John Deere 4255 Tractor Parts

4255 parts and accessories

The John Deere 4255, manufactured from 1989 to 1992, is a powerful utility tractor favored for its reliability. Equipped with a John Deere 6.8L diesel engine producing around 110 engine HP and approximately 90 PTO HP, this model offered a strong combination of power and versatility. Farmers appreciated its robust build and adaptability to various agricultural tasks, from tillage to haying.

Introduced in 1989, the John Deere 4255 was part of the '55 series, known for improved operator comfort and increased hydraulic capacity compared to previous models. Production continued through 1992. The heart of the 4255 is a John Deere 6.8L (414 cu in) six-cylinder diesel engine, delivering approximately 110 horsepower. It features a direct injection fuel system for improved efficiency. Transmission options included a SyncroPlus transmission with 12 forward and 4 reverse gears, or a PowrQuad transmission providing 16 forward and 8 reverse speeds. The 4255 delivered around 90 PTO horsepower, with a standard independent 540/1000 RPM PTO. Its hydraulic system offered a flow rate of approximately 25 GPM, often equipped with two or three remote valves. The 3-point hitch is a Category II, capable of lifting around 6,200 lbs. This tractor was commonly used for row crop operations, hay production, livestock management (baling and feeding), and general tillage work. The 4255 differentiated itself with its comfortable cab, increased hydraulic performance, and the choice between synchro and powershift transmissions, providing farmers with the flexibility to choose the features that best suited their needs.

Specifications

Engine	John Deere 6.8L 110 HP Diesel
PTO HP	90 HP @ 540/1000 RPM
Transmission	SyncroPlus/PowrQuad, 12F/4R or 16F/8R
Hydraulics	25 GPM, 2-3 remotes
3-Point Hitch	Category II, 6200 lbs lift capacity
Fuel Capacity	44 gallons
Weight	11,174 lbs
Years Produced	1989-1992

Maintenance Tips

Engine Oil & Filter: Change engine oil and filter every 250 hours using the recommended John Deere oil specification for optimal engine protection.
Hydraulic System: Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours to prevent contamination and maintain proper hydraulic performance.
Fuel System: Use clean, high-quality diesel fuel and replace the fuel filter annually or every 500 hours to ensure proper fuel delivery and prevent injector clogging.
Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel, lubricate all grease fittings, and protect the tires from direct sunlight to prevent deterioration.

History & Background

The John Deere 4255 was launched in 1989 as part of John Deere's '55 series tractors. This series represented an advancement in operator comfort and hydraulic performance compared to its predecessors. The 4255 quickly became a popular choice for farmers needing a versatile and reliable tractor in the 100-120 horsepower range.

Frequently Asked Questions

What engine is in the John Deere 4255?

The John Deere 4255 is equipped with a John Deere 6.8L (414 cu in) six-cylinder diesel engine producing approximately 110 horsepower.

What is the PTO horsepower on a 4255?

The John Deere 4255 delivers approximately 90 PTO horsepower, with an independent PTO operating at both 540 and 1000 RPM.

What oil filter fits the 4255?

The John Deere 4255 typically uses a John Deere oil filter part number AR77919. Alternative cross-references include Wix 51794 and Fram PH3756.

What are common parts needed for the 4255?

Common wear parts for the John Deere 4255 include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic cylinder seals, steering linkage components, and clutch discs.
