement control. The 3-point hitch is Category II, with a lift capacity of around 9,480 lbs. Common farming applications for the 6130R include row crop work, hay production, livestock operations, and light tillage. Its size and power differentiate it from smaller utility tractors while offering more maneuverability than larger row crop tractors, making it a versatile choice for diverse farming needs.

Specifications

Engine	John Deere PowerTech 4.5L 130 HP Diesel
PTO HP	105 HP @ 540/1000 RPM
Transmission	PowerQuad Plus, AutoQuad Plus, DirectDrive (IVT)
Hydraulics	29 GPM, Up to 4 remotes
3-Point Hitch	Category II, 9,480 lbs
Fuel Capacity	56.3 gallons
Weight	13,669 lbs
Years Produced	2011-2015

Maintenance Tips

Engine Oil and Filter: Change engine oil and filter every 500 hours using recommended John Deere oil and filter to maintain optimal engine performance and longevity.
Hydraulic System Maintenance: Inspect hydraulic fluid levels regularly and change the hydraulic filter every 1000 hours. Use only approved John Deere hydraulic fluid to prevent contamination and ensure smooth operation.
Fuel System Care: Use high-quality diesel fuel and regularly check the fuel filter for contamination. Consider using a fuel additive, especially during cold weather, to prevent fuel gelling.
Seasonal Storage: Before storing the tractor for the off-season, drain the fuel tank, add fuel stabilizer, and lubricate all grease fittings. Disconnect the battery and store it in a cool, dry place.

History & Background

The John Deere 6130R was launched in 2011 as part of the redesigned 6R series, representing a significant step forward in tractor technology and operator comfort. While there were no major redesigns during its production run (2011-2015), the 6130R solidified its place as a versatile and reliable tractor in modern agriculture, known for its efficient engine and advanced transmission options.

Frequently Asked Questions

What engine is in the John Deere 6130R?

The John Deere 6130R is equipped with a John Deere PowerTech 4.5L 4-cylinder diesel engine, producing approximately 130 horsepower.

What is the PTO horsepower on a 6130R?

The PTO horsepower on the John Deere 6130R is approximately 105 HP, available at both 540 and 1000 RPM.

What oil filter fits the 6130R?

The John Deere 6130R typically uses a John Deere oil filter part number RE504836. Other compatible filters may include cross-references from brands like Wix, Baldwin, or Donaldson. Always verify compatibility with your specific tractor's serial number and operator's manual.

What are common parts needed for the 6130R?

Commonly needed parts for the John Deere 6130R include engine oil filters, fuel filters, air filters, hydraulic filters, belts (fan belt, alternator belt), hydraulic seals and O-rings (for cylinders and remotes), steering components (tie rod ends, ball joints), and clutch parts (if applicable, depending on transmission type).

Showing 97-120 of 215 products
