John Deere 6030 Tractor Parts

6030 parts and accessories

The John Deere 6030, manufactured from 1972 to 1977, was a powerful and reliable tractor for its time, popular among farmers for its robust engine and versatility. Featuring a John Deere diesel engine producing approximately 125 horsepower, and delivering around 105 PTO horsepower, the 6030 was well-suited for a variety of demanding agricultural tasks. Its power and dependability solidified its place as a workhorse on many farms.

The John Deere 6030 was introduced in 1972 as a larger, more powerful tractor in the John Deere lineup, filling a need for increased horsepower in agricultural operations. Production continued through 1977. It's powered by a John Deere 6.6L (404 cu in) 6-cylinder diesel engine, producing around 125 engine horsepower. The transmission was typically a Synchro Range transmission with 8 forward and 2 reverse gears. The PTO delivers approximately 105 horsepower, and came with both 540 and 1000 RPM options. The hydraulic system offered a capacity of around 29 GPM, with multiple remote valves available for implements. It featured a Category II 3-point hitch. Common applications included row crop farming, hay baling and handling, livestock feeding operations, and tillage tasks. The 6030 differed from smaller models with its increased power and heavier build, while lacking the advanced features and size of larger frame tractors like the 8430. It was a solid, dependable workhorse in its class.

Specifications

Engine	John Deere 6.6L 125 HP Diesel
PTO HP	105 HP @ 540/1000 RPM
Transmission	Synchro Range 8F/2R
Hydraulics	29 GPM, 2-3 remotes
3-Point Hitch	Category II, 5900 lbs lift capacity
Fuel Capacity	46 gallons
Weight	13,500 lbs
Years Produced	1972-1977

Maintenance Tips

Check and change your engine oil and filter every 250 hours of operation using a high-quality diesel engine oil.
Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours to prevent contamination and maintain optimal hydraulic performance.
Use a fuel conditioner regularly, especially during storage to prevent fuel gelling and keep the fuel system clean.
Before seasonal storage, drain the fuel tank, add fuel stabilizer, and properly lubricate all grease fittings to protect the tractor from corrosion and ensure easy startup in the spring.

History & Background

The John Deere 6030 was launched in 1972 as a heavy-duty row crop tractor, providing farmers with a significant power upgrade. There were no major design changes during its production run, and it remains a sought-after classic for its reliability and capabilities, representing a pivotal era in agricultural mechanization.

Frequently Asked Questions

What engine is in the John Deere 6030?

The John Deere 6030 is equipped with a John Deere 6.6L (404 cu in) 6-cylinder diesel engine.

What is the PTO horsepower on a 6030?

The John Deere 6030 has a PTO horsepower rating of approximately 105 HP, available at both 540 and 1000 RPM.

What oil filter fits the 6030?

The John Deere oil filter for the 6030 is typically a John Deere AR50041 or equivalent. Common cross-references include Wix 51794 and Fram PH3756.

What are common parts needed for the 6030?

Commonly needed parts for the John Deere 6030 include engine oil filters, fuel filters, air filters, hydraulic filters, fan belts, hydraulic cylinder seal kits, tie rod ends, and clutch components.
