John Deere 5520 Tractor Parts

5520 parts and accessories

The John Deere 5520 tractor, manufactured from 2003 to 2007, offered farmers a reliable and versatile workhorse. Powered by a 75 HP diesel engine and delivering around 64 PTO horsepower, the 5520 was particularly popular for its blend of power and maneuverability in various agricultural applications. Its robust build and dependable performance solidified its place as a valued tractor on many farms.

The John Deere 5520 was introduced in 2003 as part of the John Deere 5000 series tractors and remained in production until 2007. This utility tractor is powered by a John Deere 4.5L (276 cu in) PowerTech 4045T four-cylinder diesel engine, producing approximately 75 engine horsepower. The engine is turbocharged for increased power and efficiency. Transmission options included a 9-speed SyncShuttle transmission (standard) or a 12-speed PowrReverser transmission offering enhanced directional control. The 5520 boasts a PTO horsepower rating of approximately 64 HP with a standard 540 RPM PTO, making it suitable for operating a wide range of implements. The hydraulic system delivers around 15.9 GPM, supporting two standard rear remotes for implement control. It features a Category II 3-point hitch with a lift capacity of approximately 4,189 lbs. Common farming applications for the 5520 include hay production, livestock operations (feeding, manure handling), light tillage, and row crop work. Compared to smaller models in the 5000 series, the 5520 offers more power and hydraulic capacity, while being more compact and fuel efficient than larger models.

Specifications

Engine	John Deere 4045T 75 HP 4.5L Diesel
PTO HP	64 HP @ 540 RPM
Transmission	SyncShuttle (9-speed) or PowrReverser (12-speed)
Hydraulics	15.9 GPM, 2 remotes
3-Point Hitch	Category II, 4189 lbs
Fuel Capacity	28.5 gallons
Weight	6,976 lbs
Years Produced	2003-2007

Maintenance Tips

Engine Oil and Filter: Change the engine oil and filter every 250 hours of operation using the recommended John Deere oil and filter. Regularly inspect the oil level and condition.
Hydraulic System Maintenance: Check the hydraulic fluid level regularly and change the hydraulic filter every 500 hours. Inspect hydraulic hoses and fittings for leaks and replace as needed to prevent contamination and system failure.
Fuel System Care: Use high-quality diesel fuel and change the fuel filter every 250 hours. Drain any water from the fuel/water separator regularly to prevent fuel system corrosion and injector problems.
Seasonal Storage: Before storing the tractor for extended periods, fill the fuel tank to prevent condensation and add a fuel stabilizer. Disconnect the battery, grease all lubrication points, and store the tractor in a dry, sheltered location.

History & Background

The John Deere 5520 was launched in 2003 as a versatile utility tractor in the popular 5000 series. It offered farmers a balance of power, maneuverability, and modern features. While the model didn't undergo any major redesigns during its production run, it remains a sought-after tractor for its reliability and adaptability to various farm tasks.

Frequently Asked Questions

What engine is in the John Deere 5520?

The John Deere 5520 is equipped with a John Deere 4045T 4.5L four-cylinder turbocharged diesel engine, producing approximately 75 horsepower.

What is the PTO horsepower on a 5520?

The PTO horsepower on the John Deere 5520 is approximately 64 HP at 540 RPM. The tractor is equipped with a standard 540 RPM PTO shaft.

What oil filter fits the 5520?

The recommended oil filter for the John Deere 5520 is typically a John Deere oil filter part number RE504836. Cross-references include Baldwin BD7151, Wix 51793, and Fleetguard LF3970.

What are common parts needed for the 5520?

Common wear parts for the John Deere 5520 include: engine oil filters (RE504836), fuel filters (RE522878), hydraulic filters (RE62419), fan belts, hydraulic cylinder seals, steering linkage components, and clutch discs.
