John Deere 5095M Tractor Parts

5095M parts and accessories

The John Deere 5095M, produced from 2009 to 2019, is a versatile utility tractor favored by farmers for its reliability and performance. Powered by a robust 95 horsepower PowerTech diesel engine, this model delivered ample power for various tasks. With a PTO horsepower rating around 80, the 5095M was well-suited for operating implements in haying, livestock, and general farm work.

The John Deere 5095M was introduced in 2009 as part of the 5M series, designed to offer a balance of power, comfort, and affordability. Production continued until 2019. At the heart of the 5095M is a John Deere PowerTech 4.5L 4-cylinder diesel engine. This engine produces a rated 95 engine horsepower. The engine's displacement is 276 cubic inches (4.5L). Transmission options included a 9-speed sync shift transmission, a 16-speed partial power shift transmission, or a 32-speed transmission with left hand reverser. PTO horsepower is approximately 80 HP, with options for either 540 RPM or 540/1000 RPM PTO speeds. The hydraulic system offers a flow rate of around 15.8 GPM, with available multiple rear remotes. It features a Category II 3-point hitch with a lift capacity around 4,200 lbs. The 5095M found applications in various farming operations, from row crop work and hay production to livestock management and light tillage. Compared to smaller models in the 5 series, the 5095M offered more power and hydraulic capacity. Compared to the larger frame 6 series, it was more compact and maneuverable.

Specifications

Engine	John Deere PowerTech 95 HP Diesel
PTO HP	80 HP @ 540/1000 RPM
Transmission	9-speed Sync Shift, 16-speed Partial Power Shift, or 32-speed
Hydraulics	15.8 GPM, 2-3 remotes
3-Point Hitch	Category II, 4,200 lbs lift capacity
Fuel Capacity	31.7 gallons
Weight	8,200 lbs
Years Produced	2009-2019

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using the recommended John Deere oil specification. Regularly check oil levels and inspect for leaks.
Hydraulic System: Inspect hydraulic fluid levels and filters every 500 hours. Replace filters as needed and use the correct hydraulic fluid to prevent damage and maintain optimal performance.
Fuel System: Use clean, high-quality diesel fuel. Regularly drain the fuel-water separator to prevent water contamination, which can damage the fuel injection system. Consider adding a fuel stabilizer during seasonal storage.
Seasonal Storage: Before storing the tractor for extended periods, stabilize the fuel, change the engine oil and filter, grease all fittings, disconnect the battery, and store the tractor in a dry, covered location.

History & Background

The John Deere 5095M was launched in 2009, representing John Deere's commitment to providing robust and versatile utility tractors for modern farming. Throughout its production run until 2019, the 5095M remained a popular choice, becoming a staple on many farms due to its balance of power, reliability, and ease of use. It has contributed significantly to improved farming practices across various agricultural applications.

Frequently Asked Questions

What engine is in the John Deere 5095M?

The John Deere 5095M is equipped with a John Deere PowerTech 4.5L 4-cylinder diesel engine producing 95 horsepower.

What is the PTO horsepower on a 5095M?

The PTO horsepower on the John Deere 5095M is approximately 80 HP. It offers options for both 540 RPM and 540/1000 RPM PTO speeds.

What oil filter fits the 5095M?

The recommended oil filter for the John Deere 5095M is typically a John Deere oil filter part number RE504836. Cross-references include Baldwin BD7317, Fleetguard LF16015, or Wix WL10001.

What are common parts needed for the 5095M?

Common wear parts for the John Deere 5095M include engine oil filters, fuel filters, air filters, hydraulic filters, belts (fan belt, alternator belt), hydraulic cylinder seal kits, steering components (tie rod ends), and clutch parts (if applicable to transmission type).
