John Deere 5320N Tractor Parts

5320N parts and accessories

The John Deere 5320N, manufactured from 2004 to 2007, is a specialized narrow-row crop tractor known for its maneuverability and power in confined spaces. Powered by a 67 HP Yanmar diesel engine, this tractor delivered approximately 58 PTO horsepower. Its compact design and reliable performance made it a popular choice for orchard, vineyard, and other specialized farming operations.

The John Deere 5320N was produced from 2004 to 2007 as part of the John Deere's narrow-row tractor lineup. It's powered by a Yanmar 3.3L 3TNV88 diesel engine, producing approximately 67 horsepower. This tractor features a mechanical transmission, typically available as either a 9-speed forward/3-speed reverse or a 12-speed forward/12-speed reverse synchronized transmission. The PTO delivers around 58 horsepower and offers a 540 RPM setting. The hydraulic system has a capacity of around 11.9 GPM, providing ample power for implements. It features a Category II 3-point hitch. The 5320N found applications in row crop farming, particularly in orchards, vineyards, and vegetable farms where a narrow width is essential. What sets it apart from other John Deere tractors is its narrower profile and shorter wheelbase, allowing it to navigate tight rows and corners effectively. This model was designed for tasks like spraying, mowing, and light tillage in challenging environments, offering a blend of power and agility for specialized farming needs.

Specifications

Engine	Yanmar 67 HP 3.3L Diesel
PTO HP	58 HP @ 540 RPM
Transmission	Mechanical 9F/3R or 12F/12R
Hydraulics	11.9 GPM, 2 remotes
3-Point Hitch	Category II, 3285 lbs
Fuel Capacity	16.6 gallons
Weight	4630 lbs
Years Produced	2004-2007

Maintenance Tips

Engine Oil & Filter: Change engine oil and filter every 250 hours of operation. Use John Deere Plus-50 II oil and a genuine John Deere oil filter for optimal engine protection.
Hydraulic System: Check hydraulic fluid levels regularly and change the hydraulic filter every 500 hours. Use John Deere Hy-Gard fluid to maintain optimal performance and prevent component wear. Inspect hydraulic hoses and fittings for leaks or damage.
Fuel System: Use clean, high-quality diesel fuel and replace the fuel filter every 250 hours. Drain water from the fuel tank regularly to prevent fuel system corrosion and injector problems.
Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel with a fuel stabilizer, change engine oil and filter, lubricate all grease fittings, and disconnect the battery. Store the tractor in a dry, covered location.

History & Background

The John Deere 5320N was introduced in 2004 as a specialized narrow tractor, filling a need for compact and powerful machinery in niche agricultural applications. There were no major redesigns during its production run from 2004-2007. This model significantly impacted the market by providing a reliable and efficient solution for farms requiring maneuverability in tight spaces, helping to improve productivity and reduce labor costs.

Frequently Asked Questions

What engine is in the John Deere 5320N?

The John Deere 5320N is equipped with a Yanmar 3TNV88 3.3L 3-cylinder diesel engine, producing approximately 67 horsepower.

What is the PTO horsepower on a 5320N?

The John Deere 5320N has a PTO horsepower rating of approximately 58 HP at 540 RPM.

What oil filter fits the 5320N?

The John Deere 5320N uses a John Deere oil filter part number RE504836 or a cross-reference such as a Wix 51348 or Fram PH6022.

What are common parts needed for the 5320N?

Common parts needed for the 5320N include: oil filters, fuel filters, air filters, hydraulic filters, belts (fan, alternator), hydraulic seals (cylinder and pump), steering components (tie rod ends), and clutch parts (disc, pressure plate, release bearing).
